EX-D5[B]_f.
EX-D5[B]_f.book Page 1 Wednesday, June 1, 2005 8:46 PM Warnings, cautions and others IMPORTANT for the U.K. CAUTION DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or consult your dealer. BE SURE to replace the fuse only with an identical approved type, as originally fitted.
EX-D5[B]_f.book Page 2 Wednesday, June 1, 2005 8:46 PM IMPORTANT FOR LASER PRODUCTS 1. CLASS 1 LASER PRODUCT 2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to qualified service personnel. 3. CAUTION: Visible and invisible laser radiation when open and interlock failed or defeated. Avoid direct exposure to beam. 4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED INSIDE THE UNIT. INCLUDE R&TTE NOTIFIED EQUIPMENT USB wireless transmitter [2.
EX-D5[B]_f.book Page 3 Wednesday, June 1, 2005 8:46 PM SAFETY INSTRUCTIONS “SOME DOS AND DON’TS ON THE SAFE USE OF EQUIPMENT” This equipment has been designed and manufactured to meet international safety standards but, like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured. Do read the operating instructions before you attempt to use the equipment.
EX-D5[B]_f.book Page 1 Wednesday, June 1, 2005 8:46 PM Table of contents Introduction About discs......................................................3 Description of parts .........................................5 Getting started Using the remote control .................................6 Putting the batteries in the remote control .......... 6 Operating the TV using the remote control......... 7 Connecting up .................................................8 Basic operations Playing discs .........
EX-D5[B]_f.book Page 2 Wednesday, June 1, 2005 8:46 PM Special cautions Care of the cabinet When cleaning the system, use a soft cloth and follow the relevant instructions on the use of chemically-coated cloths. Do not use benzene, thinner or other organic solvents including disinfectants. These may cause deformation or discoloring. Notes on handling 7 Important cautions Installation of the system • Select a place which is level, dry and neither too hot nor too cold; between 5°C and 35°C.
EX-D5[B]_f.book Page 3 Wednesday, June 1, 2005 8:46 PM About discs Introduction * Note on Region Code Playable disc types This system has been designed to play back the following discs: DVD VIDEO, DVD AUDIO, VCD, SVCD, CD This system can also play back the following discs: • Finalized DVD-R/-RW discs recorded in the DVD VIDEO format.
EX-D5[B]_f.book Page 4 Wednesday, June 1, 2005 8:46 PM About discs (continued) Notes on all files • The system can only recognize and play files with one of the following extensions, which can be in any combination of upper and lower case; • MP3: “.MP3”, “.mp3” • WMA: “.WMA”, “.wma” • JPEG: “.JPG”, “.JPEG”, “.jpg”, “.jpeg” • If a character other than single byte English characters is used in the file name of an MP3/WMA/JPEG file, the track/file name will not be displayed correctly.
EX-D5[B]_f.book Page 5 Wednesday, June 1, 2005 8:46 PM Description of parts Introduction The numbers represent the page numbers. Front panel Top of the unit See “Display window” below. 16 16 38 32 15 14 12 16 12 11 Behind the door 38 12 BASS/TREBLE DIMMER 3D PHONIC WIRELESS FM/AM AU X DOWN MULTI CONTROL UP 26 41 15 PLAY PAUSE 14 12 PHONES * Connect headphones (not supplied) with a stereo mini plug.
EX-D5[B]_f.book Page 6 Wednesday, June 1, 2005 8:46 PM Using the remote control The numbers represent the page numbers.
EX-D5[B]_f.book Page 7 Wednesday, June 1, 2005 8:46 PM Getting Introduction started This page is for when operating your TV using the remote control of this product.
EX-D5[B]_f.book Page 8 Wednesday, June 1, 2005 8:46 PM Connecting up – Do not turn on the power until the connection is complete – Connection Connecting antennas Connecting AM loop antenna (supplied) 1 Set up the AM loop antenna. Connecting FM antenna (supplied) Main unit (rear panel) FM antenna FM75Ω COAXIAL Put the antenna up straight in the direction where the best radio reception can be obtained, and fix by using tape. 2 Connect antenna cords.
