PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 1 Friday, October 17, 2003 11:43 AM Thank you for buying this JVC colour television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. WARNING Always use the power cords which are supplied with the TV and receiver. Some power cords are supplied with this TV.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 2 Friday, October 17, 2003 11:43 AM Burn-in A characteristic of Plasma Display Panels (PDPs) is that displaying the same image for a long time causes a part of the image to stay on the screen (this is called phosphor burn-in). Avoid burn-in as follows. Use the PICTURE SHIFT function. In order to prevent burn-in, the picture displayed on the screen is shifted up, down and to the left and right at regular intervals.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 3 Friday, October 17, 2003 11:43 AM Point defects PDPs use collections of fine pixels to display images. While there is no problem with more than 99.99% of these pixels, please understand that a very small number of pixels may not light or may light all the time. Do not install the TV near electronic equipment that is susceptible to electromagnetic waves It may cause interference in images, sound, etc.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 4 Friday, October 17, 2003 11:43 AM CONTENTS Checking contents of packages............5 Setting up your TV..................................6 Installation..........................................................6 Putting the batteries into the Remote control.....6 Connections............................................7 ENGLISH Connection diagram ...........................................7 Connecting the TV and receiver ..................
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 5 Friday, October 17, 2003 11:43 AM Checking contents of packages Check that all components are present. Contact your retailer immediately if any components are missing. ENGLISH Receiver TV AA/R6-size batteries (used to check operation) Remote control Mounting screw × 2 System cable Hook × 2 Power cord • The power cord from those below which is suitable to the area in which you live will be included with your TV.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 6 Friday, October 17, 2003 11:43 AM Setting up your TV Ensure to lift up the TV with more than 2 people. TV is too heavy to lift up by yourself and TV fall causes injuries and damage. Installation Depending on the model, the TV may come with a Wall Mounting Unit or Table Top Stand. In these cases, a separate instruction manual is provided in addition to this manual. Read that instruction manual and install the TV correctly.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 7 Friday, October 17, 2003 11:43 AM Connections Caution • Turn off all equipment (including the TV) before connecting anything. Connection diagram TV (back) ENGLISH DISPLAY INPUT CONNECT TO SYSTEM CABLE AC INPUT 110-240V Supplied system cable Cable supplied with TV • Refer to page 9 for connection details. Connecting antenna and other equipment • Refer to page 8 for connection details.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 8 Friday, October 17, 2003 11:43 AM Connections Connecting the TV and receiver Use the supplied system cable to connect the TV to the receiver. The two connectors are of different shapes. Ensure that the pins on connector 1 are oriented correctly, press the connector into the socket, and tighten the screws at left and right to lock it in place. Press connector 2 firmly into place until it is locked.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 9 Friday, October 17, 2003 11:43 AM Connections Connecting the power cord to the AC outlet Insert the AC plugs on the power cords from the TV and receiver into AC outlets. Caution Back of the TV AC INLET ENGLISH • Operate only from the power source specified (AC 110 – 240 V, 50/60 Hz) on the unit. • Failure to use the supplied power cord or to insert it into a correctly earthed outlet may result in electric shocks.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 10 Friday, October 17, 2003 11:43 AM Initial settings When the TV is first turned on, it enters the initial setting mode, and the JVC logo is displayed. Follow the instructions on the on-screen display to make the initial settings. VCR/TV/DVD Switch ENGLISH Yellow button Blue button • If the power lamp stays red and does not change to green: Your TV is in the standby mode. Press the # (Standby) button again to turn your TV on.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 11 Friday, October 17, 2003 11:43 AM Initial settings 6 Press the blue button to start the AUTO PROGRAM function The AUTO PROGRAM menu appears and received TV channels are automatically registered in the Programme numbers (PR). • To cancel the AUTO PROGRAM function: Press the b button.
PD-42DV2 (ASIA) / LCT1445-001A / English Body_Eng.fm Page 12 Tuesday, October 21, 2003 10:07 AM TV buttons and functions TV (front) Receiver (front) How to open the cover S VIDEO AUDIO L R IN(VIDEO-5) ENGLISH Refer to the pages in parentheses for details.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 14 Friday, October 17, 2003 11:43 AM Remote control buttons and functions Use the PR LIST: 1 Press the h (Information) button to display the PR LIST Pressing the h (Information) button changes the display as follows: ID 12 : 00 ENGLISH AV 01 02 03 04 05 06 07 08 09 TV -10 Use the o button: Press the o button to choose a VIDEO terminal.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 15 Friday, October 17, 2003 11:43 AM Remote control buttons and functions ZOOM function You can change the screen size according to the picture aspect ratio. Choose the optimum one from the following ZOOM modes. REGULAR: Use to view a normal picture (4:3 aspect ratio) as its original size is.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 16 Friday, October 17, 2003 11:43 AM Remote control buttons and functions Displaying the current time Using the PIP function You can display the Current Time on the screen. Press the h (Information) button to display the current time Pressing the h (Information) button changes the display as follows: You can view two pictures (Main-picture and sub-picture).
