JLFFW175 JLFFIN175 Fridge-Freezer Instruction manual
Safety information It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant warnings. These warnings have been provided in the interest of safety.
. Make sure that you can come to the mains plug of the appliance. 4. Do not pull the mains cable. 5. If the power plug socket is loose, do not insert the power plug. There is a risk of electric shock or fire. 6. You must not operate the appliance without the lamp cover of interior lighting. • This appliance is heavy. Care should be taken when moving it. • Do not remove nor touch items from the freezer compartment if your hands are damp/wet, as this could cause skin abrasions or frost/freezer burns.
• The appliance must not be located close to radiators or cookers. • Make sure that the mains plug is accessible after the installation of the appliance. • Ice lollies can cause frost burns if consumed straight from the appliance. Care and cleaning • Before maintenance, switch off the appliance and disconnect the mains plug from the mains socket. • Do not clean the appliance with metal objects. • Do not use sharp objects to remove frost from the appliance. Use a plastic scraper.
Contents For the user For the installer Safety information 2 Product description 6 Operation Switching on Switching off Temperature regulation First use Cleaning the interior Technical data 16 Installation 16 16 16 17 18 18 18 18 19 Positioning Location Electrical Connection Permanent connection Rear spacers Levelling Removing the shelf holders Door reversibility 7 7 7 7 7 7 Daily use 8 Freezing fresh food 8 Repairs - after sales service Storage of frozen food 8 Environmental concerns Thawing
Product description 1 14 2 3 15 4 A 16 5 17 6 7 18 8 9 19 21 22 10 B 20 11 23 12 24 13 25 13. 14. 15. 16. 17. 18. 19. 20. 21. 22. 23. 24. 25. A - Refrigerator B - Freezer 1. Top 2. Light box and temperature regulator 3. Glass shelves 4. Bottle rack 5. Cooling surface 6. Glass shelf 7. Defrost water drain 8. Salad/vegetable drawer 9. Rating plate 10. Quick freeze drawer 11. Storing compartments 12.
Operation Switching on A medium setting is generally the most suitable. Insert the plug into the wall socket. Turn the Temperature regulator clockwise to a medium setting. However, the exact setting should be chosen keeping in mind that the temperature inside the appliance depends on: • room temperature • how often the door is opened • the quantity of food stored • the location of the appliance. Switching off To turn off the appliance, turn the Temperature regulator to the "O" position.
Daily use Small pieces may even be cooked still frozen, directly from the freezer: in this case, cooking will take longer. Freezing fresh food The freezer compartment is suitable for freezing fresh food and storing frozen and deep-frozen food for a long time. To freeze fresh foods it is not necessary to change the medium setting. However, for a faster freezing operation, turn the temperature regulator toward higher settings to obtain the maximum coldness.
The freezing baskets have a limit stop to prevent their accidental removal or falling out. At the time of its removal from the freezer, pull the basket towards yourself and, upon reaching the end point, remove the basket by tilting its front upwards. At the time of putting it back, slightly lift the front of the basket to insert it into the freezer. Once you are over the end points, push the baskets back in their position.
Helpful hints and tips • do cover or wrap the food, particularly if it has a strong flavour • position food so that air can circulate freely around it Normal Operating Sounds • You may hear a faint gurgling and a bubbling sound when the refrigerant is pumped through the coils or tubing. This is correct. • When the compressor is on, the refrigerant is being pumped around and you will hear a whirring sound and a pulsating noise from the compressor. This is correct.
• prepare food in small portions to enable it to be rapidly and completely frozen and to make it possible subsequently to thaw only the quantity required; • wrap up the food in aluminium foil or polythene and make sure that the packages are airtight; • do not allow fresh, unfrozen food to touch food which is already frozen, thus avoiding a rise in temperature of the latter; • lean foods store better and longer than fatty ones; salt reduces the storage life of food; • it is advisable to show the use by date
Many proprietary kitchen surface cleaners contain chemicals that can attack/damage the plastics used in this appliance. For this reason it is recommended that the outer casing of this appliance is only cleaned with warm water with a little washing-up liquid added. After cleaning, reconnect the equipment to the mains supply. Defrosting the freezer A certain amount of frost will always form on the freezer shelves and around the top compartment.
It is recommended to operate the appliance at the highest position of the thermostatic control for some hours so that it can reach the sufficient storing temperature as soon as possible. Important! Never use sharp metal tools to scrape off frost from the evaporator as you could damage it. Do not use a mechanical device or any artificial means to speed up the thawing process other than those recommended by the manufacturer.
Problem Possible cause Solution Products prevent that water flows Make sure that products do not into the water collector. touch the rear plate. Water flows on the ground. The melting water outlet does not Attach the melting water outlet to flow in the evaporative tray above the evaporative tray. the compressor. There is too much frost and ice. Products are not wrapped properly. Wrap the products better. The door is not closed correctly. Refer to "Closing the door".
2. Pull outwards the hook of the lamp cover. 3. Remove the lamp cover. 4. Replace the lamp with one of the same power (the maximum power is shown on the light bulb cover). 5. Install the lamp cover. 6. Tighten the screw to the lamp cover. 7. Connect the plug to the mains socket. 8. Open the door. Make sure that the light comes on. 1 2 3 Closing the door 1. Clean the door gaskets. 2. If necessary, adjust the door. Refer to "Installation". 3. If necessary, replace the defective door gaskets.
Technical data JLFFW175 JLFFIN175 Height 1750 mm 1750 mm Width 595 mm 595 mm Depth 632 mm 632 mm 20 h 20 h Dimension Rising Time The technical information are situated in the rating plate on the internal left side of the appliance and in the energy label. Installation Location Read the "Safety Information" carefully for your safety and correct operation of the appliance before installing the appliance.
100 mm min 1 B 20 mm A 2 5 3 4 Warning! It must be possible to disconnect the appliance from the mains power supply; the plug must therefore be easily accessible after installation. 1 Green and Yellow: Earth 3 Brown: Live 5 Blue: Neutral As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: 1.
The appliance is supplied with a 13 amp plug fitted 2 . In the event of having to change the fuse in the plug supplied, a 13 amp ASTA approved (BS 1362) fuse must be used. Warning! A cut off plug inserted into a 13 amp socket is a serious safety (shock) hazard. Ensure that it is disposed of safely.
m1 A m5 m2 m6 B m3 m4 C 2. 3. Door reversibility 4. Remove the doors. Remove the spacer (m6) and move to the other side of the hinge pivot (m5). Unscrew the lower hinge (b1) Warning! Before carrying out any operations, remove the plug from the power socket. Important! To carry out the following operations, we suggest that this be made with another person that will keep a firm hold on the doors of the appliance during the operations. To change the opening direction of the door, do these steps: 1.
8. 12. Re-insert the lower door on the lower hinge pivot (b2). 13. Fit the upper door on the upper hinge pivot (t1). 14. Re-insert the upper door on the middle hinge pivot (m5) slightly tilting both doors. 15. Re-screw the middle hinge (m2). Do not forget the plastic spacer (m1) inserted under the middle hinge. Make sure that the edges of the doors run parallel to the side edge of the appliance. 16. Reposition, level the appliance, wait for at least four hours and then connect it to the power socket.
They will give you details for your local Service engineer. Before calling out an engineer, please ensure you have read the details under the heading “Something not working”. When you contact your local service engineer you will need to give the following details: 1. Your name, address and post code 2. Your telephone number 3. Clear and concise details of fault 4. The purchase date as found on your receipt 5. The model and serial number of the appliance.
