MICRO COMPONENT MD SYSTEM UX-Z7MD —Consists of CA-UXZ7MD and SP-UXZ7MD — CA-UXZ7MD SP-UXZ7MD TA/News/Info INSTRUCTIONS For Customer Use: Enter below the Model No. and Serial No. which are located either on the rear, bottom or side of the cabinet. Retain this information for future reference. Model No. Serial No. LVT0900-004A [UB] UX-Z7MD[UB]Cover_f 1 02.6.
Warnings, Cautions and Others Caution— button! Disconnect the mains plug to shut the power off completely. The button in any position does not disconnect the mains line. The power can be remote controlled. – G-1 – UX-Z7MD[UB]Safety_f 1 02.6.
English CAUTION To reduce the risk of electrical shocks, fire, etc.: 1. Do not remove screws, covers or cabinet. 2. Do not expose this appliance to rain or moisture. CAUTION • Do not block the ventilation openings or holes. (If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.) • Do not place any naked flame sources, such as lighted candles, on the apparatus.
Caution: Proper Ventilation To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows: 1 Front: No obstructions and open spacing. 2 Sides/ Top/ Back: No obstructions should be placed in the areas shown by the dimensions below. 3 Bottom: Place on the level surface. Maintain an adequate air path for ventilation by placing on a stand with a height of 10 cm or more.
English IMPORTANT FOR LASER PRODUCTS / REPRODUCTION OF LABELS / 1 CLASSIFICATION LABEL ON EXTERIOR SURFACE CLASS LASER 1 PRODUCT 2 WARNING LABEL INSIDE THE UNIT CAUTION: Invisible laser radiation when open and interlock failed or defeated. AVOID DIRECT EXPOSURE TO BEAM. (e) ADVARSEL: Usynlig laserstråling ved åbning, når sikkerhedsafbrydere er ude af funktion. Undgå udsættelse for stråling (d) VARNING: Osynlig laserstrålning när denna del är öppnad och spärren är urkopplad. Betrakta ej strålen.
English Introduction We would like to thank you for purchasing one of our JVC products. Before operating this unit, read this manual carefully and thoroughly to obtain the best possible performance from your unit, and retain this manual for future reference. About This Manual Power sources This manual is organized as follows: • When unplugging the unit from the wall outlet, always pull the plug, not the AC power cord.
Location of the Buttons .................................. 3 Recording ...................................................... 33 Main Unit ............................................................... 3 Remote Control ...................................................... 5 Before You Start Recording on an MD ................ 34 Setting MD Recording Modes ............................. 36 Recording CD onto an MD—CD Synchronized Recording .......................................................
English Location of the Buttons Become familiar with the buttons on your unit. Main Unit 1 2 e 3 4 5 6 r t y u 7 p i o ; a q s w d 8 9 f g Main unit See pages in the parentheses for details. 1 2 3 4 5 6 7 8 9 Disc tray (20) Display window (4) REV.MODE button (25, 30, 39, 40) MD 0 (eject) button (11, 24, 26, 58) • Pressing this button also turns on the unit. MD #¥8 (play/pause) button (11, 13, 24) • Pressing this button also turns on the unit.
English Display window on the electronic swing panel 1 2 3 45 6 7 8 9 0 - = ~ ! Display window See pages in the parentheses for details.
English Remote Control t y 1 u i 2 o 3 ; 4 a 5 6 s d f 7 8 9 p q w e r g h j k 1 Number buttons • 1 – 10, 0 and +10 buttons (12, 18, 21, 25, 26, 44 – 46, 52 – 55) • Character entry buttons (A – Z, 0 – 9) (28, 57) • MARK button (28, 57) and buttons (15, 28, 52, 56 – 58) • 2 TITLE/EDIT button (52 – 56) button (27, 45 – 50) 3 GROUP SKIP 4 GROUP TITLE/EDIT button (44 – 50, 56) button (27, 45 – 50) 5 GROUP SKIP 6 LP: button (36) 7 PLAY MODE button (21, 22, 25 – 27) 8 REPEAT button (22, 27) 9 CLOCK
Continued Unpacking To connect an outdoor FM antenna Before connecting it, disconnect the supplied FM antenna. After unpacking, check to be sure that you have all the following items. The number in the parentheses indicates the quantity of the pieces supplied. • • • • Outdoor FM antenna (not supplied) FM antenna (1) AM loop antenna (1) Remote control (1) Batteries (2) If any is missing, consult your dealer immediately.
