8 Configuration level
2013-04-01
88
k Factory setting
8.2.2 Probe type 1
For analog input1
Comment
Setting range for limit
value:
(can be restricted via
the setup)
Limits for
underrange/
overrange
Pt100 DIN EN 60751 In 3-wire circuit -1999 to +9999 °C -205 °C / +855 °C
Pt1000 DIN EN 60751 In 3-wire circuit -1999 to +9999 °C
-205 °C / +855 °C
Pt100 DIN EN 60751 In 2-wire circuit -1999 to +9999 °C
-205 °C / +855 °C
Pt1000 DIN EN 60751 In 2-wire circuit -1999 to +9999 °C
-205 °C / +855 °C
W3Re-W25Re "D" Thermocouple -1999 to +9999 °C -5 to +2500 °C
Cu-CuNi "T" Thermocouple DIN EN 60584 -1999 to +9999 °C -205 to +405 °C
Fe-CuNi "J" Thermocouple DIN EN 60584 -1999 to +9999 °C -205 to +1205 °C
Cu-CuNi "U" Thermocouple DIN 43710 -1999 to +9999 °C -205 to +605 °C
Fe-CuNi "L" Thermocouple DIN 43710 -1999 to +9999 °C -205 to +905 °C
NiCr-Ni "K" Thermocouple DIN EN 60584 -1999 to +9999 °C -205 to +1377 °C
Pt10Rh-Pt "S" Thermocouple DIN EN 60584 -1999 to +9999 °C -5 to +1773 °C
Pt13Rh-Pt "R" Thermocouple DIN EN 60584 -1999 to +9999 °C -5 to +1773 °C
Pt30Rh-Pt6Rh "B" Thermocouple DIN EN 60584 -1999 to +9999 °C 295 to 1825 °C
NiCrSi-NiSi "N" Thermocouple DIN EN 60584 -1999 to +9999 °C -105 to +1305 °C
4to20mA
Standard signal
-1999 to +9999 °C 3.6 to 21 mA
