MODEL SMPV-4GBEB DIGITAL MEDIA PLAYER PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE
DEAR JENSEN CUSTOMER Selecting fine audio equipment such as the unit you've just purchased is only the start of your musical enjoyment. Now it's time to consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the Electronic Industries Association's Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level.
permanent record of your purchase to aid in identification in the event of theft of loss. Model Number:SMPV-4GBEB Serial No: L SAFETY INFORMATION Read this user guide carefully to ensure proper use of the product and to avoid any danger or physical damage. Do not use this unit in extremely hot, cold, dusty and moist environment. Do not drop the unit, this could cause damage to the external cabinet as well as internal components. Do not repair the unit by yourself, or it will cause damage.
NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
POWER SOURCE & RECHARGING This unit operates on a built-in Li –polymer battery and must be charged prior to use. Please charge the unit for at least 8 hours before first use. 1. Connect the PC USB port and the unit’s USB port with the provided USB cable. 2. An animating battery icon will appear as shown in the diagram on the right during charging. Once full charged, the battery will stop running. The average recharging time is approximately 3 hours for normal use. 3.
3. Please dispose of properly for recycling. COMPONENTS AND BUTTON FUNCTIONS 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. [- ]: Backward/Fast Backward/Volume Down Button [ +]: Forward/Fast Forward/Volume Up Button [R/V]: Record/Volume Button [M]: Menu Button [ ]: Power on/off / Play/Pause Button LCD Screen Lanyard Strap Hole Mini USB Port Reset Button / mic opening Headphone Jack Hold (Key Lock) Switch DOWNLOADING MUSIC TO YOUR UNIT Connecting to your Personal Computer: 1.
2. 3. The unit will turn itself on automatically. The LCD screen will look like the image on the right indicating a successful connection to the computer’ USB interface is established successfully. For Windows XP/Vista/7 users, once the unit is connected to your computer, it appears as a removable drive in “My Computer”. Downloading files into your unit: For Windows users: 1. Select the track(s) you want to download. 2. Right-click on the file(s), a menu pops up and click “Copy”. 3.
Removing the unit from the computer: Note: Please follow these steps carefully to avoid data loss or unit damage. For Windows users: 1. Click on the “Safely Remove Hardware” icon (green arrow) in the system tray of your Windows desktop to bring up the list of USB Mass Storage Device attached to our computer. 2. 3. 4. 5. From the device list, choose the Drive designator that corresponds to your unit, for example Drive (H:). Click on the chosen device to unload it from your computer system.
Creating the playlist: As soon as the USB cable is disconnected from the unit, the following prompt will pop up: “ Create playlist or not “ Tap Button for “Yes” or M Button for “No“.
1. 2. 3. Hold the Button to turn on the unit. On first use, please press the Reset button once with a pointed object such as a straighten paper clip, to correctly initialize the unit and the unit will restart and go to Music function of Main Menu automatically. To turn unit off, hold Button. Playing music, video, voice/radio recordings 1. Connect the earbuds to the Headphone Jack. 2. Make sure the Hold Switch is set to the unlock ² position. 3.
2. 3. Tap the M Button to save the current recording to the Record\Voice subfolder. Hold the M Button to return to the previous function screen. Volume Adjustment In Music, Video, Playback or Radio mode, tap R/V Button to select volume adjust mode. When the speaker icon is shown reversed, tap or hold either - or + Button to decrease or increase the volume output. FUNCTION MENUS AND SETTINGS Menu Navigation 1.
Indicators of Music function EQ mode: shows either Nature, Rock, Pop, Classical, Soft, Jazz, DBB or SRS WOW™HD in effect File type & bitrate: shows MP3,WMA,OGG,ASF,APE file types and its bitrate in kbps File search mode: it shows up when file mode in navigation submenu is chosen Folder search mode: it shows up when folder mode in navigation submenu is chosen File information: shows current file number/total file number, filename, ID3 tag & storing folder details Lyrics available: indicates a displayable ly
bar graph Volume adjust: it will be highlighted when volume adjust mode is selected by R/V Button Playing time: shows the elapsed and total time of current music file Battery level: shows 3 blue segments when fully charged, Press M Button for more functions below: While playing, the following 13 functions are available: MENU-1-1 Repeat mode Tap - or + Button to choose from 7 playback/repeat modes: Normal (default) – Repeat one – Folder once – Folder – Repeat all – Random - Intro Press Button to confirm.