English Connecting Speakers AM antenna To connect speakers 1 You can connect the speakers using the speaker cords. 1 2 2 Vinyl-covered wire (not supplied) 3,4 Speaker terminals Black 3 SPEAKERS Red CAUTION: R L R L SPEAKER IMPEDANCE 4~16Ω Black AM loop antenna (supplied) 1 If cords are covered with insulation, twist the core of the cord at the end of each cord, then remove the insulation. 2 Connect the AM loop antenna to the AM LOOP terminals as illustrated.
Connecting External Equipment To remove the speaker grilles The speaker grilles are removable as illustrated below: You can connect another equipment which can be used as a playback device. Holes Projections When you connect and use the equipment, refer also to its manual supplied. • DO NOT connect other equipment while the power is on. • DO NOT plug in any equipment until all connections are complete.
English Putting the Batteries into the Remote Control NOW, you can plug in the unit and other connected equipment FINALLY! Insert the batteries—R6P(SUM-3)/AA(15F)—into the remote control, by matching the polarity (+ and –) on the batteries with the + and – marking on the battery compartment. When the remote control can no longer operate the unit, replace both batteries at the same time.
The buttons emphasized in the illustration below are used and explained in this section (pages 11 to 15). Remote control Main unit – 10 – EN10-15UX-Z7MD[UB]f 10 02.6.
English Turning On the Power Setting the Auto Power Off When you press one of the source selecting buttons, the unit automatically turns on (and starts playback if the source is ready). Using Auto Power Off function, the unit automatically turns itself off if no sound comes in for more than 3 minutes except when FM or AM is selected as the source. If any operation is done during this 3-minute period, Auto Power Off is canceled temporarily even though no sound comes in.
English Setting the Clock When you unplug the AC power cord or if a power failure occurs The clock loses the setting and is reset to “0:00.” If this happens, set the clock again. You can set the clock whether the unit is turned on or in standby mode. On the remote control ONLY: 1 Press CLOCK/TIMER. To turn off the clock indication (power save mode) “0:00” appears in the main display with the hour digit flashing. Press DISP/CHARA while the unit is in standby mode.
English Selecting the Sources and Starting Play Adjusting the Volume To select the tuner or external equipment as the source On the remote control: Press FM/AM/AUX. You can adjust the volume level only while the unit is turned on. • The volume level has no effect on recording. The unit automatically turns on (when the unit is in standby), and the last selected source appears in the main display.
English Reinforcing the Bass Sound Selecting the Sound Modes The richness and fullness of the bass sound is clearly maintained regardless of how low you set the volume —Active Hyper Bass Pro. • This effect does not affect recording. You can use this effect only for playback. • This function also effects the sound from headphones. You can select one of the 4 preset sound modes. • This effect does not affect recording. You can use this effect only for playback.
English Setting the Display Illumination To create your favorite colors To select the illumination color You can create two favorite colors and store them in memory as “MANUAL1” and “MANUAL2.” • There is a time limit in doing the following steps. If the unit exits from the color adjusting mode before you finish, start from step 1 again. You can select the illumination color by your preference.
The buttons emphasized in the illustration below are used and explained in this section (pages 17 and 18). Remote control Main unit – 16 – EN16-18UX-Z7MD[UB]f 16 02.6.
English To stop during searching, press ¢ or 4 (or UP or DOWN on the main unit). Setting the AM Tuner Interval Spacing Some countries space AM stations 9 kHz apart, and some countries use 10 kHz spacing. When shipped, the built-in AM tuner is set to 9 kHz spacing. You can change it to 9 kHz or 10 kHz spacing. When you repeatedly press ¢ or 4 (or UP or DOWN on the main unit) The frequency changes step by step.
English Presetting Stations When you unplug the AC power cord or if a power failure occurs The FM and AM preset stations will be erased in a day. If this happens, preset the stations again. You can preset 30 FM and 15 AM stations manually. In some cases, test frequencies have been already memorized for the tuner since the factory examined the tuner preset function before shipment. This is not a malfunction. You can preset the stations you want into memory by following the presetting method.
