JLBIHD603 - JLBIHD904 built-in cooker hood Instruction manual
Important Safety Information It is most important that this instruction manual should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings. These warnings ha ve been pr ovided in the inter est of saf ety .
Contents For the User Important Safety Information Description of the Appliance For the Installer 2 Electrical Connections 9 4 Electrical Requirements Electrical Connection 9 9 Using the cooker hood 10 Installing the Cooker Hood 5 Cooker Hood Controls To Operate Recirculation Extraction 10 10 10 10 Maintenance and Cleaning 11 External Cleaning Metal Grease Filters Charcoal Filters To Remove/Replace Charcoal Filter Changing the Light Bulb 11 11 12 12 12 Installation Requirements Unpacking Fi
Description of the Appliance 90 8 650 min.
Installation Please ensure that when the appliance is installed it is easily accessible to an engineer in the event of a breakdown. All installations must comply with the local authorities requirements for the discharge of exhaust air. Incorrect installation may affect the safety of this cooker hood. Installation Requirements Before installation check the wall to which the cooker hood is to be fitted for electric cables, water pipes or gas.
Installing the Cooker Hood 1÷2 Fitting the Wall Brackets 12a 116 116 306 11 X 7.2.1 650 min. • Draw a vertical line on the supporting wall up to the ceiling, or as high as practical, at the centre of the area in which the hood will be installed. • Draw a horizontal line at 650 mm above the hob. • Place bracket item 7.2.1 on the wall as shown about 1-2 mm from the ceiling or upper limit aligning the centre (notch) with the vertical reference line.
Extraction (Ducted) The cooker hood is more effective when installed in the extraction mode (ducted to the outside). Venting kits may be purchased through your retailer or DIY store, and must be evacuated through an outside vent of ø125 (5ins) or ø150mm (6ins). The ducting used must be manufactured from fire retardent material conforming to the relevant British Standard or DIN 4102-B1. When the cooker hood is ducted to the outside the charcoal filter must be removed.
Fitting the Upper Chimney • Expand the sides of the upper chimney stack item 2.1 and place the chimney over the two brackets 7.2.1 ensuring they are well seated. • Secure the chimney stack to the brackets 7.2.1 using the four self tapping screws item 12c (2.9 x 9.5mm) supplied. Fitting the Lower Chimney • Expand the of the lower chimney stack item 2.2 and place the chimney over the upper chimney stack item 2.1 and the canopy. • Secure the chimney stack to the canopy using the two screws item 12c (2.9 x 9.
Electrical Connections DOUBLE INSULATED DO NOT EARTH Electrical Requirements Any permanent electrical installation must comply with the latest I.E.E. Regulations and local Electricity Board regulations. For your own safety this should be undertaken by a qualified electrician e.g. your local Electricity Board, or a contractor who is on the roll of the National Inspection Council for Electrical Installation Contracting (NICEIC).
Using the cooker hood The cooker hood is designed to extract unpleasant odours from the kitchen, it will not extract steam. The appliance can be installed to recirculate or extract contaminated air. Cooker Hood Controls The cooker hood functions are controlled by four push button switches located centrally in the control fascia. L Turns the worktop lighting On and Off S Mains light - illumination indicates fan motor is running V1 Motor ON/OFF switch.
Maintenance and Cleaning Before carrying out any maintenance or leaning isolate the cooker hood from the mains supply. The cooker hood must be kept clean, as a build up of grease or fat can be a fire hazard. External cleaning Wipe the cooker hood frequently with warm soapy water using a mild detergent. Never use scouring pads or abrasive cleaners. Never use excessive amounts of water when cleaning particularly around the control panel.
Before carrying out any maintenance or cleaning isolate the cooker hood from the mains supply. Charcoal Filters In the recirculation mode the charcoal filters absorb smells and unwanted odours. The charcoal filters cannot be cleaned, we recommend they should be replaced approximately every three months or more often if the hood is used for more than three hours per day. To Remove/Replace the Charcoal Filters 1. First remove the metal grease filters. 2.
Something not Working If the appliance is not working correctly, please carry out the following checks, before contacting your local Service Force agent. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. Symptom Solution The cooker hood will not start • Check the hood is connected to the electricity supply. • Make sure the switch is in the ‘ON’ position.
John Lewis Partnership 171 Victoria Street London SW1E 5NN www.johnlewis.
