Dimension Guide

JENN-AIR
®
DETAILED PLANNING DIMENSIONS
2 of 3
IMPORTANT: Dimensional specifications are provided for planning purposes only.
Do not make any cutouts based on this information. Refer to the Installation Guide before
selecting cabinetry, verifying electrical/gas connections, making cutouts or beginning installation.
All Jenn-Air
®
appliances are appropriately UL, CUL or CSA approved. 8719AdZw816
C
C
L L
K K
M
N
O
135º 135º
A A
B
C
D
E
F
G
J
H
I
E
F
G
H
I
A*
B*
C*
D*
H
I
P
JFFCC72EF
SIDE VIEW
MODEL # JFFCC72EF
in cm
A*
Height to top of drawer (min.) 24
15
⁄16 63.3
B*
Height to top of drawer handle (min.)
Pro-Style
®
Stainless 23
11
⁄16 60.2
Euro-Style Stainless 23
9
⁄16 59.8
C*
Height of recessed refrigerator (min.) 70
15
⁄16 180.1
D*
Height to top of hinges (min.) 71
15
⁄16 182.7
E
Depth with drawer fully open
including drawer handle (min.)
Pro-Style
®
Stainless 46
7
⁄16 117.9
Euro-Style Stainless 45
15
⁄16 116.7
F
Depth with handles (min.)
Pro-Style
®
Stainless 31
15
⁄16 81.1
Euro-Style Stainless 31
1
⁄4 79.4
G
Depth with doors (min.) 29
5
⁄16 74.4
H
Depth without doors (min.) 24
5
⁄8 62.6
I
Depth to back of hinges (min.) 16
3
⁄4 42.6
* Add
3
⁄4" (1.9 cm) to the height dimension when leveling legs are fully
extended.
DIMENSIONS AS INSTALLED
72" COUNTER-DEPTH FRENCH DOOR REFRIGERATORS WITH EXTERNAL DISPENSER
JFFCC72EF – 35
3
/4" x 71
15
⁄16" x 31
1
/4" (with handles)
