MODELS: HD-P61R1U, HD-P70R1U
Quick Setup TV Models
Side Panel Diagram
VOLUME
INPUT 4
CHANNEL
OPERATE
+
–
+
–
MENU
OVER
S-VIDEO
VIDEO
L/MONO
R
AUDIO
INPUT
Front Panel Diagram
LAMP/PROGRAM LED
POWER BUTTON
POWER LED
MEDIA CARD SLOT
POWER LAMP/PROGRAM
POWER LAMP/PROGRAM
Close door when using media cards
COMPACT
FLASH
SD/
MMC
xD-Picture
Card
*HD-P70R1U ONLY
• For information on the LED, see page 102.
• Media Card Slot is for HD-P70R1U ONLY. To open the door, gently pull the tab on the door.
