Monoblock Klimagerät EC 10 Climatiseur Monobloc EC 10 Aria condizionata Monobloc EC 10 Y.
1.GENERAL INFORMATION ENGLISH 1.3 RECEIVING THE GOODS P0 The air conditioner is delivered in a protective packaging and is accompained by an instruction manual. This manual is an integral part of the air conditioner and should therefore be carefully read and preserved. When the air conditioner is unpacked, please check that the air conditioner and accessory packed are complete and undamaged. 1 4 3 2 5 12 1.4 HANDLING Be fully aware of the weight of the air conditioner before attempting to lift it.
EC 10 2971 2874 932 850+2000 3.7+8.
spirit level P3 Outdoor Indoor 2m 2m P4
26mm O 52mm 455mm FRESH AIR HOLE ( OPTIONAL )
P13 FRESH AIR HOLE - For the fresh air hole, the diameter would be 52mm. It is optional for the customer. 3° INCLINATION A B Soft terminal P5 Hard terminal A B System "A" is more common use , and the discharge pipe go outside where there is no problem to connect or to discharge it , this solution is OK for hot country and normal cold temperature out side .
2.INSTALLATION ENGLISH 2.5 INSTALLATION OF THE PIPES (P20) System “B”: in case of impossibility to install the drainage pipa as showed on “A” system, please use system “B” to drain the condensate moisture to a suitable place. If use system “B”, please do not unplug the black rubber cup from system “A”. Usually “B” hole is used in the installation when the outside temperature is very low, and in this way we prevent no ice in the discharge water pipe.
P9 P10 P7 P8
P14 P11 LIFT IT UP HERE LIFT IT UP HERE Water Water cap P12
Press the ON/OFF button " ",switch on the air conditioner, it will run by memory mode. Press the MODE button " " set up the mode to fan " ", the air conditioner will run in fan. Press UP " " or DOWN " " button, to adjust the setting up temperature. Press the FAN SPEED button " ", set up the fan speed. is low speed, is middle speed, is high speed, (flashing) is auto speed. Fan auto fan, the speed is choosen by the difference of room temperature and setting temperature.
Fresh air pipe O 50 Fresh air filter There is fresh air system in the back of the unit . On the wall , the fresh air pipe would be 50mm accordingly . The air conditioner will change the room air automatically , in this way new clean and fresh air will intake to the room . Same time , the air conditioner performance would be lower . The filter should be cleaned regularly to keep the fresh air flow smoothly .
P16 P18 P17 P19 P15 LIFT IT UP HERE LIFT IT UP HERE
POSITION OF ELECTRIC HEATER POSSIBLE SOLUTIONS 1. Wrong setting of the timer/ Check it . 2 . Problems on the power supply / Call the service center . 3 . The filter could be dirty/ Clean it . 4 . The room temperature is too high / Wait unit the temperature goes down . 5 . The temperature is not properly set / Check it . 6 . The grids could be obstructed / Check and remove the eventual obstacles .