English Playing Back CDs (CD-R/CD-RW) The buttons emphasized in the illustration below are used and explained in this section (pages 20 to 22). Remote control Main unit – 19 – EN19-22UX-Z7MD[UB]f 19 02.6.
Playing Back the Entire CD—Normal Play This unit has been designed to play back discs bearing the following logos: 1 Press CD 0 on the main unit. The unit automatically turns on, the electronic swing panel slides downward, then the disc tray comes out. Audio CD CD Recordable (CD-R) Disc tray CD ReWritable (CD-RW) Electronic swing panel In addition to the above discs, this unit can play back audio data recorded on CD Text, CD-G (CD Graphics), and CD-Extra.
English Basic CD Operations While playing a disc, you can do the following operations. To stop playback for a moment Press CD 3/8. The CD indicator and the elapsed playing time start flashing on the display. • When the key-touch tone is activated (see page 11), the unit keeps beeping while pausing. To resume playback, press CD 3/8 again. Programing the Playing Order of the Tracks —Program Play You can arrange the order in which the tracks play before you start playing. You can program up to 32 tracks.
English 4 Press CD 3/8. To check the program contents The tracks are played at random. Random play ends when all the tracks are played once. Before playing, you can check the program contents by pressing ¢ or 4. • ¢: Shows the programed tracks in the programed order. • 4: Shows them in the reverse order. To skip the current track, press ¢. • You cannot go back to the previous tracks by pressing 4.
English Playing Back MDs The buttons emphasized in the illustration below are used and explained in this section (pages 24 to 28). Remote control Main unit – 23 – EN23-28UX-Z7MD[UB]f 23 02.6.
Playing Back the Entire MD—Normal Play While the unit is pulling in the MD: • DO NOT press MD 0. • DO NOT close the electronic swing panel by force. 1 Press MD 0 on the main unit. The unit automatically turns on, the electronic swing panel slides upward, then the MD loading slot appears. • If an MD is already in the MD loading slot, it will be ejected. 2 Insert an MD into the MD loading slot. The MD is pulled in, then the electronic swing panel slides downward automatically.
English To go to another track About MD indicator Press ¢ or 4 repeatedly. • ¢: Skips to the beginning of the next or succeeding tracks. • 4: Goes back to the beginning of the current or previous tracks. An MD is loaded To go to another track directly using the number buttons During playback During pause To prohibit disc ejection—Disc Lock You can prohibit disc and MD ejection from the unit and can lock discs.
English 4 Press the number buttons to select the tracks. • For how to use the number buttons, see “To go to another track directly using the number buttons” on the previous page. PRGM indicator Step No. If you try to program a 33rd step “MEMORY FULL” will appear in the main display. If the total playing time is 150 minutes or more The total playing time will not be shown. (“– – : – –” will appear.) Playing at Random—Random Play Total playing time The last programed track No. Ex.
English Playing Tracks in a Group—Group Play To go to another group, press GROUP SKIP or GROUP SKIP repeatedly during Group play. • GROUP SKIP : Skips to the first track in the next or succeeding groups. • GROUP SKIP : Goes back to the first track in the current or previous groups. You can play back tracks in a group. • To make or edit groups, see pages 42 to 50. On the remote control ONLY: 1 Load an MD including a group(s). 2 Press MD 3/8, then 7. To stop during play, press 7.
2) Press the character entry button for a character you want to enter. Ex.: • To enter an “A” or “a,” press ABC once. To enter a “B” or “b,” press ABC twice. To enter a “C” or “c,” press ABC three times. • To enter a symbol, press MARK repeatedly until the mark you want appears. • To enter a numeral, press 0 – 9. • To enter a space while entering a title, press twice. • To move the character entry position while entering a title, press or .
English Playing Back Tapes The buttons emphasized in the illustration below are used and explained in this section (page 30). Remote control Main unit – 29 – EN29-32UX-Z7MD[UB]f 29 02.6.
To fast-wind to the left, press 4. You can play back type I tapes. To fast-wind to the right, press ¢. 1 Push ) (PUSH OPEN). To remove the cassette, push ) (PUSH OPEN). The cassette holder opens. DO NOT push ) (PUSH OPEN) during tape play. ) (PUSH OPEN) To play both sides—Reverse mode You can set the deck to play just one side or both sides of a tape once, or both sides continuously. Press REV.MODE.
