Contents COLOR TELEVISION INSTRUCTIONS Thank you for buying this JVC color television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin. Safety precautions Preparation 2 3 1 Confirm which remote control you have ... 2 Insert the batteries into the remote control ... 3 Connecting the antenna and VCR ............. 4 Connecting other devices .......................... 5 Connect the power cord to the AC outlet ... 6 Initial setting ....................
Safety precautions WARNING • To prevent fire or shock hazard, do not expose the TV to rain or moisture. CAUTION • Operate only from the power source indicated on the rear of the TV. • Avoid damaging the power cord and mains plug. When you unplug the TV, pull it out by the mains plug. Do not pull on the power cord. • Never block or cover the cabinet openings for ventilation. Never install the TV where good 15 cm ventilation is unattainable.
Preparation 1 Confirm which remote control you have Your TV comes with one of the two remote controls shown below. Functions you can operate differ depending on the type of remote control.
Preparation 3 Connecting the antenna and VCR • Read the manuals provided with the devices. Depending on the device, the connection method may be different from the diagrams. Also the device settings may need to change depending on the connection method. • Turn off all the devices including the TV. • Connecting cables are not supplied. • When connecting monaural audio to the TV, use the L/MONO jack.
Preparation 4 Connecting other devices If you are not connecting any other devices, skip step 4 and perform step 5. • Use the headphones with a stereo mini jack (3.5 mm in diameter). When you connect the headphones, the TV speakers go off. • The OUTPUT terminal outputs the video and sound signals which you are viewing on the TV. You can dub them onto the VCR connected to the OUTPUT terminal. (The OUTPUT terminal cannot output component video signals.
Preparation 6 Initial setting When the TV is first turned on, it enters the initial setting mode, and the JVC logo is displayed. Follow the instructions on the on-screen display to perform the initial settings. 1 Press the Main power button on the TV. The POWER lamp lights. After the JVC logo has been displayed, the TV automatically switches to the auto program mode.
Basic operation • The illustration below is for the remote control RM-C248 supplied with AV-29L31. Your remote control may not look exactly like the illustrations. POWER DISPLAY 1 Press the POWER button to turn your TV on. • If your TV does not turn on, press the Main power button on the TV then press the POWER button again. • You can also turn on your TV by pressing any of the following buttons; - the CHANNEL m button - the TV/VIDEO button 2 Select a channel. MENU ■ Press the CHANNEL m button.
Remote control buttons and functions ECO SENSOR button CLOSED CAPTION button You can adjust this TV so that the screen automatically adjusts to the optimum contrast according to the brightness of your room. This function reduces eye strain and the power consumption of this TV. If they are included in a program, you can view closed captions or text information. Press this button to select the desired mode. DIGITAL ECO SENSOR DISPLAY: The ECO SENSOR function switches on.
Remote control buttons and functions DISPLAY button RETURN + button You can continuously display the current channel number or VIDEO mode on the screen. You can set a channel you frequently view to the Return Channel and you can view that channel at any time with one-touch. Press this button. To set the channel to the Return Channel: To turn the display off, press this button again. • When selecting a VIDEO mode with no signal, indication of the VIDEO mode becomes fixed on the screen.
Using the TV’s menus This TV has a number of functions you can operate using the menus. To use all your TV’s functions fully, you need to understand how to use the menus. 4 Press the MENU M buttons to change function settings. DISPLAY button Example: POWER DISPLAY MENU t buttons MENU MENU m buttons CHANNEL Changes the AUTO SHUTOFF setting.
Using the TV’s menus INPUT VNR You can view images from VCRs or other devices connected to your TV. You can reduce picture noise. 1 Press MENU T to display the “MENU 1” menu, then select “INPUT”. MENU 1 TV ON ON 00 INPUT VNR COMPRESS(16:9) PICTURE TILT SELECT BY OPERATE BY -+ 1 Press MENU T to display the “MENU 1” menu, then select “VNR”. MENU INPUT VNR COMPRESS(16:9) PICTURE TILT SELECT BY OPERATE BY -+ EXIT BY DISPLAY 2 Press MENU M to select the “VIDEO-1”, “VIDEO-2” or “VIDEO-3”.