EX-D5[B]_f.book Page 9 Wednesday, June 1, 2005 8:46 PM Connecting up Getting Connection started Connecting speakers There is no difference between the left and right speakers. Speaker terminal Speaker cord Speaker cord (supplied) SPEAKERS Speaker cord (supplied) Without black line With black line Without black line With black line R L Main unit (rear panel) Right speaker (rear panel) Left speaker (rear panel) CAUTION • DO NOT connect more than one speaker to one speaker terminal.
EX-D5[B]_f.book Page 10 Wednesday, June 1, 2005 8:46 PM Connecting up (continued) – Do not turn on the power until the connection is complete – Connection Connecting other devices This page is for when connecting the main unit with other devices. Connecting subwoofer With an amplifier-built-in subwoofer (not supplied), you can enjoy a more dynamic bass sound. Refer to the manual of the subwoofer for details.
EX-D5[B]_f.book Page 11 Wednesday, June 1, 2005 8:46 PM Connecting up Getting Connection started Connecting by using the component video cord Connecting with TV Supplied composite video cord TV You can enjoy better quality pictures than when using the S-Video cord. Main unit COMPONENT Y PB VIDEO PR S-VIDEO VIDEO OUT CAUTION Connect the main unit directly with a TV (or a monitor) without routing through a VCR. Otherwise it may cause picture distortion while playing.
EX-D5[B]_f.book Page 12 Wednesday, June 1, 2005 8:46 PM Playing discs Playback (Refer to page 17 for playing MP3/WMA and JPEG.) page 5 1 Press Place a disc with the label side facing up. • Place an 8 cm disc in to the hollow part in the center. AUDIO. • The power will be turned on and the standby indicator will go off. • Press AUDIO again to turn off the power. 2 Press 0OPEN/CLOSE to open the disc tray to load a disc. 3 Press DVD/CD 3. The disc tray will close and playback will start.
EX-D5[B]_f.book Page 13 Wednesday, June 1, 2005 8:46 PM Basic operations Ex.: When a CD is played WIRELESS S V C DV D - A Track number Ex.: When an MP3/WMA file is played Display window during disc playback Ex.: When a DVD VIDEO is played S V C DV D - A Track number S V C DV D - A To switch the display Disc type Chapter number Elapsed playing time Press DISPLAY. Each time you press the button, the display indication changes temporarily as follows: • For DVD VIDEO Ex.
EX-D5[B]_f.book Page 14 Wednesday, June 1, 2005 8:46 PM Playing discs (continued) Designate the chapter number or track number to play during playback. • Refer to “How to use the number buttons” on page 15. WIRELESS To stop playback Press 7 during playback. To pause playback Press 8 during playback. To start normal playback again, press DVD/CD 3. • For JPEG slide-show, pressing DVD/CD 3 starts playback from the next file. To advance picture frame-by-frame Press 8 during pause.
EX-D5[B]_f.book Page 15 Wednesday, June 1, 2005 8:46 PM Basic operations Playing back from a position 10 seconds before (One Touch Replay) Skip to the beginning of the selection Press 4 or ¢ during playback*. Press during playback. NOTE • This operation may not be carried out for some discs. • It is not possible to go back to the previous title. Slow Motion Playback • Press ¢ to skip the next chapter or track.
EX-D5[B]_f.book Page 16 Wednesday, June 1, 2005 8:46 PM Playing discs (continued) Playing audio/video files To change the brightness of the display window (DIMMER) Press DIMMER repeatedly. WIRELESS • Each time you press the button, the dimmer mode changes as follows: AUTO DIMMER: During the video source playback, the display window dims and the illumination automatically turns off. DIMMER ON: The display window and the illumination dim. DISPLAY OFF: The display window and the illumination turn off.
EX-D5[B]_f.book Page 17 Wednesday, June 1, 2005 8:46 PM Advanced operations 5 Playback Press DVD/CD 3 or ENTER. NOTE Display of an MP3/WMA disc is described here as an example. For a JPEG disc, read “track” as “file”. • GROUP/TITLE can also be used in Step 2. • The number buttons can also be used in Step 4. In this case, Step 5 is not needed. (For how to use the number buttons, refer to page 15.) • 4 or ¢ can also be used in Step 4. In this case, Step 5 is not needed.