English Listening to External Equipment The buttons emphasized in the illustration below are used and explained in this section (page 32). Remote control Main unit – 31 – EN29-32UX-Z7MD[UB]f 31 02.6.
listening level. You can listen to external equipment connected to the AUX/DVD jacks on the rear of the unit. • First make sure that the external equipment is properly connected as follows: DO NOT connect other equipment while the power is on. 5 Apply sound effects, if you wish. • For how to apply sound effects, see page 14.
English Recording The buttons emphasized in the illustration below are used and explained in this section (pages 34 to 40). For recording operations, you mainly use the buttons on the main unit. Main unit Remote control – 33 – EN33-40UX-Z7MD[UB]f 33 02.6.
English Before You Start Recording on an MD • It may be unlawful to record or play back copyrighted material without the consent of the copyright owner. • When you record onto partially recorded MD, its contents are not erased or overwritten. The recording starts from the point following the last recorded track of the MD. If you want to record on such an MD from the beginning, you have to erase its contents first (see “Erasing All Tracks —ALL ERASE” on page 55).
English Stereo Long-Hour Recording (MDLP) On conventional MD recorders, 2 times long-hour recording on MDs has been possible only in monaural sound, but this unit allows for 2 times or 4 times longhour recording without losing stereo sound. With this feature, songs (tracks) can be recorded on a single MD using different recording length modes—SP: Standard Play, LP2: 2 Times Long Play, LP4: 4 Times Long Play. SP: Signifies standard-hour stereo recording.
Setting MD Recording Modes Before recording on MDs, set the recording length mode (SP/LP2/LP4), “LP:”-prefix addition mode, and the group recording mode. On the remote control ONLY: Recording CD onto an MD—CD Synchronized Recording Using the CD synchronized recording method, you can start and stop CD play and MD recording at the same time. 1 Prepare a disc. To set the recording length mode After placing a disc, press CD 3/8, then 7 before going to the next step.
English 2 Insert a recordable MD into the MD loading slot. To record a single track during play or pause • Set the MD recording length mode, “LP:”-prefix addition mode, and Group recording mode (see “Setting MD Recording Modes” on page 36). On the main unit ONLY: While playing back or pausing a track you want to record, press ONE TOUCH MD REC. The playback of the track is stopped, and the same track starts playing from the beginning again. This time, the MD recorder starts recording the track.
English Before You Start Recording on a Tape • It may be unlawful to record or play back copyrighted material without the consent of the copyright owner. • The recording level is automatically set correctly, so it is not affected by the volume level. Thus, during recording you can adjust the sound you are actually listening to without affecting the recording level. • While recording, you can hear sound mode effect and/or the AHB PRO (Active Hyper Bass PRO) effect through the speakers or headphones.
English 4 Press ONE TOUCH TAPE REC on the main unit. Recording onto a Tape The recording starts and the REC indicator starts flashing on the display. • When you select a track by pressing ¢ or 4 before pressing ONE TOUCH TAPE REC, recording starts from the selected track (except when Program play mode is selected). • When recording an external equipment, start playback after “AUX = TAPE” appears in the main display. You can use only type I tapes for recording. 1 Prepare the source to record.
To record a single track during play or pause On the main unit ONLY: 1 Prepare a disc. While playing back or pausing a track you want to record, press MD&TAPE REC. The playback of the track is stopped, and the same track starts playing from the beginning again. This time, the MD recorder and cassette deck start recording the track. • After the track is recorded, both playback and recording stop automatically.
English Editing MDs The buttons emphasized in the illustration below are used and explained in this section (pages 42 to 58). Remote control Main unit – 41 – EN41-50UX-Z7MD[UB]f 41 02.6.
English Guidance—MD Group Functions To add to the conventional MD Editing functions (called the track editing functions in this manual), MD Group functions help you to classify the tracks by making groups on your MD. Classifying the tracks on an MD MDLP enables you to record more tracks on a single MD than usual. So, there are many tracks which have been recorded from the various sources—CDs, FM, and so on—on your MD. Track No.
