9 Technical data
109
2013-04-01
9.10 Case
EMC According to DIN EN 14597 and standards from the standard series DIN EN 61326
Interference emission Class B
Interference immunity Evaluation criteria FS according to DIN EN 14597, regulation and control devices (RS)
1. All specifications refer to the measuring range end value
Material Polycarbonate
Flammability class UL 94 V0
Electrical connection On the front via screw terminals up to max. 2.5 mm
2
Maximum tightening torque of the screws: 0.5 Nm
Mounting On 35 mm DIN rail according to DIN EN 60715
Installation position Any
Weight Approx. 230 g
Protection type IP20 according to DIN EN 60529