WOW technology is incorporated under license from SRS Labs, Inc. MENU-1-4 Tempo rate This function allows you to change the playback speed. There are 17 levels from -8 to +8 in which -8 is the slowest, +8 is the fastest and 0 (default) means normal speed. MENU-1-5 A-B replay This function allows you to repeat a certain passage of MP3 songs only for the chosen number of cycles at the chosen rest interval in between successive replays. MENU-1-5-1 Replay Tap Button to start replay function.
This function displays all accessible folders in the unit’s user memory. Note: the ROOT folder is reserved for system use. MENU-1-7 List mode This function lists all compatible music files in the unit’s memory according to Title, Artist, Album & Filename. Choose the Exit option to return to the music screen. MENU-1-8 Favorite This function lets you keep a quick list of your favorite music tracks. Choose the Exit option to return to the music screen.
folder. When all tracks in the current folder are listed, it will proceed to the files in the previous or next folder. MENU-1-9-2 Folder mode Tap Button to enable folder search mode. In the music screen, when you tap/hold the - or + Button, it will go back to previous or next music folder until the last or first folder is reached. MENU-1-10 Bookmark While playing a music track, this function let you insert bookmarks (timestamps) within it for instant playback from those entry points.
This function allows you to set the fast forward or reverse speed while playing a music track. Tap - or + Button to choose from 5 speeds: 1X – 2X – 4X (default) – 8X -16X Press Button to confirm. MENU-1-12 FFREV sound setting This function allows you to set whether sound can be heard while quickly searching within the playing music track. Tap - or + Button to choose from: Sound off (default) – Sound On. MENU-1-13 Exit Choose this to return to music screen.
Tap Button to confirm. MENU-1-4 Fade in/out time Tap Button to set the fade in (rise) and fade out (decay) time in music playback. Tap - or + Button to choose from 3 settings: Fast (default) – Normal - Slow Press Button to confirm. MENU-1-5 Exit Choose this to return to music screen. MENU-2 VIDEO Choose VIDEO to play only AMV or AVI files converted by the included video conversion software. Please refer to the video converter quick guide for details. Tap Button to start playing.
Tap Button to confirm. MENU-2-3 Delete all Tap Button to permanently delete all files in the current folder from memory. Tap - or + Button to choose from “No” (default) or “Yes”. Tap Button to confirm. MENU-2-4 Repeat Tap - or + Button to choose from 7 playback/repeat modes: Normal – Repeat one – Folder once – Folder – Repeat all – Random - Intro Press Button to confirm. MENU-2-5 Exit Choose this to return to video pause or stop screen.
Note: “Fine” quality will take up larger memory space than “Long” type for same recording time. MENU-3-3 Record gain Tap Button to set the sensitivity of the built-in recording microphone. Tap - or + Button to choose from 0 – 7 where 0 is lowest sensitivity and 7 is highest. Default setting is 3. Tap Button to confirm. MENU-3-4 Exit Choose this to return to record pause or stop screen. MENU-4 PLAYBACK Choose PLAYBACK to playback live or radio recordings stored in memory.
Tap + Button to fix replay end point B. “A-B” stops flashing and now it starts to replay the passage between markers A and B. If you want to change the marker points for a new replay passage, just tap - Button, then “A” start to flash and repeat above steps to complete. Tap Button to terminate A-B replay function. MENU-4-4 Exit Choose this to return to playback pause or stop screen.
Indicators of Radio function FM stereo indicator: appears when a strong stereo signal is received Preset channel number (CH01 – 20): indicates the current preset channel number Receiving frequency: indicates the current FM frequency Frequency scale (87.5-108MHz): the red pointer on the frequency scale indicates the relative location of the receiving frequency From the radio screen, tap - or + Button to manually tune to the desired FM station frequency at 0.1MHz interval.
