Dimensions Guide

Architectural Detail Manual
July 2010
JELD-WEN reserves the right to change specifications without notice.
Pa
g
e7-38
QT1 QT2
RT1 RT2
RT3
RT4
LP7
LP8 LP14 LP16
LP18
LP1 LP2 LP3
LP4
LP5
EXTENDED CIRCLE SEGMENT
EXTENDED HALF ROUND
EXTENDED QUARTER ROUND
GRILLE & SDL LITE PATTERNS
Fixed, Radius and Geometric Windows
Premium Vinyl
