341426-BIM-A-0108
20 Johnson Controls Unitary Products
TABLE 14: SUPERHEAT CHARGING TABLE FOR DYA042
OUTDOOR
TEMP. °F
SUPERHEAT AT COMPRESSOR SUCTION (F), AIRFLOW = 400 CFM
INDOOR WB TEMP. (°F)
55 57 59 61 63 65 67 69 71 73 75
65 18.0 19.7 21.4 23.0 24.7 26.3 28.0 29.1 30.2 31.3 32.4
70 13.4 15.3 17.3 19.3 21.2 23.2 25.2 26.6 28.1 29.6 31.1
75 8.7 10.9 13.2 15.5 17.8 20.0 22.3 24.2 26.1 28.0 29.9
80 - 6.6 9.1 11.7 14.3 16.9 19.5 21.7 24.0 26.3 28.6
85 - - 5.1 7.9 10.8 13.7 16.6 19.3 21.9 24.6 27.3
90 - - - 6.7 9.3 11.9 14.6 17.4 20.2 23.1 25.9
95 - - - 5.5 7.8 10.2 12.5 15.5 18.5 21.5 24.5
100 ----6.38.09.812.916.119.222.4
105 -----5.97.110.313.716.920.3
110 -------7.811.214.718.1
115 -------5.28.812.416.0
TABLE 15: SUPERHEAT CHARGING TABLE FOR DYA048
OUTDOOR
TEMP. °F
SUPERHEAT AT COMPRESSOR SUCTION (F), AIRFLOW = 400 CFM
INDOOR WB TEMP. (°F)
55 57 59 61 63 65 67 69 71 73 75
65 20.9 21.8 22.7 23.6 24.4 25.3 26.2 27.4 28.6 29.8 31.0
70 17.6 18.7 19.7 20.7 21.7 22.7 23.7 25.2 26.6 28.1 29.6
75 14.4 15.5 16.6 17.8 18.9 20.0 21.2 22.9 24.7 26.4 28.2
80 11.1 12.4 13.6 14.9 16.1 17.4 18.6 20.7 22.7 24.8 26.8
85 7.8 9.2 10.6 12.0 13.3 14.7 16.1 18.4 20.8 23.1 25.4
90 5.8 7.0 8.2 9.3 10.5 11.7 12.9 15.7 18.6 21.5 24.4
95 - - 5.8 6.7 7.7 8.6 9.6 13.0 16.5 19.9 23.3
100 - - 5.4 6.0 6.7 7.4 8.0 11.6 15.2 18.7 22.3
105 - - - 5.3 5.7 6.1 6.5 10.2 13.9 17.6 21.3
110 -------8.712.616.420.3
115 -------7.311.315.319.3
TABLE 16: SUPERHEAT CHARGING TABLE FOR DYA060
OUTDOOR
TEMP. °F
SUPERHEAT AT COMPRESSOR SUCTION (F), AIRFLOW = 400 CFM
INDOOR WB TEMP. (°F)
55 57 59 61 63 65 67 69 71 73 75
65 7.0 9.2 11.4 13.6 15.9 18.1 20.3 21.8 23.2 24.7 26.1
70 6.1 8.4 10.7 13.0 15.2 17.5 19.8 21.2 22.7 24.1 25.6
75 5.3 7.6 9.9 12.3 14.6 16.9 19.3 20.7 22.2 23.6 25.0
80 - 6.8 9.2 11.6 14.0 16.3 18.7 20.2 21.6 23.1 24.5
85 - 6.0 8.4 10.9 13.3 15.8 18.2 19.6 21.1 22.5 23.9
90 - - 6.5 8.7 10.8 12.9 15.1 17.1 19.1 21.1 23.1
95 - - - 6.5 8.3 10.1 11.9 14.5 17.1 19.7 22.3
100 - - - 5.9 7.3 8.6 10.0 12.9 15.8 18.7 21.6
105 - - - 5.3 6.2 7.1 8.0 11.3 14.5 17.7 20.9
110 ----5.25.66.19.613.216.720.2
115 -------8.011.815.719.6
