Dimensions Guide

Architectural Detail Manual
July 2010
JELD-WEN reserves the right to change specifications without notice.
Pa
g
e7-14
PICTURE UNITS
PPC7860 PPC8460 PPC9060
PPC7866 PPC8466 PPC9066
PPC7872 PPC8472 PPC9072
PPC7878 PPC8478 PPC9078
PPC7884 PPC8484
35 35 35
35 35 35
35 35 35
35 35 35
35 35
DAYLIGHT OPENING
FRAME SIZE
ROUGH OPENING
UNIT SIZE
60”(1524)
61 3/4”(1568) 59 1/2”(1511) 55 7/8”(1419)
66”(1676)
67 3/4”(1721) 65 1/2”(1664) 61 7/8”(1572)
72”(1829)
73 3/4”(1873) 71 1/2”(1816) 67 7/8”(1724)
78”(1981)
79 3/4”(2026) 77 1/2”(1969) 73 7/8”(1876)
84”(2134)
85 3/4”(2178) 83 1/2”(2121) 79 7/8”(2029)
78”(1981)
79 3/4”(2026)
77 1/2”(1969)
73 7/8”(1876)
84”(2134)
85 3/4”(2178)
83 1/2”(2121)
79 7/8”(2029)
90”(2286)
91 3/4”(2330)
89 1/2”(2273)
85 7/8”(2181)
Fixed, Radius and Geometric Windows
Premium Vinyl
SCALE: 1
/
4” = 1’