Using the TV’s menus AUTO SHUTOFF BLUE BACK You can set your TV to turn off if no signals are received for about 15 minutes or longer after the end of a broadcast. You can mute the sound and change the picture into a blue screen while no signals are received by the TV, or when the signals are unstable. 1 Press MENU T to display the “MENU 2” menu, then select “AUTO SHUTOFF”.
Using the TV’s menus VIDEO-2 SET AUTO CH PRESET Set the VIDEO-2 SET correctly according to the video signal input from the external device connected to the VIDEO-2 terminal. If this setting is incorrect, images will not be displayed. You can automatically preset all TV channels that can be received by your TV to channels. 1 Press MENU T to display the “MENU 2” menu, then select “VIDEO-2 SET”.
Using the TV’s menus CHANNEL SKIP MTS You can set undesired channels to be skipped. Channels set to be skipped cannot be selected by the CHANNEL m buttons nor the CHANNEL SCAN button. You can select a MTS (Multi-Channel Television Sound) setting for stereo, mono and SAP (Second Audio Programs). 1 Press MENU T to display the “MENU 3” menu, then select “CHANNEL SKIP”.
Using the TV’s menus Picture Adjustments AI VOLUME You can adjust the picture as you like. You can prevent the sudden increase or decrease of volume that occurs when changing channels or switching VIDEO modes. 1 Press MENU T to display the “MENU 4” menu. MENU 4 1 Press MENU T to display the “MENU 5” menu, then select “AI VOLUME”. TINT COLOR BRIGHT PICTURE DETAIL SELECT BY OPERATE BY -+ EXIT BY DISPLAY 2 Press MENU T to select an item and press MENU M to adjust it.
Attaching the Twin Port Bass Blaster Unit The Twin Port Bass Blaster Unit is packaged together with the TV. Before you use the TV, mount the Twin Port Bass Blaster Unit correctly on the TV. Note: • The BASS functions do not work unless the Twin Port Bass Blaster Unit is connected correctly to the TV. For details on the BASS functions, see page 8. CAUTION: • The Twin Port Bass Blaster Unit is just placed on top of the TV and is not held in place by a screw.
TV buttons and parts Front 1 2 V 3 4 L/MONO 5 6 R IN (VIDEO-3) 7 8 7 8 1 1 2 3 4 2 3 4 Headphone jack VIDEO-3 terminal MENU button CHANNEL m buttons 5 5 6 7 8 VOLUME m buttons TV/VIDEO button POWER lamp Main power button Rear VIDEO-1 INPUT COMPONENT (VIDEO-2) INPUT OUTPUT Y /V V L / MONO C B L / MONO L R R V CR 1 2 1 VIDEO-1 INPUT terminal 2 COMPONENT (VIDEO-2) INPUT terminal 3 OUTPUT terminal 4 Antenna socket R 3 4 17 LCT1118-001
Using the buttons on the TV Basic operation Operating menus • Check to make sure the CHILD LOCK function is set to “OFF”. When the CHILD LOCK function is set to “ON”, the TV cannot be operated using the front control buttons. For details, see “CHILD LOCK” on page 12. You can operate functions in menus using the front control buttons on the TV. 1 Press CHANNEL M to turn the TV on from standby mode. 2 Press MENU y repeatedly to display the menu you want to use. 2 Press CHANNEL M to select a channel.
Troubleshooting If there is no picture or the TV does not operate normally, make sure the problem isn’t due to the reasons indicated below. If the problem persists even after taking the measures indicated, please contact a service technician. Cannot turn the TV on Poor picture • Press the Main power button on the TV. • Connect the power cord to the AC outlet. • Adjust the picture settings. (see page 15.) • Is a component signal output device, such as a DVD player, connected correctly? (see page 5.
Specifications TV RF systems M Colour systems NTSC Channels VHF 2 to 13, VHF 14 to 69 Sub Mid, Super, Hyper and Ultra bands. External input / output VIDEO-1: VIDEO input, AUDIO L/R input VIDEO-2/COMPONENT: VIDEO input, AUDIO L/R input, COMPONENT VIDEO (Y/CB/CR) input VIDEO-3: VIDEO input, AUDIO L/R input OUTPUT: VIDEO output , AUDIO L/R output Headphone jack: stereo mini jack (3.5 mm diameter) Sound-multiplex systems BTSC (Multi Channel Sound) Design and specifications subject to change without notice.
