ENGLISH Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. CONTENTS How to reset your unit ............................... How to use the M (MODE) button ............. 2 3 LOCATION OF THE BUTTONS ............ 4 Control panel ............................................. 4 BASIC OPERATIONS ....................... 5 Turning on the power ..........................
LOCATION OF THE BUTTONS ENGLISH Control panel Display window 1 2 3 4 5 6 7 8 9 p q w e r t y u Remote sensor Control dial (standby/on/attenuator) button SEL (select) button Screws—M2 × 5 mm (only for KD-SC800R) Plate cover and standard plate (only for KD-SC800R) FM/AM button 5 (up) button +10 button 0 (eject) button 4 /¢ buttons (control panel release) button DISP (display) button • Also functions as SSM buttons when pressed together with M (MODE) button.
ENGLISH BASIC OPERATIONS 1 3 2 Turning on the power 1 Adjust the sound as you want. (See pages 20 and 21.) Turn on the power. To drop the volume in a moment Note on One-Touch Operation: When you select a source in step 2 below, the power automatically comes on. You do not have to press this button to turn on the power. 2 4 Select the source. Press briefly while listening to any source. “ATT” starts flashing on the display, and the volume level will drop in a moment.
ENGLISH 4 Setting the clock 1 Select “24H/12H.” 2 Select “24H” or “12H.” You can also set the clock system to either 24 hours or 12 hours. 1 1 2 Press and hold SEL (select) for more than 2 seconds so that one of the PSM items appears on the display. (PSM: see page 23.) 5 2 Set the clock system. Finish the setting. Set the hour. 1 Select “CLOCK H” (hour) if not shown on the display. 2 Adjust the hour. 1 To check the current clock time or change the display mode Press DISP (display) repeatedly.
ENGLISH RADIO OPERATIONS Listening to the radio You can use either automatic searching or manual searching to tune in to a particular station. Searching a station automatically: Auto search 1 To stop searching before a station is received, press the same button you have pressed for searching. Searching a station manually: Manual search 1 Select the band (FM1 – 3, AM). Each time you press the button, the band changes as follows: Select the band (FM1 – 3, AM).
ENGLISH 3 Tune in to a station you want while “M” (manual) is flashing. To tune in to stations of higher frequencies To tune in to stations of lower frequencies • If you release your finger from the button, the manual mode will automatically turns off after 5 seconds. • If you hold down the button, the frequency keeps changing (in 50 kHz intervals for FM and 9 kHz intervals for AM—MW/LW) until you release the button.
You can preset up to 6 stations in each band (FM1, FM2, FM3, and AM) manually. Ex.: Storing FM station of 88.3 MHz into the preset number 1 of the FM1 band. 1 Select the band (FM1 – 3, AM) you want to store stations into (in this example, FM1). Each time you press the button, the band changes as follows: FM1 2 FM2 FM3 AM Tune in to a station (in this example, of 88.3 MHz).
ENGLISH RDS OPERATIONS What you can do with RDS RDS (Radio Data System) allows FM stations to send an additional signal along with their regular programme signals. For example, the stations send their station names, as well as information about what type of programme they broadcast, such as sports or music, etc. Another advantage of RDS function is called “Enhanced Other Networks.
Press and hold SEL (select) for more than 2 seconds so that one of the PSM items appears on the display. (PSM: see page 23.) Using TA Standby Reception TA Standby Reception allows the unit to switch temporarily to Traffic Announcement (TA) from the current source (another FM station or CD). ENGLISH 1 • TA Standby Reception will not work if you are listening to an AM station. 2 3 4 Press T (TP/PTY) to activate TA Standby Reception.
ENGLISH Using PTY Standby Reception 4 Finish the setting. PTY Standby Reception allows the unit to switch temporarily to your favorite programme (PTY: Programme Type) from the current source (another FM station or CD). • PTY Standby Reception will not work if you are listening to an AM station. You can select your favorite programme type for PTY Standby Reception. When shipped from the factory, PTY Standby Reception is turned off. (“OFF” is selected for PTY Standby Reception.
2 You can search any one of the PTY codes. In addition, you can store your 6 favorite programme types in the number buttons. When shipped from the factory, the following 6 programme types have been stored in the number buttons (1 to 6). To store your favorite programme types, see below. To search your favorite programme type, see page 14. 1 POP M 2 ROCK M 3 EASY M 4 CLASSICS 5 AFFAIRS 6 VARIED Select one of the twenty-nine PTY codes. (See page 16.) Selected code name appears on the display.
ENGLISH To search your favorite programme type 1 Press and hold T (TP/PTY) for more than 2 seconds while listening to an FM station. • If there is a station broadcasting a programme of the same PTY code as you selected, that station is tuned in. • If there is no station broadcasting a programme of the same PTY code as you selected, the station will not change. Note: In some areas, the PTY search will not work correctly. The last selected PTY code appears.
You can change the initial indication on the display to station name (PS NAME), station frequency (FREQ), or clock time (CLOCK) while listening to an FM RDS station. • See also “Changing the general settings (PSM)” on page 22. 1 Press and hold SEL (select) for more than 2 seconds so that one of the PSM items appears on the display. 2 Press ¢ or 4 to select “DISPMODE” (display mode). 3 Turn the control dial to set to the desired indication (“PS NAME,” “FREQ,” or “CLOCK”).
