JLFFW2001 - JLFFS2002 Fridge-Freezer Instruction Booklet 214.3679.
Contents Instructions for the User Instructions for the Installer Safety Instructions 4 Technical Specifications 12 Description of the Appliance 5 Installation 13 Control Panel 5 Unpacking 13 Using the Appliance 7 Positioning 13 Before Use 7 Ventilation 13 Starting the Appliance 7 Levelling 13 Freezer Compartment 7 Freezing Fresh Food 7 Frozen Food Storage 7 Refrigerator Compartment 7 Fresh Compartment 7 Food Storage Electrical Requirements Door Reversal 14 14 15 8 En
Safety Instructions These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using this appliance. If you are unsure of the meanings of these warnings contact the John Lewis Branch from which you purchased the appliance. Installation • • • • • This appliance is heavy. Care should be taken when moving it. It is dangerous to alter the specifications or attempt to modify this product in any way.
Description of Appliance Control Panel Butter and Cheese Compartment Bottle Rack Shelves Door Storage Compartment Fruit/Vegetable drawer Bottle Compartment Fresh Box Door Storage Compartment Fast freeze compartment Freezer Drawer Control Panel 1 Freezer 7 3 6 Alarm °C off Quick freeze On/Off Fridge 4 5 1 4 5 1 1 2 3 Stand by 2 2 3 Freezer Temperature Control Door Alarm Temperature Alarm 4 5 3 2 6 4 5 6 Fast Freezer Button ON/OFF Button Fridge Temperature Control 5
Control Panel ON/OFF Button The appliance controls are located in the top panel inside the refrigerator compartment. Thermostat Control To switch the appliance on or off, press the ON/OFF button continuously for 3 seconds. When the appliance is switched on, the ON/OFF button will illuminate. The freezer and fridge thermostats control the temperature inside the freezer and refrigerator respectively.
Using the Appliance This appliance is designed for domestic use only, specifically for storage of edible foodstuffs. This appliance is designed to operate in ambient temperatures (surrounding air temperature) between 10°C (50°F) and 32°C (90°F). If these temperatures are exceeded i.e. colder or warmer, the appliance may not operate correctly. Before Use Remove all transit packaging. Wash the inside of the appliance with lukewarm water with a little bicarbonate of soda added (5ml to 0.5 litre of water).
Food Storage Energy Saving Advice • Do not install the cabinet close to sources of heat, such as a cooker, dishwasher or radiator. • Locate the appliance in a cool well-ventilated room and make sure that the air openings of the cabinet are not obstructed. • Avoid unnecessary frosting in the cabinet by packing all foodstuffs into airtight packages before placing them in the freezer. • Always leave warm food to cool down to room temperature before placing in the fridge or freezer.
Maintenance and Cleaning Before any maintenance or cleaning work is carried out DISCONNECT the appliance from the ELECTRICITY supply. External Cleaning Wash the outer cabinet with warm soapy water. Do not use abrasive products. There may be sharp edges on the underside of the product so care should be taken when cleaning. Ensure the vents at the back of the appliance are clear of dust and debris etc.
Something Not Working If your appliance is not operating correctly, carry out the following checks before contacting John Lewis Serviceplan. Important: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation a charge will be made, even if the appliance is under guarantee.
Normal Operating Sounds 1. Temperature control May cause clicking sounds when the system is connected or disconnected. 2. Cooling system The injected cooling gas may produce a gurgling sound while passing through the tubes. 3. Motor May cause a humming noise and or slight knocking sound. 4. Fan You may occasionally hear the fan working. This is normal; the fan help to ensure the air circulates more effectively.
Technical Specifications A distance of 56mm must exist between the appliance and the wall, to allow the door to be fully opened. The refrigeration system and the insulation of this appliance do not contain CFCs or HCFCs. Height (mm) 2000 Width (mm) 595 Depth (mm) 695 Power Supply 220-240V / 50Hz Total Power Absorbed 150W Energy Consumption kWh/year 395 kWh/day 1.08 Freezing Capacity (Kg/24hrs) 10 Gross Capacity (ltrs/cu.ft) Fridge 246/8.7 Freezer 130/4.6 Net Capacity (ltrs/cu.
Installation Unpacking Remove all transit packaging. Positioning rating plate The appliance should be located in a well-ventilated, dry room. To ensure correct operation the appliance should: • Not be exposed to direct sunlight. • Not be installed next to radiators, cookers or other sources of heat. • Only be installed in a location where the ambient temperature corresponds to the climate classification for which the appliance is designed. Fig.
Electrical Connection Any electrical work required to install this appliance must be carried out by a qualified electrician or competent person. This appliance must be earthed. The manufacturer declines any liability should these safety measures not be observed. Electrical Requirements Before switching on, make sure the electricity supply voltage is the same as that indicated on the appliance rating plate. The appliance is supplied with a 13 amp plug fitted.
Door reversal If you wish to change the opening direction of the doors, proceed as follows: B 1. Open the freezer door. Remove the plinth (A) at the bottom of the appliance, by pushing downwards and pulling outwards. (See fig 5) 2. Remove the hinge cover (B) in the plinth and reposition on the opposite side of the plinth. 3. Whilst supporting the lower door, use an 8mm nut driver to remove the 3 hinge retaining bolts and remove the lower hinge. A 4. Carefully lower the door off the central hinge. 5.
John Lewis partnership 171 Victoria Street London SW1E 5NN www.johnlewis.