規格 電視RF制式 M 彩色制式 NTSC 頻道 VHF 2至13, VHF14至69 副中頻、高頻、超高頻和極高頻頻道 外接輸入 輸出 VIDEO-1: VIDEO 輸入, AUDIO L/R 輸入 VIDEO-2/COMPONENT: VIDEO 輸入, AUDIO L/R 輸入, COMPONENT VIDEO (Y/CB/CR) 輸入 VIDEO-3: VIDEO 輸入, AUDIO L/R 輸入 OUTPUT: VIDEO 輸出 , AUDIO L/R 輸出 耳機插口: 立體聲微型插口(直徑3.5毫米) 聲音多重制式 BTSC(多頻道音響) 目錄 彩色電視機 使用說明書 感謝惠購JVC彩色電視機。 請在使用電視機前通讀本說明書,以便 掌握新電視機的使用方法。 安全須知 準備 1 2 3 4 5 6 確認遙控器的種類 ....................... 3 將電池裝入遙控器 ....................... 3 連接天線和錄像機 ...................... 4 連接其他裝置 ..........................
安全須知 警告 • 為了防止火災或觸電的危險,請勿將電視機暴露於雨中或放在潮濕之處。 注意 • 僅在電視機背面所示的電源規格內操作使用。 • 請勿損傷電源線和主插頭。撥下插頭時應拿著主插頭撥出而不要拉電源線。 • 切勿擋住或蓋住用於通風的開放縫隙。切勿 將電視機安裝在通風不良之處。安裝電視機 15 cm 時,請在電視機周圍留出不小於圖示的最小 距離的空間,以便通風。 • 請勿讓物體或液體進入電視機的開放縫隙 中。 10 cm 15 cm 10 cm • 電視機發生故障時,請撥下電源插頭,並請 維修服務人員修理。請勿自行維修或打開後蓋。 • 電視機屏幕的表面容易損壞。使用電視機時請十分小心。當電視機屏幕髒污時,請用柔軟 的乾布擦拭。切勿用力擦。切勿使用任何清潔劑或去污劑。 • 當長期不使用電視機時,請務必撥下插頭。 <僅適用於AV-21L31B> 與電視機一起裝有TWIN PORT BASS BLASTER(雙端口低音發音器裝置)。使用電視機 之前,請將TWIN PORT BASS BLASTER裝置正確地安裝在電視機上。 2
準備 1 確認遙控器的種類 本電視機帶有下列兩種遙控器之一。可使用的功能因遙控器的種類不同而不同。 RM-C248 RM-C249 POWER DISPLAY POWER DISPLAY MENU MENU BASS CHANNEL VOLUME CLOSED CAPTION CHANNEL MUTING CLOSED CAPTION TV/VIDEO 1 2 3 4 5 6 7 8 9 CHANNEL SCAN RETURN 0 TV/VIDEO PICTURE MODE ECO SENSOR 100 OFF TIMER RM-C248 REMOTE CONTROL UNIT VOLUME MUTING 1 2 4 5 6 7 8 9 CHANNEL SCAN RETURN 0 PICTURE MODE ECO SENSOR 3 100 OFF TIMER RM-C249 REMOTE CONTROL UNIT 2 將電池裝入遙控器 正確插入兩節電池,注意正,極和負.極,先插入負.
準備 3 連接天線和錄像機 • 請閱讀裝置附帶的使用說明書。有的裝置的連接方法可能不同於圖示方法。而且裝置的設定也可 能因連接方法而異。 • 關閉電視機在內的所有裝置。 • 不提供連接電纜。 • 將單聲道音頻裝置與電視機相連接時,請使用L/MONO插口。 連接天線 VIDEO-1 INPUT V COMPONENT (VIDEO-2) INPUT VHF/UHF OUTPUT Y /V V L / MONO C B L / MONO L R CR R R 接天線和錄像機 VHF/UHF VIDEO-1 INPUT V 3 OUTPUT Y /V V L / MONO C B L / MONO L R R RF 1 4 COMPONENT (VIDEO-2) INPUT CR R 2
準備 4 連接其他裝置 如果不需連接任何其他裝置時,請跳過步驟4,執行步驟5。 • 請使用帶立體聲微型插口(直徑3.