ENGLISH PTY codes NEWS: AFFAIRS: News Topical programmes expanding on current news or affairs INFO: Programmes which impart advice on a wide variety of topics SPORT: Sport events EDUCATE: Educational programmes DRAMA: Radio plays CULTURE: Programmes on national or regional culture SCIENCE: Programmes on natural science and technology VARIED: Other programmes like comedies or ceremonies POP M: Pop music ROCK M: Rock music EASY M: Easy-listening music LIGHT M: Light music CLASSICS: Classical music OTHER M:
ENGLISH CD OPERATIONS Playing a CD 1 The display changes to show the following: The CD–in indicator lights up. Open the control panel. Note on One-Touch Operation: When a CD is already in the loading slot, pressing CD turns on the unit and starts playback automatically. 2 Total track number of the inserted disc Insert a CD into the loading slot. The unit turns on, draws the CD and starts playback automatically. 3 Total playing time of the inserted disc Close the control panel by hand.
ENGLISH To stop play and eject the CD To go to a particular track directly Press 0. CD play stops and the control panel flips down. The CD automatically ejects from the loading slot. The source changes to the tuner (you will hear the last received station). • If you change the source, the CD play also stops (without ejecting the CD). Next time you select “CD” as the source, CD play starts from where playback has been stopped previously.
• Ex. 1: To select track number 32 while playing track number 6 You can play back the current track repeatedly. 1 Press M (MODE) to enter the functions mode while playing a CD. ENGLISH To play back tracks repeatedly (Track Repeat Play) How to use the +10 and –10 buttons 2 Press RPT (repeat), while (Three times) Track 6 (Twice) \ 10 \ 20 \ 30 \ 31 \ 32 • Ex.
ENGLISH SOUND ADJUSTMENTS Selecting preset sound modes (C-EQ: custom equalizer) You can select a preset sound mode (C-EQ: custom equalizer) suitable to the music genre. • There is a time limit in doing the following procedure. If the setting is canceled before you finish, start from step 1 again. 1 2 Press M (MODE) to enter the functions mode. Press EQ (equalizer), while still in the functions mode.
2 You can adjust the sound characteristics to your preference. 1 To increase the level or turn on the loudness To decrease the level or turn off the loudness Select the item you want to adjust. Each time you press the button, the adjustable items change as follows: TRE* 1 TRE (treble) FAD VOL LOUD BAL (loudness) (balance) To do: Adjust the bass. Ex. 1: When you adjust “TRE” (treble) Range –06 (min.) | +06 (max.) Adjust the treble. –06 (min.) | +06 (max.
ENGLISH OTHER MAIN FUNCTIONS Changing the general settings (PSM) You can change the items listed on the next page by using the PSM (Preferred Setting Mode) control. Basic Procedure 1 Press and hold SEL (select) for more than 2 seconds so that one of the PSM items appears on the display. (See page 23.) To select the level meter—LEVEL You can select the level display according to your preference. When shipped from the factory, “AUDIO 2” is selected. • AUDIO 1: Shows the audio level indicator.
• For detailed operations of each PSM items, refer to the pages listed in the table.
ENGLISH Selecting the display color Changing the standard plate This section is only for KD-SC800R. This section is only for KD-SC800R. You can select the color of the display according to your preference. When shipped from the factory, “ALL DEMO” is selected. You can change the standard plate with another plate supplied with your unit. You can also download them by visiting . • When changing the plate, be careful not to leave your fingerprints on the plate or cover.
Replace with another plate (a standard, cutout, or downloaded plate) of your preference. How to use the cutout plates 1 Unfold the supplied cutout plates. • When attaching a standard plate ENGLISH 3 Standard plate 2 Cut the plates out using a scissors. Plate cover • When attaching a cutout or downloaded plate Add the transparent plate (supplied) between the cutout or downloaded plate and the plate cover in order to attach the plate cover in place.
ENGLISH Detaching the control panel You can detach the control panel when leaving the car. When detaching or attaching the control panel, be careful not to damage the connectors on the back of the control panel and on the panel holder. Attaching the control panel 1 Insert the right side of the control panel into the groove on the panel holder. Detaching the control panel Before detaching the control panel, be sure to turn off the power. 1 Unlock the control panel.
USING THE REMOTE CONTROLLER 3. Return the battery holder. Insert again the battery holder by pushing it until you hear a clicking sound. (back side) ENGLISH This unit can be remotely controlled as instructed here (with an optionally purchased remote controller). We recommend that you use remote controller RM-RK50 or RM-RK60 with your unit. (Ex.: When you are using RM-RK60) Before using the remote controller: • Aim the remote controller directly at the remote sensor on the main unit.
ENGLISH Location of the buttons RM-RK60 3 Selects the preset stations while listening to the radio. Each time you press the button, the preset station number increases, and the selected station is tuned in. 4 Selects the sound mode (C-EQ: custom equalizer). Each time you press the button, the sound mode (C-EQ) changes. 5 Selects the band while listening to the radio. Each time you press the button, the band changes. 6 Selects the source. Each time you press the button, the source changes.
What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms Causes CD Playback FM/AM General • Sound cannot be heard from the speakers. Remedies The volume level is set to the minimum level. Adjust it to the optimum level. Connections are incorrect. Check the cords and connections. • This unit does not work at all. The built-in microcomputer may have functioned incorrectly due to noise, etc.
ENGLISH MAINTENANCE Handling discs When playing a CD-R or CD-RW This unit has been designed to reproduce CDs, CD-Rs (Recordable), and CD-RWs (Rewritable). • This unit is not compatible with MP3 discs. How to handle discs When removing a disc Center holder from its case, press down the center holder of the case and lift the disc out, holding it by the edges. • Always hold the disc by the edges. Do not touch its recording surface.
AUDIO AMPLIFIER SECTION CD PLAYER SECTION Maximum Power Output: Front: 45 W per channel Rear: 45 W per channel Continuous Power Output (RMS): Front: 17 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion. Rear: 17 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 0.8% total harmonic distortion.