EX-D5[B]_f.book Page 18 Wednesday, June 1, 2005 8:46 PM Resume Playback WIRELESS This system can store the stop point, and when you start playback again by pressing DVD/CD 3 (even while on standby), it starts from the position where you have stopped—Resume Play. The RESUME indicator lights on the display window when you stop playback. How to suspend playback Perform any of the following operations during playback. Press 7 once.* Press AUDIO to turn off the power.
EX-D5[B]_f.book Page 19 Wednesday, June 1, 2005 8:46 PM Select the scene to be played WIRELESS Advanced operations NOTE *1 For a VCD and SVCD, this operation can be carried out only when the PBC function is off. • This operation cannot be carried out for a disc without a menu screen. • Playback may start for some discs without pressing ENTER. Designate the time (Time search) 1 Press ON SCREEN twice during playback*2. The menu bar will be displayed (page 28). 2 Press cursor 2/3 to select .
EX-D5[B]_f.book Page 20 Wednesday, June 1, 2005 8:46 PM Program Playback/Random Playback Play the disc in the desired order (Program Playback) It is possible to program a maximum of 99 chapters or tracks. The same chapter or track can be programmed more than once. WIRELESS 1 While the disc is stopped, press PLAY MODE repeatedly to display “PROGRAM” on the display window on the main unit. TV screen Program screen 2 NOTE Set the remote control mode selector to AUDIO before using the number buttons.
EX-D5[B]_f.book Page 21 Wednesday, June 1, 2005 8:46 PM Advanced operations To program on the display window on the main unit, operate as follows: (1) Select a title/group using the number buttons. (2) Designate a chapter/track number using the number buttons. • Refer to “How to use the number buttons” (page 15). • The program number will be displayed on the lower display window (Ex.: “P2”).
EX-D5[B]_f.book Page 22 Wednesday, June 1, 2005 8:46 PM Repeat Playback Refer to page 17 for Repeat Playback of MP3/WMA and JPEG files. For DVD AUDIO Repeat items On the TV Current track On the display window TRACK Current group GROUP Cancel OFF For CD/VCD/SVCD Repeat items Current track All tracks Cancel On the TV On the display window TRACK ALL OFF NOTE Playing the title/chapter/ group/track/all tracks repeatedly (REPEAT) Press REPEAT during playback.
EX-D5[B]_f.book Page 23 Wednesday, June 1, 2005 8:46 PM Advanced operations Playing the designated part repeatedly (A-B Repeat Playback) 1 Press ON SCREEN twice during playback. The menu bar (page 28) will be displayed. 2 Press cursor 2/3 to select OFF . 3 4 Press ENTER. Press cursor 5/∞ to display OFF A B . Other Repeat modes can be selected here. For other Repeat modes, refer to “Playing the title/chapter/group/track/all tracks repeatedly (REPEAT)” (page 22).
EX-D5[B]_f.book Page 24 Wednesday, June 1, 2005 8:46 PM Other convenient functions Selecting the audio language 1 Press AUDIO during playback of a disc containing several audio languages. Ex.: • Each time you press the button, the audio language will be alternated. Also, the audio language can be changed by pressing cursor 5/∞. • For a language code such as “AA”, refer to “Language codes” (page 45).
EX-D5[B]_f.book Page 25 Wednesday, June 1, 2005 8:46 PM Advanced operations Enlarging the picture (ZOOM) 2 • It is recommended to select “NORMAL” usually, or “CINEMA” in a dark room. When either “NORMAL” or “CINEMA” is selected, go to Step 7. • When either “USER 1” or “USER 2” is selected, the adjustment can be carried out in detail in the operations after Step 3. (only for moving image) 1 Press ZOOM during playback or while paused.
EX-D5[B]_f.book Page 26 Wednesday, June 1, 2005 8:46 PM Other convenient functions (continued) Adjusting playback level (DVD LEVEL) WIRELESS The audio of a DVD VIDEO may be recorded at a lower level (volume) than for other types of disc. If the difference is not to your liking, adjust the DVD Level. 1 Press DVD LEVEL during playback. • Each time you press the button, the level will be alternated among “NORMAL”, “MIDDLE” and “HIGH”. • Select the level while listening to the sound played.
EX-D5[B]_f.book Page 27 Wednesday, June 1, 2005 8:46 PM Functions specific to DVD AUDIO Advanced operations Playing the Bonus Group There are some DVD AUDIO discs with a special group, called “Bonus Group”, recorded. NOTE This operation can be carried out when “BONUS” is lit on the display window on the main unit. WIRELESS 1 Press GROUP/TITLE repeatedly during playback to select a bonus group. “KEY_ _ _ _” appears on the TV screen, and on the display window on the main unit.