Tap Button to pause during recording and tap it again to resume. Tap M Button to save the current recording. Hold M Button to return to the radio function screen. Tap M Button for 5 more options: MENU-5-1 Save Tap Button to save the receiving frequency into the next available preset channel location. If all preset channels are full, the save function will be aborted. MENU-5-2 Delete Tap Button to clear the current preset channel from memory instantly.
Tap Button to open. While displaying an image in manual mode, tap - or + Button to choose the previous or next image. Tap M Button or Button to return to picture folder list. While in stop mode, the following 5 functions are available: MENU-6-1 Local folder Tap Button to display all supported files in the current folder. Tap - Button to choose “ \ ” to go up one level to display all other folders in the user memory. Tap - or + Button to choose the desired folder. Tap Button to confirm.
MENU-7 TEXT Choose TEXT to read “eBook” or text files (ANSI format). Tap Button to display all support text files in the current folder. Tap - or + Button to choose the desired file. Tap Button to open. While reading, the following functions are available: Tap - or + Button to go to previous or next page (when manual scroll is chosen) Tap Button to stop and return to text folder list. Hold M Button to return to Main Menu.
Tap - or + Button to choose the desired folder. Tap Button to confirm. MENU-7-2 Display mode This function allows you to set the text scroll function. Tap - or + Button to choose from 2 options: Manual – Auto (default). For auto scroll, tap - or + Button to choose from 1 to 10 seconds (default is 3 seconds). MENU-7-3 Delete file Tap Button to display all supported files in the current folder. Tap - or + Button to choose the desired file to permanently delete from memory. Tap Button to select.
Choose SETTING to customize the unit to fit your preferences. MENU-9-1 System time Choose this to set the system time for live/radio recordings. Tap M Button to highlight the Year item and then tap - or + Button to adjust the it. Tap M Button to highlight the next Month item and then tap - or + Button to adjust it. Repeat the above procedure to set the Day, Hour, Minute and Second items accordingly. Tap Button after adjusting the last item to confirm and exit.
Tap - or + Button to choose from 4 options: 0 (default) -15 30 -60 minutes where 0 means sleep mode is off. MENU-9-5 A-B replay Choose this to set A-B replay mode of Music and Playback functions. Tap - or + Button to choose from 2 options: Manual replay (default) – Auto replay Note: when auto replay is selected, you only need to set the starting point A and the system will automatically complete the end point B according to previous A-B settings.
Before first use and after charging up your unit, we recommend you to press the Reset Button located between the USB port and Headphone Jack to correctly initialize it. In case of an erroneous display or prolonged abnormal behavior during normal use, you can also safely restore it to its factory preset conditions by pressing the Reset Button. Please note that all personal settings including current time, alarm time and sleep session will be cleared.
The system time is not controlled by quartz and therefore may gain time faster than normal clocks. Please try to check and adjust the system time, if necessary, before making live/radio recordings. Check out for correct interface language you have chosen. - Make sure the USB port of your computer is working normally and the connecting cable is not broken. - Make sure memory space of your player is not full.
Preset EQ & SRS Sound Effects FM Band FM Preset Channels 19 User Interface Languages Operating System Supported File System Working Temperature Nature, Rock, Pop, Classical, Soft, Jazz, DBB & SRS WOW™ HD 87.50 -- 108.00MHz 20 Simplified Chinese, Traditional Chinese, English (default), Japanese, Korean, French, German, Italian, Dutch, Portuguese, Spanish, Swedish, Czech, Danish, Polish, Russian, Turkish, Hungarian, Romanian.
warranty, the return charges will be at SPECTRA’s expense. There are no other express warranties other than those stated herein. This warranty is valid only in accordance with the conditions set forth below: 1. The warranty applies to the SPECTRA product only while: a. It remains in the possession of the original purchaser and proof of purchase is demonstrated. b.
IF THE UNIT IS OUTSIDE THE WARRANTY PERIOD, please include a check for $25.00 to cover the cost of repair, handling and return postage. All out of warranty returns must be sent prepaid. It is recommended that you contact SPECTRA first at 1-800-777-5331 or by e-mail at info@spectraintl.com for updated information on the unit requiring service. In some cases the model you have may be discontinued and SPECTRA reserves the right to offer alternative options for repair or replacement.
