Dimensions Guide

Architectural Detail Manual
July 2010
JELD-WEN reserves the right to change specifications without notice.
Pa
g
e7-8
PICTURE UNITS
PPC3660 PPC3860 PPC4260 PPC4860 PPC5460
PPC3666 PPC3866 PPC4266 PPC4866 PPC5466
PPC3672 PPC3872 PPC4272 PPC4872 PPC5472
PPC3678 PPC3878 PPC4278 PPC4878 PPC5478
PPC3684 PPC3884 PPC4284 PPC4884 PPC5484
35 35 35 35 35
35 35 35 35 35
35 35 35 35 35
35 35 35 35 35
35 35 35 35 35
36”(914)
37 3/4”(959)
35 1/2”(902)
31 7/8”(810)
38”(965)
39 3/4”(1010)
37 1/2”(953)
33 7/8”(860)
42”(1067)
43 3/4”(1111)
41 1/2”(1054)
37 7/8”(962)
48”(1219)
49 3/4”(1264)
47 1/2”(1207)
43 7/8”(1114)
54”(1372)
55 3/4”(1416)
53 1/2”(1359)
49 7/8”(1267)DAYLIGHT OPENING
FRAME SIZE
ROUGH OPENING
UNIT SIZE
60”(1524)
61 3/4”(1568) 59 1/2”(1511) 55 7/8”(1419)
66”(1676)
67 3/4”(1721) 65 1/2”(1664) 61 7/8”(1572)
72”(1829)
73 3/4”(1873) 71 1/2”(1816) 67 7/8”(1724)
78”(1981)
79 3/4”(2026) 77 1/2”(1969) 73 7/8”(1876)
84”(2134)
85 3/4”(2178) 83 1/2”(2121) 79 7/8”(2029)
Fixed, Radius and Geometric Windows
Premium Vinyl
SCALE: 1
/
4” = 1’