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 17 Friday, October 17, 2003 11:43 AM Remote control buttons and functions Cancelling the PIP function: Press the R button or b button. Using the MULTI-PICTURE function You can display multi-pictures that enable you to easily find a program you want to view. 1 Press the X button to display multi-pictures The channels are displayed in the channel number order. The multi-pictures will appear in multi-picture mode.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 18 Friday, October 17, 2003 11:43 AM Teletext function Basic operation Using the List Mode 1 Choose a TV channel with a teletext broadcast 2 Make sure to set the VCR/TV/DVD switch to the TV position. You can store the numbers of your favourite teletext pages in memory and call them up quickly using the colour buttons.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 19 Friday, October 17, 2003 11:43 AM Teletext function Sub-page Some teletext pages include sub-pages that are automatically displayed. 1 Choose a teletext page that includes sub-pages Sub-page numbers that can be viewed are automatically displayed at the top of the screen. Reveal Some teletext pages include hidden text (such as answers to a quiz). You can display the hidden text.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 20 Friday, October 17, 2003 11:43 AM Using the TV’s menu This TV has a number of functions you can operate using menus. To fully utilize all your TV’s functions, you need to understand the basic menu operating techniques fully. 3 Press the 6 buttons to choose a function • For details of the functions in the menus, see the following pages.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 21 Friday, October 17, 2003 11:43 AM PICTURE SETTING Refer to “Using the TV’s menu” (see page 20) for details of displaying the menu. PICTURE SETTING PICTURE MODE CONTRAST BRIGHT SHARP COLOUR TINT WHITE BALANCE BRIGHT MID BACK TV RESET OK D0014-EN You can choose one of three PICTURE MODEs to adjust the picture settings automatically. BRIGHT: Heightens contrast and sharpness.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 22 Friday, October 17, 2003 11:43 AM PICTURE FEATURES Refer to “Using the TV’s menu” (see page 20) for details of displaying the menu. PICTURE FEATURES DIGITAL VNR Super DigiPure COLOUR SYSTEM PULL DOWN 4:3 AUTO ASPECT COLOUR MANAGEMENT PIP AUTO AUTO AUTO ON BACK TV OK D1015-EN ENGLISH DIGITAL VNR The DIGITAL VNR function cuts down the amount of noise in the original picture.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 23 Friday, October 17, 2003 11:43 AM PICTURE FEATURES COLOUR SYSTEM PULL DOWN The colour system is chosen automatically. However, if the picture is not clear or no colour appears, choose the colour system manually. 1 Choose COLOUR SYSTEM. Then press the a button The sub-menu of the COLOUR SYSTEM function appears.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 24 Friday, October 17, 2003 11:43 AM SOUND SETTING Refer to “Using the TV’s menu” (see page 20) for details of displaying the menu. You can turn off the sound from the TV speakers; but you should only do this if an audio system is connected to the TV as a substitute for the TV speakers. SOUND SETTING STEREO/ BASS TREBLE BALANCE SPEAKER BBE CINEMA SURROUND A.H.B.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 25 Friday, October 17, 2003 11:43 AM SOUND SETTING HEADPHONE You need to use the HEADPHONE menu to adjust the volume of the headphones. The HEADPHONE menu can also be used to set whether or not sound comes from the TV speakers when the headphones are being used and to perform the settings for the sound coming from the headphones. ENGLISH 1 Press the 6 buttons to choose HEADPHONE.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 26 Friday, October 17, 2003 11:43 AM VIDEO SETTING Refer to “Using the TV’s menu” (see page 20) for details of displaying the menu. VIDEO SETTING VIDEO-1 VIDEO-3 VIDEO-2 VIDEO-5 VIDEO-4 TV BACK TV ID LIST OK D0020-EN ENGLISH ID LIST You can have a name corresponding to the devices connected for each VIDEO terminal. Giving a name to a VIDEO terminal makes the VIDEO terminal number appear on the screen, together with the name.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 27 Friday, October 17, 2003 11:43 AM FEATURES Refer to “Using the TV’s menu” (see page 20) for details of displaying the menu. FEATURES SLEEP TIMER BLUE BACK CHANNEL GUARD REFRESH PICTURE SHIFT OFF ON OFF To set the CHANNEL GUARD function 1 Choose CHANNEL GUARD, then press the o button “SET ID NO.” (ID number setting screen) appears. SET ID NO.