COLOUR TELEVISION MODEL WITH THE TELETEXT FUNCTION AV-1414FE AV-2114YE MODEL WITHOUT THE TELETEXT FUNCTION AV-1403AE AV-1403FE AV-1404AE AV-1404FE AV-14F14 AV-2103CE AV-2103DE AV-2103QE AV-2103TE AV-2104CE AV-2104DE AV-2104QE AV-2104TE AV-2104YE AV-21C14 AV-21E14 AV-21F14 Contents Knowing your TV’s features .......................... 2 Remote control buttons and basic functions . 3 TV buttons and functions .............................. 5 Setting up your TV ........................................
Thank you for buying this JVC colour television. To make sure you understand how to use your new TV, please read this manual throughly before you begin. Safety Instructions WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO ENSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES REGARDING THE USE OF THIS TV. 1 Operate only from the power source indicated on the rear of the TV. 2 Avoid damaging the power cord and mains plug.
Remote control buttons and basic functions 1 1 8 3 6 6 9 7 2 9 0 4 5 RM-C1260 WITH THE TELETEXT FUNCTION (AV-1414FE/AV-2114YE) 8 0 2 3 7 5 4 RM-C1261 WITHOUT THE TELETEXT FUNCTION (AV-1403AE/AV-1403FE/AV-1404AE/ AV-1404FE/AV-14F14/AV-2103CE/ AV-2103DE/AV-2103QE/AV-2103TE/ AV-2104CE/AV-2104DE/AV-2104QE/ AV-2104TE/AV-2104YE/AV-21C14/ AV-21E14/AV-21F14) No.
Remote control buttons and basic functions How to operate menus and menu locations TO Display the MENU. Operation Press the MENU/OK button 2. Display the top menu. Press 5/∞ buttons 3 to choose a menu title. Then press MENU/OK button 2. Display the 2nd menu. Press 5/∞ buttons 3 to choose a menu title. Then press MENU/OK button 2. Display the 3rd menu. Press 5/∞ buttons 3 to choose a menu title. Then press MENU/OK button 2. Return to the previous Press the DISPLAY button 8. menu.
TV buttons and functions The following illustrations are for AV-1404FE and AV-1403AE only, which are used for explanation purpose. Your TV may not look exactly like the illustrated. Front of the TV 9 8 7 6 5 4 32 1 AV-1404FE VIDEO AUDIO IN (VIDEO-2) 9 8 MENU OK 7 6 5 MENU CHANNEL VOLUME 4 2 1 VIDEO AUDIO IN (VIDEO-2) AV-1403AE OK Rear of the TV AV-1404FE VIDEO-1 INPUT AV-1403AE OUTPUT VIDEO-1 INPUT OUTPUT VIDEO VIDEO AUDIO AUDIO =No.
Setting up your TV CAUTION • Turn off the equipment including the TV before connecting. 1 Connecting the aerial To install rod aerial Install into the top-rear aerial holder. Once installed, it cannot be removed. indoor aerial * For model 14” series only VHF/UHF outdoor aerial Rod aerial* Aerial holder Rear of the TV VIDEO-1 INPUT OUTPUT VIDEO AUDIO If you connect a VCR, connect the aerial output jack of your VCR and the aerial jack on the TV with the aerial cable.
Setting up your TV (continued) 5 Making the initial settings Set up your TV by pressing any buttons except POWER button, then operate the TV menu by following the steps as below: LANGUAGE ENGLISH êìëëäàâ ìäê 7 • Press 5/∞ button to select your desired language*, then press MENU/OK button. ≠ TEXT LANGUAGE • Press the red button to cancel the SETUP TOUR RESTART function.
Basic setting for picture COLOUR SYSTEM You can select the appropriate colour system when the picture is not clear or no colour appears. Press the COLOUR SYSTEM button to select a setting. In TV mode: AUTO PAL SECAM In VIDEO mode: AUTO PAL SECAM NTSC4.43 NTSC3.
Advance setting for picture ❇ MENU BLUE BACK You can set the TV to automatically change to a blue screen and mute the sound if the signal is weak or absent, or when there is no input from an antenna. Select the BLUE BACK in the INSTALL menu, then choose ON or OFF. INSTALL BLUE BACK If you wish to continue viewing the poor picture, cancel the BLUE BACK function. Original features for picture 2 Press a colour button, then press the number buttons to enter the page number.
Basic setting for sound SOUND SYSTEM You can select an appropriate sound system when abnormal sound occurs even when the picture appears normally. Press the SOUND SYSTEM button to select a setting. B/G I D/K The function is not available in video mode. For the sound system in each country or region, see the table below: Area Asia, Middle East Europe Oceania Africa Country or Region Bahrain, Kuwait, Oman, Qatar, United Arab Emirates, Yemen, etc. Indonesia, Malaysia, Singapore, Thailand, India, etc.
Favorite channel and video setting To register the favorite channel You can register and recall 4 favorite channels by using the colour buttons (red, green, yellow, blue). 1 In TV mode, select a TV channel (PR01- 99) you desired to register. 2 Press and hold a colour button for 3 seconds or more. “FAVORITE CHANNEL 7 PROGRAMMED!” appears on the screen and current channel is registered. 3 To register other favorite channels, repeat Step 1 to 2. To recall the favorite channel, press the colour button.
Customized setting VNR You can reduce the noise. Select the VNR in the PICTURE FEATURES menu under PICTURE menu, then choose a setting of VNR function. ❇ MENU VNR OFF AUTO MIN MAX PICTURE PICTURE FEATURES VNR is turned off. Effect of VNR is automatically controlled. Effect of VNR becomes minimum level. Effect of VNR becomes maximum level. If you select MAX, the picture becomes softer even if the original picture is sharp. LANGUAGE You can choose your desired on screen display language.
TV channel presetting To register the TV channels automatically You can register the TV channels into the TV’s channel list automatically. 1 Display the INSTALL menu. INSTALL ❇ MENU 2 Choose AUTO PROGRAM, then press the MENU/OK button. AUTO PROGRAM function starts, and the channels received are registered in the channel list (PR list) automatically. 3 “SETUP TOUR RESTART?” appears. To start the SETUP TOUR To skip the SETUP TOUR Press the MENU/OK button.
TV channel presetting To add in the new channel (INSERT in the EDIT menu) You can add in the new channel in the TV channel list as you like. You need to find the “CH/CC” number for the TV channel. Find the “CH/CC” number corresponding to the channel number of the TV channel from the attached sheet “CH/CC number list” on this page. 1 Display the INSTALL menu. INSTALL ❇ MENU 2 Choose EDIT/ MANUAL, then press the MENU/OK button. EDIT menu appears.
Additional preparation The illustrations shown in this section are for AV-1404FE only, which are used for explanation purpose. Your TV may not look exactly the same as illustrated. Before connecting Front of the TV • Read the manuals provided with the devices Camcorder or TV game for the proper connection. • Turn off all the devices including the TV. • Note that connecting cables are not supplied.
Specifications TV RF systems B/G, I, D/K Colour systems TV mode: PAL, SECAM VIDEO mode: PAL, SECAM, NTSC 3.58 MHz, NTSC 4.43 MHz Receiving channels VHF low channel (VL), VHF high channel (VH), UHF channel (U) Receives cable channels in mid band, super band and hyper band. Power requirements AC 110 to 240 V, 50/60 Hz External input / output VIDEO-1: VIDEO-2: OUTPUT: Headphone jack: VIDEO input, AUDIO input VIDEO input, AUDIO input, VIDEO output, AUDIO output stereo mini jack (3.