準備 6 初始設定 首次打開電視機時,將進入初始設定模式,並出現JVC標志。 請按照屏幕上顯示的說明,進行初始設定。 1 按下電視機上的主電源按鈕。 POWER指示燈發出。顯示JVC標志 後,電視機自動切換為語種設定模 式。 POWER MENU 3 AUTO CH PRESET CHANNEL SKIP CLOSED CAPTION MTS STEREO SAP MONO ON AIR SELECT BY OPERATE BY -+ DISPLAY POWER DISPLAY MENU t MENU MENU m EXIT BY DISPLAY CHANNEL VOLUME • 如果以前已打開過電視機,則不會顯示JVC 標志。此時,請利用自動頻道預置功能,進 行初始設定。詳細說明,請參照第13頁。 2 按下 MENU M 按鈕。 顯示子菜單。 TUNER MODE:CABLE AIR START SELECT BY OPERATE BY -+ EXIT BY DISPLAY 3 按下MENU M 按鈕,選擇“CABLE”或“AIR”。 4 按下MENU T按鈕,選擇“STAR
基本操作 • 下圖是AV-29L31所附帶的遙控器RM-C248。 您使用的遙控器可能不完全如圖所示。 1 按下 POWER 按鈕,打開電視機。 • 如果電視機未打開,請按下電視機上的主電源 按鈕,然後再次按下POWER按鈕。 • 也可透過按下下列任一按鈕來打開電視機; - CHANNEL m 按鈕 - TV/VIDEO按鈕 POWER DISPLAY 2 選擇頻道。 ■ 按下 CHANNEL m 按鈕。 • 對於頻道跳越已設為“YES”的頻道,不 能用上下選擇功能進行選擇。請參照第14 頁。 MENU ■ 按下數字按鈕,輸入頻道號。 CHANNEL VOLUME CLOSED CAPTION • 當要選擇大於100的頻道時,請按下100+ 按鈕後,輸入兩位數。 MUTING 1 2 3 4 5 6 7 8 9 CHANNEL SCAN RETURN 0 TV/VIDEO PICTURE MODE ECO SENSOR 100 OFF TIMER 3 按下 VOLUME M 按鈕,調節聲 音。 4 按下 POWER 按鈕,關閉電視機。 • 長期不使用電視機
遙控器按鈕和功能 ECO SENSOR(ECO電子眼)按鈕 CLOSED CAPTION(封閉字幕)按鈕 可調節本電視機,使屏幕自動根據室內的明 亮程度調節至最佳對比度。此功能減少眼睛 緊張和電視機的電力消費。 如果節目中有封閉字幕,可觀看封閉字幕或 文字資訊。 請按下此按鈕,選擇所需模式。 DIGITAL ECO SENSOR DISPLAY: 打開ECO SENSOR功能。在此模式時,每當 室內的明亮程度發生變化時,都會顯示幾秒 鐘表示室內明亮程度的三葉草標記。室內變 暗時,顯示在屏幕上的三葉草標記會增加。 DIGITAL ECO SENSOR: 打開ECO SENSOR功能。但是在此模式時, 不顯示三葉草標記。 DIGITAL ECO SENSOR OFF: 關閉ECO SENSOR功能。 PICTURE MODE(圖像模式)按鈕 可按需選擇三種圖像調節設定值。 請按下此按鈕,選擇一個模式。 BRIGHT: 加大對比度和銳度。 STANDARD: 調節圖像至標準。 SOFT: 使對比度和銳度柔和。 • 按下此按鈕,將“MENU 4”中的所有圖像設 定值全部返回到默認設定值。 8 請按下此按
遙控器按鈕和功能 DISPLAY(顯示)按鈕 可在屏幕上持續顯示當前頻道號或視頻模 式。 RETURN <(智能控制調回系統)按 鈕 請按下此按鈕。 可將經常觀看的頻道設定為調回頻道,任何 時候僅需按一下就可觀看該頻道。 再次按下此按鈕,停止顯示。 若要將頻道設定為調回頻道: • 當選擇無信號的視頻模式時,視頻模式的顯示 會固定在屏幕上。 1 選擇要設定為調回頻道的頻道。 OFF TIMER(關機定時器)按鈕 可將電視機設定成到了設定的時間後自動關 閉。 2 持續按住此按鈕,直至出現“RETURN PLUS PROGRAMMED!”的訊息。 • 關閉電視機時,將取消調回頻道的設定。 請按下此按鈕,選擇時間。 若要觀看調回頻道: 請按下此按鈕。 • 可以10分鐘為增量設定時間,最多為120分鐘。 • 按下此按鈕,可交替觀看兩個頻道(當前頻道 和調回頻道)。 • 在OFF TIMER功能關閉電視機前的1分鐘,會 出現“GOOD NIGHT!”。 按一次此按鈕,會顯示剩餘時間。 按下此按鈕,把時間設為0時,將取消OFF TIMER功能。 • OFF TIMER功能不會關閉電視機的主電
