TABLE 7: PHYSICAL DATA
MODEL
DYA
036 042 048 060
EVAPORATOR
BLOWER
CENTRIFUGAL BLOWER (Dia. x W. in.) 11 x 10 11 x 10 12 x 11 12 x 11
FAN MOTOR HP (3 Speed) 3/4 3/4 1 1
EVAPORATOR
COIL
ROWS DEEP 2 3 3 3
FINS PER INCH 15 13 13 13
FACE AREA (Sq. Ft.) 3.5 3.5 4.5 4.5
CONDENSER
FAN
PROPELLER DIA. (in.) 22222222
FAN MOTOR HP 1/4 1/4 1/4 1/4
NOM. CFM TOTAL 2,400 2,400 3,000 3,000
CONDENSER
COIL
ROWS DEEP 1 1 1 1
FINS PER INCH 20 20 20 20
FACE AREA (Sq. Ft.) 11.7 11.7 14.8 14.8
CHARGE REFRIGERANT 22 (lbs./oz.) 4 / 3 4 / 9 6 / 0 5 / 4
FILTER
1
FACE AREA (Sq. Ft.) Size (Nominal) 2.6/20x20 2.6/20x20 3.3/20x12 3.3/20x12
FURNACE
SECTION
NATURAL GAS BURNER ORIFICE NO.
(Drill Size)
43 43 40 40
PROPANE BURNER ORIFICE NO.
(Drill Size)
55 55 53 53
GAS CONNECTION SIZE
1/2
NPTI 1/2 NPTI 1/2 NPTI 1/2 NPTI
COMPRESSOR
TYPE
HERMETICALLY SEALED
(R = RECIPROCATING, S = SCROLL)
RRSS
1.
Three phase 036 thru 042 size units are supplied with one (1) filter and on three phase 048 and 060 size units two (2) filters are
supplied. See FILTERS on page 5.
TABLE 8: ELECTRICAL DATA
MODEL
DYA
POWER
SUPPLY
VOLTAGE
LIMITATIONS
1
COMPRESSOR
COND.
FAN
MOTOR,
FLA
SUPPLY
AIR
BLOWER
MOTOR
FLA
MINIMUM
CIRCUIT
AMPACITY
MAX.
FUSE
SIZE,
AMPS
2
MAX.
HACR
BREAKER
SIZE,
AMPS
UNIT
POWER
FACTOR
TRANSFORMER
SIZE (VA)
MIN. MAX. RLA LRA
036 208/230-3-60 187 253 10.9 78.0 1.1 3.5 18.2 25 25 .96 75
036 460-3-60 414 504 5.8 40.0 0.6 1.8 9.6 15 15 .96 75
042 208/230-3-60 187 253 11.5 88.0 1.1 3.5 19.0 25 25 .96 75
042 460-3-60 414 504 5.8 42.0 0.6 1.8 9.7 15 15 .96 75
048 208/230-3-60 187 253 14.1 105 1.3 7.0 25.9 35 35 .96 75
048 460-3-60 414 504 7.1 55.0 0.7 3.5 13.1 20 20 .96 75
060 208/230-3-60 187 253 15.5 125 1.3 7.0 29.5 40 40 .96 75
060 460-3-60 414 504 8.9 66.5 0.7 3.5 15.4 20 20 .96 75
1.
Utilization range “A” in accordance with ARI Standard 110.
2.
Dual element, time delay type.
