Installation Guide
Table Of Contents
- Applications
- North American Emissions Compliance
- United States
- Canada
- Installation
- Parts included
- Dimensions
- Accessories
- General precautions
- Setup and adjustments
- Installing the Johnson Controls Vibration Diagnostics Service mobile application on your mobile device
- Assembling the hardware
- Operation
- Recording
- Charging
- Using other sensors
- Maintenance
- Cleaning
- Storing
- Troubleshooting
- Depleted battery
- Repair information
- Technical specifications
- Johnson Controls Vibration Diagnostics Service
Johnson Controls Vibration Diagnostics Service Installation Guide
2
Canada
Installation
Parts included
• WVS-1000 DAQ
• Tri-axial accelerometer
• Sensor cable
• Sensor magnet
• WVS-1000 holster
• Protective carrying case
Dimensions
The WVS-1000 DAQ is 75 mm x 120 mm x 25 mm.
Accessories
You can purchase an adapter that allows you to collect vibration data from a single axis vibration sensor via a BNC
connector. This adapter plugs into the tri-axial sensor cable and converts the M-12 connector to a male BNC. This
is useful when collecting data from permanently mounted sensors or online systems.
Industry Canada Statement(s)
The term IC before the certification/registration number only signifies that the Industry Canada technical
specifications were met.
This device has been designed to operate with an antenna having a maximum gain of 0.5 dBi. Antenna having a
higher gain is strictly prohibited per regulations of Industry Canada. The required antenna impedance is 50
ohms.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the
Equivalent Isotropically Radiated Power (EIRP) is not more than that required for successful communication.
Le terme « IC » précédant le numéro d'accréditation/inscription signifie simplement que le produit est conforme
aux spécifications techniques d'Industry Canada.
Cet appareil a été conçu pour fonctionner avec une antenne d'un gain maximum de 0.5 dBi. En application des
réglementations d'Industry Canada, l'utilisation d'une antenne de gain supérieur est strictement interdite.
L'impédance d'antenne requise est de 50 ohms.
Pour réduire les interférences radio potentielles avec les dispositifs d'autres utilisateurs, le type d'antenne et son
gain doivent être choisis de façon à ce que la Puissance Isotrope Rayonnée Équivalente (PIRE) ne soit pas
supérieure à la puissance nécessaire pour une bonne communication.