使用電視機的菜單 本電視機具有許多可用菜單操作的功能。為了充分利用所有的電視機功能,請掌握利用菜單 的方法。 4 按下 MENU M 按鈕,改變功能的 設定值。 DISPLAY POWER DISPLAY 例如: 改變AUTO SHUTOFF設定值。 MENU t MENU MENU m CHANNEL MENU 2 AUTO SHUTOFF OFF CHILD LOCK OFF BLUE BACK ON VIDEO-2 SET COMPONENT VOLUME SELECT BY OPERATE BY -+ EXIT BY DISPLAY ⇔ MENU 2 AUTO SHUTOFF ON CHILD LOCK OFF BLUE BACK ON VIDEO-2 SET COMPONENT SELECT BY OPERATE BY -+ EXIT BY DISPLAY • 有些功能的操作方法可能不同。 ■基本操作 5 按下 DISPLAY 按鈕,關閉顯示。 1 按下 MENU T 按鈕。 • 要用電視機前面板上的按鈕操作菜單, 請參照第18頁上的“操作菜單”。 顯示五個菜
使用電視機的菜單 輸入 (INPUT) 降噪 (VNR) 可觀看來自與電視機連接的錄像機或其他裝 置的圖像。 可減少圖像的噪音。 1 按下 MENU T,顯示“MENU 1” 菜單,然後選擇“INPUT”。 MENU INPUT VNR COMPRESS(16:9) PICTURE TILT SELECT BY OPERATE BY -+ 1 TV ON ON 00 EXIT BY DISPLAY 2 按下 MENU M,選擇“VIDEO-1”, “VIDEO-2”或“VIDEO-3”。 電視模式轉換為視頻模式。 畫面糾正 (PICTURE TILT) <僅適用於AV-29L31和AV-29L31B> 地球的磁力有時可能會使圖像傾斜。此時, 可糾正圖像的傾斜。 1 按下 MENU T,顯示“MENU 1” 菜單,然後選擇“PICTURE TILT”。 MENU INPUT VNR COMPRESS(16:9) PICTURE TILT SELECT BY OPERATE BY -+ 1 TV ON ON 00 EXIT BY DISPLAY 1 按下 MENU T,顯示“MENU 1” 菜
使用電視機的菜單 自動關機 (AUTO SHUTOFF) 藍背景 (BLUE BACK) 可將電視機設定成當最後一個電視節目結束 後約1 5 分鐘以上未接收到信號時關閉電視 機。 當電視機未接收到信號或信號不穩定時,可 靜音並將圖像變成藍色屏幕。 1 按下 MENU T,顯示“MENU 2”菜 單,然後選擇“AUTO SHUTOFF”。 MENU 2 AUTO SHUTOFF ON CHILD LOCK ON BLUE BACK ON VIDEO-2 SET COMPONENT SELECT BY OPERATE BY -+ EXIT BY DISPLAY 2 按下 MENU M,選擇“ON”。 要取消自動關機功能時,請選擇“OFF”。 • 自動關機功能並不關閉電視機的主電源。 • 自動關機功能對視頻模式無效。 童鎖 (CHILD LOCK) 可使電視機的前面控制按鈕功能無效。 當此功能被設定為“ON”時,隻能用遙控器 操作電視機。 利用此功能可防止兒童在未得到父母的同意 的情況下操作電視機。 1 按下 MENU T,顯示“MENU 2”菜 單,然後選擇“CHILD LOCK”。 MENU 2