EX-D5[B]_f.book Page 28 Wednesday, June 1, 2005 8:46 PM Using the menu bar Select this to change time information displayed on the display window on the main unit and the status bar. Each time ENTER is pressed, the display will be alternated. DVD VIDEO/DVD AUDIO (operating during playback) TOTAL : Elapsed playing time of current title/ group. T.REM : Remaining time of current title/group. TIME : Elapsed playing time of current chapter/track. REM : Remaining time of current chapter/track.
EX-D5[B]_f.book Page 29 Wednesday, June 1, 2005 8:46 PM Preferences Advanced operations NOTE The playback status mark has the same meaning of the mark on the On-screen guide (page 15). • For a language code such as “AA”, refer to the “Language codes” (page 45). Items Contents MENU LANGUAGE Select the language for the DVD VIDEO menu. AUDIO LANGUAGE Select the audio language for the DVD VIDEO. SUBTITLE Select the subtitle language for the DVD VIDEO.
EX-D5[B]_f.book Page 30 Wednesday, June 1, 2005 8:46 PM Preferences (continued) AUDIO Items Contents ( DIGITAL AUDIO OUTPUT OTHERS : initial setting) Items Contents ( Select an output signal type from the following in accordance with the device connected to the digital audio output terminal (AV amplifier, etc.). (See the list below for the preference items and output signal.) RESUME Select ON /OFF. (page 18) ON SCREEN GUIDE Select ON /OFF.
EX-D5[B]_f.
EX-D5[B]_f.book Page 32 Wednesday, June 1, 2005 8:46 PM Listening to a radio broadcast Selecting a station 1 Press FM/AM. Each time you press the button, FM and AM (MW) change alternately. WIRELESS 2 Press 4/¢ to select the station (frequency). Automatic tuning: Hold down 4/¢ until the system starts searching, and then release the button. (The AUTO indicator lights while searching.) When a station of sufficient signal strength is tuned in to, the system stops searching automatically.
EX-D5[B]_f.book Page 33 Wednesday, June 1, 2005 8:46 PM Tuning in to a preset station Listening to radio 3 WIRELESS Select the number you want to store by pressing number buttons while “MEMORY” is flashing. • You can also select the number by using the number buttons. • Refer to “How to use the number buttons” (page 15). 4 Press MEMORY while the selected number is flashing. “STORED” appears on the display window and the selected station is stored.
EX-D5[B]_f.book Page 34 Wednesday, June 1, 2005 8:46 PM Using the RDS To show the RDS signals information Using the RDS (Radio Data System) when receiving FM stations RDS allows FM stations to send an additional signal along with their regular program signals. For example, the stations send their station names, as well as information about what type of program they broadcast, such as sports or music, etc. Press RDS DISPLAY while listening to an FM station.
EX-D5[B]_f.book Page 35 Wednesday, June 1, 2005 8:46 PM Listening to radio Searching for a program by PTY codes One of the advantages of the RDS service is that you can locate a particular kind of program from the preset channels (page 33) by specifying the PTY codes. • While the PTY code selected in Step 2 is still on the display window: 3 Press PTY SEARCH again. To search for a program using the PTY codes NOTE Before you start operation; • The PTY Search is only applicable to preset stations.
EX-D5[B]_f.book Page 36 Wednesday, June 1, 2005 8:46 PM Using the RDS (continued) Description of the PTY codes NEWS: AFFAIRS: INFO: SPORT: EDUCATE: DRAMA: CULTURE: SCIENCE: VARIED: POP M: ROCK M: EASY M: LIGHT M: CLASSICS: OTHER M: WEATHER: FINANCE: CHILDREN: SOCIAL: RELIGION: PHONE IN: TRAVEL: LEISURE: JAZZ: COUNTRY: NATION M: OLDIES: 36 News. Topical program expanding or enlarging upon the news — debate, or analysis. Programs the purpose of which is to impart advice in the widest sense.
