JLBIFF 1802 Built-in fridge freezer Instruction manual John Lewis Partnership 171 Victoria Street London SW1E 5NN www.johnlewis.
Important Safety Information It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings. These warnings have been provided in the interest of safety.
Something not working If the appliance is not working correctly, please carry out the following checks, before contacting your local Service Force repair agent. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. SYMPTOM 4 No power to the appliance SOLUTION Ñ Check there is power at the socket. Ñ Check there is not a power cut by checking the household lights.
Maintenance and Cleaning Contents For the User Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. For the Installer Important Safety Information 2 Installation 6 Internal cleaning Description of the appliance 5 Technical Specification 6 Control panel 12 Electrical Connection 6 Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water). Rinse and dry thoroughly.
Description of the Appliance Hints and Tips Food Storage • To obtain the best results from your appliance, neither hot foods nor liquids which may evaporate, should be placed in the larder compartment. • Keep the time between buying chilled food and placing it in your fridge as short as possible. • Do not push food together too much, try to allow air to circulate around each item. • Do not store food uncovered. • Remove suspect food from your refrigerator and clean, refer to ‘Maintenance and Cleaning’.
Installation Positioning the door shelves It is dangerous to alter the specifications or attempt to modify this product in any way. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. Care must be taken to ensure that the appliance does not stand on the electrical supply cable. To permit storage of food packages of various sizes, the door shelves can be adjusted in height.
Using the refrigerator The thermostat is valid for both freezer and refrigerator compartments. Fresh food refrigeration Setting the temperature To obtain the best performance, do not store warm food or evaporating liquids in the refrigerator; do cover or wrap the food, particularly if it has a strong flavour. The temperature inside the refrigerator is regulated by the thermostat with 6 temperature positions and an “OFF” (O) position.
Using the freezer Building In Before use Before carrying out any work, remove the plug from the power socket. Remove all securing tapes.Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). Please ensure that when the appliance is installed it is easily accessible for the engineer in the event of a breakdown. Do not use soap or detergent as the smell may linger. Dry thoroughly. Quick-freezing The appliance is supplied with the right or left door opening.
The Control Panel Fit the appliance in the niche by making sure that it stands against the interior surface of the unit on the side where the door hinges of the appliances are fitted. Insert the appliance until the upper strip butts up against the unit (1) and make sure that the lower hinge is in line with the surface of the unit (2).
Place guide (Ha) on the inside part of the furniture door, up and down as shown in the figure and mark the position of external holes.After having drilled holes, fix the guide with the screws supplied. Fix cover (Hd) on guide (Hb) until it clips into place. ca. 50 mm 90° 21 m m Hb 90° ca.
Place guide (Ha) on the inside part of the furniture door, up and down as shown in the figure and mark the position of external holes.After having drilled holes, fix the guide with the screws supplied. Fix cover (Hd) on guide (Hb) until it clips into place. ca. 50 mm 90° 21 m m Hb 90° ca.
The Control Panel Fit the appliance in the niche by making sure that it stands against the interior surface of the unit on the side where the door hinges of the appliances are fitted. Insert the appliance until the upper strip butts up against the unit (1) and make sure that the lower hinge is in line with the surface of the unit (2).
Using the freezer Building In Before use Before carrying out any work, remove the plug from the power socket. Remove all securing tapes.Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). Please ensure that when the appliance is installed it is easily accessible for the engineer in the event of a breakdown. Do not use soap or detergent as the smell may linger. Dry thoroughly. Quick-freezing The appliance is supplied with the right or left door opening.
Using the refrigerator The thermostat is valid for both freezer and refrigerator compartments. Fresh food refrigeration Setting the temperature To obtain the best performance, do not store warm food or evaporating liquids in the refrigerator; do cover or wrap the food, particularly if it has a strong flavour. The temperature inside the refrigerator is regulated by the thermostat with 6 temperature positions and an “OFF” (O) position.
Installation Positioning the door shelves It is dangerous to alter the specifications or attempt to modify this product in any way. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. Care must be taken to ensure that the appliance does not stand on the electrical supply cable. To permit storage of food packages of various sizes, the door shelves can be adjusted in height.
Description of the Appliance Hints and Tips Food Storage • To obtain the best results from your appliance, neither hot foods nor liquids which may evaporate, should be placed in the larder compartment. • Keep the time between buying chilled food and placing it in your fridge as short as possible. • Do not push food together too much, try to allow air to circulate around each item. • Do not store food uncovered. • Remove suspect food from your refrigerator and clean, refer to ‘Maintenance and Cleaning’.
Maintenance and Cleaning Contents For the User Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. For the Installer Important Safety Information 2 Installation 6 Internal cleaning Description of the appliance 5 Technical Specification 6 Control panel 12 Electrical Connection 6 Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water). Rinse and dry thoroughly.
Something not working If the appliance is not working correctly, please carry out the following checks, before contacting your local Service Force repair agent. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. SYMPTOM 4 No power to the appliance SOLUTION Ñ Check there is power at the socket. Ñ Check there is not a power cut by checking the household lights.
Important Safety Information It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings. These warnings have been provided in the interest of safety.
JLBIFF 1802 Built-in fridge freezer Instruction manual John Lewis Partnership 171 Victoria Street London SW1E 5NN www.johnlewis.