使用電視機的菜單 視頻-2設定 (VIDEO-2 SET) 自動頻道預置 (AUTO CH PRESET) 請按照從連接在VIDEO-2端子上的外接裝置 輸入的視頻信號正確地設定視頻-2設定。如 果設定不正確,將不能正確顯示圖像。 可自動將所有電視機可接收的電視頻道預置 為頻道。 1 按下 MENU T,顯示“MENU 2” 菜單,然後選擇“VIDEO-2 SET”。 MENU 2 AUTO SHUTOFF ON CHILD LOCK ON BLUE BACK ON VIDEO-2 SET COMPONENT SELECT BY OPERATE BY -+ 1 按下 MENU T,顯示“MENU 3”菜 單,然後選擇“AUTO CH PRESET”。 MENU 3 AUTO CH PRESET CHANNEL SKIP CLOSED CAPTION MTS STEREO SAP MONO ON AIR SELECT BY OPERATE BY -+ EXIT BY DISPLAY EXIT BY DISPLAY 2 按下 MENU M。 2 按照 VIDEO-2 端子輸入的視頻信號設定 視頻
使用電視機的菜單 頻道跳越 (CHANNEL SKIP) 多頻道電視音響(MTS) 可設定不要的頻道,將其跳過。被設定 為跳躍的頻道不能用CHANNEL m 按鈕 或 C H A N N E L S C A N按 鈕 選 擇 。 可選擇MTS(多頻道電視音響)設定,以 選擇立體聲、單聲道和SAP(第二聲訊節 目)。 1 按下 MENU T,顯示“MENU 3” 菜單,然後選擇“CHANNEL SKIP”。 1 按下MENU T,顯示“MENU 3”菜 單,然後選擇“MTS”。 MENU 3 AUTO CH PRESET CHANNEL SKIP CLOSED CAPTION MTS STEREO SAP MONO ON AIR SELECT BY OPERATE BY -+ EXIT BY DISPLAY 2 按下 MENU M。 顯示子菜單。 SELECT BY OPERATE BY -+ EXIT BY DISPLAY 2 按下MENU M,選擇模式。 • “ON AIR ”指示現正發送的信號。 CH SKIP CH SKIP CH SKIP CH SKIP 01 - 06 -
使用電視機的菜單 圖像調節 自動音控 (AI VOLUME) 可按照需要調節圖像。 可防止改變頻道或切換視頻模式時的音量的 突然增減。 1 按下 MENU T ,顯示“MENU 4” 菜單。 MENU 4 TINT COLOR BRIGHT PICTURE DETAIL SELECT BY OPERATE BY -+ 1 按下 MENU T,顯示“MENU 5” 菜單,然後選擇“AI VOLUME”。 MENU BASS TREBLE BALANCE AI VOLUME MONO SURROUND EXIT BY DISPLAY SELECT BY OPERATE BY -+ 2 按下MENU T,選擇一個項目,並 按下MENU M 進行調節。 TINT* COLOR BRIGHT PICTURE DETAIL -:較紅 -:較淡 -:較暗 -:較低 -:較柔和 +:較綠 +:較深 +:較亮 +:較高 +:較明顯 * 用VIDEO-2 SET功能選擇“COMPONENT” 後,您不能調節TINT。 聲音調節 可按照需要調節聲音。 1 按下 MENU T,顯示“MENU 5” 菜單
安裝TWIN PORT BASS BLASTER (雙端口低音發音器裝置) <僅適用於AV-21L31B> 與電視機一起裝有TWIN PORT BASS BLASTER裝置。使用電視機之前,請將TWIN PORT BASS BLASTER裝置正確地安裝在電視機上。 注: • 除非將TWIN PORT BASS BLASTER裝置正確連接於電視機,否則BASS(超低音)功能不能發揮作用。 注意: • 僅需將TWIN PORT BASS BLASTER裝置放在電視機的頂上,而無需用螺絲固定。使用TWINPORT BASS BLASTER裝置時,請遵守下列注意事項。否則TWIN PORT BASS BLASTER裝置或電視機可能 會倒下並損壞,或意外受傷。 —請勿將手或肘放在TWIN PORT BASS BLASTER裝置上。 —請勿連著電視機頂上的TWIN PORT BASS BLASTER裝置一起搬動電視機。搬動電視機前,請務必取 下TWIN PORT BASS BLASTER裝置。 —請勿邊拿著TWIN PORT BASS BLASTER裝置邊搬動電視機。 1 將TWIN PORT BASS BLASTE