EX-D5[B]_f.book Page 37 Wednesday, June 1, 2005 8:46 PM Listening to radio To stop listening to the program selected by Enhanced Other Network Press TA/News/Info repeatedly again so that the program type indicator (TA/NEWS/INFO) goes off from the display window. The system exits from Enhanced Other Network standby mode and goes back to the previously selected station.
EX-D5[B]_f.book Page 38 Wednesday, June 1, 2005 8:46 PM Using USB wireless transmission 1 • For smooth operation, do not run too many applications simultaneously when your PC has been turned on. WIRELESS 2 Connect the supplied wireless transmitter to the USB connector of the PC. • Before connecting the transmitter to the PC, remove the cover of the transmitter. • For WindowsR Me, WindowsR 2000, or WindowsR XP: When you connect the transmitter, the PC will detect the transmitter automatically.
EX-D5[B]_f.book Page 39 Wednesday, June 1, 2005 8:46 PM Convenient functions 4 Start the music application and play any music on your PC. • The PLAYER indicator on the transmitter flashes. If the transmitter blocks usage of other USB ports Use the supplied extension cable. USB WIRELESS TRANSMITTER USB WIRELESS TRANSMITTER POWER ID Extension cable PLAYER Your PC music is transmitted to the system.
EX-D5[B]_f.book Page 40 Wednesday, June 1, 2005 8:46 PM Using USB wireless transmission (continued) If noise comes during playback or playback is interrupted with the wireless connection, try either operation below: • press CHANNEL on the transmitter to search for another frequency. Each time you press CHANNEL, the frequency advances one channel up from CH 1 up to CH 13. • press and hold CHANNEL for more than three seconds to make sure the transmitter detects the best frequency automatically.
EX-D5[B]_f.book Page 41 Wednesday, June 1, 2005 8:46 PM Listening to the sound of other audio device Setting the various timer WIRELESS Connect the other audio device to this system in advance (page 10). 1 Press AUX. The source changes to AUX. 2 Play the other audio device. For details, refer to the manual of the device connected. 3 Adjust the volume and the sound quality of the system (page 16). Setting the built-in clock Without setting the built-in clock, you cannot use any timers.
EX-D5[B]_f.book Page 42 Wednesday, June 1, 2005 8:46 PM Setting the various timer (continued) How the daily timer works: Once the daily timer has been set, the timer indicator and timer number indicator (1/2/3) are lit on the display window. Daily timer turns on the system at the same time everyday until the timer setting is canceled manually or another daily timer is activated.
EX-D5[B]_f.book Page 43 Wednesday, June 1, 2005 8:46 PM Tray Lock Sleep Timer When the time you specify elapses, the system will be turned off by itself. Press SLEEP. Each time you press the button, the time indicated on the display window on the main unit changes (in minutes). Changing the time Reselect the time by pressing SLEEP repeatedly. Convenient functions You can lock the disc tray to prevent the disc from being ejected.
EX-D5[B]_f.book Page 44 Wednesday, June 1, 2005 8:46 PM Troubleshooting When you encounter a problem that seems to be a fault, check the following points before contacting your JVC service center. Power source 7 Power does not come on. • The power cord is not connected to the main unit or an AC outlet. → Connect the power cord correctly (page 11). Operation 7 You cannot operate any button. • Some specific operations may be inhibited for some discs. 7 The remote control does not work.
EX-D5[B]_f.book Page 45 Wednesday, June 1, 2005 8:46 PM Language codes Others 7 It is not possible to switch audio or subtitles between languages. • The disc does not contain 2 or more languages. → If only a single language is recorded on the disc, switching to another language is impossible (page 24). 7 No subtitle is displayed. • The disc does not contain any subtitles. → A DVD VIDEO without subtitles cannot display any subtitles. • The subtitle language is set to “OFF”. → Specify a language (page 29).
EX-D5[B]_f.book Page 46 Wednesday, June 1, 2005 8:46 PM Specifications Reference General Power source: Power consumption: Audio input AC 230 V , 50 Hz 25 W (in operation) 1.0 W (on standby) 3.0 kg Weight: External dimensions (W x H x D): 150 mm x 152 mm x 246 mm Sound input: AUX x1 400 mV/50 kΩ USB Wireless Transmission The USB wireless transmitter supplied with this system supports Direct Sequence Spreading Spectrum (DSSS) using 2.4 GHz frequency band.
MEMO
EX-D5[B]_f.