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 28 Friday, October 17, 2003 11:43 AM FEATURES 3 Press the Number buttons to enter the ID number The lock is temporarily released so you can view the TV channel. If you have forgotten the ID number: Perform step 1 of “To set the CHANNEL GUARD function”. After confirming the ID number, press the b button to exit the menu.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 29 Friday, October 17, 2003 11:43 AM INSTALL Refer to “Using the TV’s menu” (see page 20) for details of displaying the menu. INSTALL LANGUAGE AUTO PROGRAM EDIT / MANUAL BACK TV OK 3 Press the a button to start the AUTO PROGRAM function The AUTO PROGRAM menu appears and received TV channels are automatically registered in the Programme numbers (PR). • To cancel the AUTO PROGRAM function, press the b button.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 30 Friday, October 17, 2003 11:43 AM INSTALL 2 Follow the operation description of a function you want to use and operate the function 2 Press the red button to start the ID function EDIT MOVE: This function changes a Programme number (PR) of a TV channel. ID: This function registers a Channel name (ID) to a TV channel.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 31 Friday, October 17, 2003 11:43 AM INSTALL 4 Press the Number buttons to enter the remaining CH/CC number The TV shifts to registration mode. When the registration is completed, the picture of the TV channel appears on the screen. • The CH/CC number is a number indicating the broadcast frequency to the TV.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 32 Friday, October 17, 2003 11:43 AM INSTALL Changing the TELETEXT LANGUAGE setting After the AUTO PROGRAM function is completed, you can change the country you have already set by using the AUTO PROGRAM function. 1 Display the INSTALL menu ENGLISH When the EDIT menu is currently being displayed: Press the h (Information) to return to the INSTALL menu. 2 Press the 6 buttons to choose AUTO PROGRAM.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 33 Friday, October 17, 2003 11:43 AM Additional preparation Connecting the external devices Connect the devices to the TV, paying attention to the following connection diagram.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 34 Friday, October 17, 2003 11:43 AM Additional preparation Connecting devices to the OUT terminal The signals of the images and sound you are currently viewing with this TV are output through the OUT terminal. By connecting a VCR to the OUT terminal, you can record the currently shown image and sound to that VCR. To do this, connect the VCR and OUT terminal following the steps below.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 35 Friday, October 17, 2003 11:43 AM CH/CC numbers When you want to use the INSERT function on page 30, find the CH/CC number corresponding to the Channel number of the TV channel from this table. US: The US channel numbers are the channel numbers used in the United States, Philippines, etc. CCIR: The CCIR channel numbers are the channel numbers used in the Middle East, Southeast Asia, etc.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 36 Friday, October 17, 2003 11:43 AM Troubleshooting If a problem arises while you are using the TV, please read this “Troubleshooting” well before you request having the TV repaired. You may be able to fix it easily by yourself. For example, if the AC plug is disconnected from the AC outlet, or the TV aerial has problems, you may think there is a problem with the TV itself.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 37 Friday, October 17, 2003 11:43 AM Troubleshooting Other concerns ENGLISH • When the SLEEP TIMER function operates, the TV is automatically turned off. If the TV is turned off suddenly, try to press the # (Standby) button to turn on the TV once again. At this time, if the TV resumes a normal state, there is no problem.
PD-42DV2 (ASIA) / LCT1445-001A / English PD-42DV2_Eng.book Page 38 Friday, October 17, 2003 11:43 AM Specifications Item Model PD-42DV2 Broadcasting systems B, G, I, D, K, K1, M Colour systems PAL, SECAM, NTSC 3.58/4.43 MHz Channels and frequencies VHF low channel (VL) =46.25 to 168.25 MHz VHF high channel (VH) =175.25 to 463.25 MHz UHF channel (U) =471.25 to 855.25 MHz • Receives cable channels in mid band (X to Z+2, S1 to S10), super band (S11 to S20) and hyper band (S21 to S41).