電視機按鈕和部件 前面 <AV-29L31和AV-29L31B> 1 2 3 4 V L/MONO 5 6 R IN (VIDEO-3) <AV-21L31B> 1 1 2 3 4 2 3 4 8 7 8 5 5 6 7 8 耳機插口 VIDEO-3端子 MENU按鈕 CHANNEL m 按鈕 7 VOLUME m 按鈕 TV/VIDEO按鈕 POWER指示燈 主電源按鈕 後面 VIDEO-1 INPUT COMPONENT (VIDEO-2) INPUT OUTPUT Y/ V V L / MONO C B L / MONO L R R V 1 CR 2 R 3 4 1 VIDEO-1 INPUT端子 2 COMPONENT(VIDEO-2) INPUT端子 3 OUTPUT端子 4 天線插口 17
使用電視機的按鈕 基本操作 操作菜單 • 請確認童鎖功能被設為“OFF”。當童鎖功能 為“ON”時,不能用前面控制按鈕操作電視 機。詳細說明,請參照第12頁上的“童鎖 (CHILD LOCK)”。 可用電視機前面控制按鈕操作菜單中的功 能。 1 按下 CHANNEL M,從標準模式打開 電視機。 2 反復按下 MENU y,顯示需使用的菜 單。 2 按下 CHANNEL M,選擇頻道。 3 按下 MENU y,選擇所需的功能或項 目。 3 按下 VOLUME M 按鈕,調節音量。 4 要關閉電視機時,請按下主電源按鈕, 關閉電視機的主電源。 若要將電視模式轉換為視頻模式: • 如果電視機帶有TV/VIDEO按鈕,請按下該按 鈕。請參照第7頁。 • 如果電視機沒有TV/VIDEO按鈕,請用 “MENU 1”中的輸入功能選擇視頻模式。 18 1 按下 MENU y ,顯示菜單。 4 按下 MENU M 或 VOLUME M,進 行所需的操作。 詳細說明,請參照各功能的說明。 5 按下 VOLUME M 關閉菜單的顯示。
故障排除 如果無圖像顯示或電視機工作不正常,請檢查問題是否是由下列所示的原因引起的。 如果即使采用了下列方法還是解決不了問題時,請與維修人員聯絡。 不能打開電視機 圖像不正常 • 按下電視機上的主電源按鈕。 • 調節圖像設定值。(參照第15頁。) • DVD播放機等組合信號輸出裝置的連接是 否正確?(參照第5頁。) • 視頻-2設定(VIDEO-2 SET)設定值是否正 確?(參照第13頁。) • 如果噪音(雪花)遮住了整個圖像時,請檢查 下列各點。 - 電視機和天線的連接是否正確? - 天線電纜是否損壞? - 是否天線指向右方? - 天線是否壞了? • 如果電視機或天線受其他裝置的干擾,會在圖 像上出現條紋或噪音。請使造成干擾的裝置遠 離電視機。 • 如果電視機或天線受來自大山或建築物的信號 反射的干擾,會出現雙重圖像(重影)。請改 變天線的方向或將其更換為方向性較好的天 線。 • 當在屏幕上顯示明亮的白色靜止圖像(例如白 色衣服)時,白色部分會看上去呈彩色。當圖 像從屏幕上消失後,該不自然的色彩也會消 失。 • 將電源線連接於交流電源插座。 屏幕變為藍色 • 藍背景(BULE BACK)功能是
規格 電視RF制式 M 彩色制式 NTSC 頻道 VHF 2至13, VHF14至69 副中頻、高頻、超高頻和極高頻頻道 外接輸入 輸出 VIDEO-1: VIDEO 輸入, AUDIO L/R 輸入 VIDEO-2/COMPONENT: VIDEO 輸入, AUDIO L/R 輸入, COMPONENT VIDEO (Y/CB/CR) 輸入 VIDEO-3: VIDEO 輸入, AUDIO L/R 輸入 OUTPUT: VIDEO 輸出 , AUDIO L/R 輸出 耳機插口: 立體聲微型插口(直徑3.5毫米) 聲音多重制式 BTSC(多頻道音響) 目錄 彩色電視機 使用說明書 感謝惠購JVC彩色電視機。 請在使用電視機前通讀本說明書,以便 掌握新電視機的使用方法。 安全須知 準備 1 2 3 4 5 6 確認遙控器的種類 ....................... 3 將電池裝入遙控器 ....................... 3 連接天線和錄像機 ...................... 4 連接其他裝置 ..........................
