8 Configuration level
2013-04-01
98
8.5 Analog output
Parameter Comment
Value range
(factory setting in bold)
8.5.1 Function
Here, the measured value that is to be shown at the
analog output is set.
Main measured value
Measured value1
Measured value2
Difference
Main measured value:
With the max. alarm switching behavior, the greater of
the two measured values is shown; with the min. alarm,
the lower of the two measured values is shown.
Measured value1:
Measured value of analog input 1 (E1) is shown
Measured value2:
Measured value of analog input 2 (E2) is shown
Difference:
E1-E2 is shown
The signal that should be output by the analog output
can be set with scaling start and end.
8.5.2 Signal type
4to20mA 4to20mA
0to20mA
2to10V
0to10V
0to20mA
2to10V
0to10V
8.5.3 Scaling start
v
Figure in Chapter 8.5.6 -9999 to -200 to +9999
8.5.4 Scaling end
v
Figure in Chapter 8.5.6 -9999 to 800 to +9999
