Operation Manual

POSITION OF ELECTRIC HEATER
There are two electric heaters on both
sides of unit, and they would be controlled
by remote control or on board control.
As the arrow direction, the inlet grille
would be removed, and the filters would
be taken out.
For filters cleaning, please refer to
3. 15 MAINTENANCE " FILTER CLEANING"
ATTENTION:
Do not cover the electric heater during the
working.
The distance between electric heater and
wooden furniture or other inflammable
things should be more than 1m.
3. 16 PROBLEM SOLVING
PROBLEM POSSIBLE CAUSES
- The air conditioner does not work.
- The air conditioner does not refrigerate
the room.
- Strange smell in the room. Water drips
from the air conditioner.
- The remote control control does not work.
- The air conditioner does not work for 3
minutes when switched on.
POSSIBLE SOLUTIONS
1. Wrong setting of the timer/ Check it.
2. Problems on the power supply / Call the
service center.
3. The filter could be dirty/ Clean it.
4. The room temperature is too high / Wait
unit the temperature goes down.
5. The temperature is not properly set /
Check it.
6. The grids could be obstructed / Check
and remove the eventual obstacles.
-- Dampness in the room, coming from walls,
carpets, furnishing or similar
-- Wrong installation of the air conditioner.
-- Wrong connection of the drainage pipe.
-- Exhausted batteries.
-- Wrong insertion of the batteries inside the
remote control.
-- Protection of the air conditioner. Wait for
3 minutes and the airconditioner will start to
work again.