English Introducing Group Editing Functions The groups and tracks can be edited in many ways (Group editing functions and Track editing functions). From this page to page 50, the group editing functions are explained. For details on the track editing functions, see pages 51 to 55. Forming a group (FORM GR): Page 44 This function forms a series of tracks or a single track into a new group. Moving a group (MOVE GR): Page 48 This function moves the selected group by reordering the group and track numbers.
English 5 Press SET. Forming a Group—FORM GR This function allows you to form a group from a series of tracks which do not belong to the other groups. You can form a group from a single track. Once a new group is formed, the other groups are renumbered. • You can form up to 99 groups on a single MD. • To stop any time during the editing process before step 8, press GROUP TITLE/EDIT. • If the selected first track belongs to another group, “GROUP TRACK” appears in the main display.
English 5 Press SET. Adding a Track to a Group—ENTRY GR This function allows you to enter a track into a group. The track will be added as the last track in the selected group. The track numbers will be renumbered. • To stop any time during the editing process before step 8, press GROUP TITLE/EDIT. • If the loaded MD has no group, you cannot go to the following steps. • When the selected track belongs to a group, its group number appears in the main display.
point. The track selected in this step will be the first track in the divided group. • You can select the track using the number buttons. In this case, the selected track starts playback repeatedly. This function allows you to divide one group into two separate groups. You cannot divide the group containing only a single track. When the original group has a title, two separate groups are reassigned the same title as the original group. Once a new group is divided, the other groups are renumbered.
English 5 Press SET. Joining Two Groups—JOIN GR This function allows you to join two adjacent groups into a single group. When the groups have their own titles, the title of the preceding group is reassigned to the joined group. Once two groups are joined, the other groups are renumbered. • To stop any time during the editing process before step 6, press GROUP TITLE/EDIT. • To cancel the setting, press CANCEL, then repeat from step 4. 6 Press ENTER.
English 5 Press SET. Moving a Group—MOVE GR This function allows you to move a group. Once a group is moved, the tracks and the other groups are renumbered. • To stop any time during the editing process before step 8, press GROUP TITLE/EDIT. • To cancel the setting, press CANCEL, then repeat from step 4. 6 Press GROUP SKIP On the remote control ONLY: or GROUP SKIP to select the position where you want to move the group.
English 5 Press SET. Ungrouping Tracks—UNGROUP This function allows you to dissolve a group. You cannot erase the tracks using this function. Once tracks are ungrouped, the other groups are renumbered. • To stop any time during the editing process before step 6, press GROUP TITLE/EDIT. On the remote control ONLY: • To cancel the setting, press CANCEL, then repeat from step 4. 6 Press ENTER.
or GROUP SKIP select the group you want to erase. This function allows you to erase a group together with tracks in the group. You cannot resume the tracks in the erased group. Once a group is erased, the other tracks and groups are renumbered. • To stop any time during the editing process before step 6, press GROUP TITLE/EDIT. On the remote control ONLY: to Ex.: When group 6 is selected 5 Press SET. In the following example, the process is explained from the very first—that is, inserting a disc.
English Introducing Track Editing Functions The groups and tracks can be edited in many ways (Group editing functions and Track editing functions). From this page to page 55, the track editing functions are explained. For details on the group editing functions, see pages 43 to 50. Dividing a track (DIVIDE): Page 52 This function divides a track by adding a track mark(s) in the desired point(s) in the middle or where you want to search for later.
to divide the track. “POSIT. (position) 0” appears in the main display, and the unit repeats the selected point—a 3-second period following the dividing point. This function allows you to divide one track into two separate tracks. It is useful, for example, when you want to add track marks at a certain point within a track or if you want to separate a recording. When the original track has a title, two separate tracks are reassigned the same title as the original track.
English 5 Press SET. Joining Two Tracks—JOIN This function allows you to join two adjacent tracks into one track. When the tracks have their own titles, the title of the preceding track is reassigned to the joined track. Once two tracks are joined, the other tracks and/or the groups are renumbered. • To stop any time during the editing process before step 6, press TITLE/EDIT. • To cancel the setting, press CANCEL, then repeat from step 4. 6 Press ENTER.
English 5 Press SET. Moving a Track—MOVE This function allows you to move a track to the position you prefer. It is useful to change the order of the tracks as you like. Once a track is moved, the tracks and/or the groups are renumbered. • To stop any time during the editing process before step 8, press TITLE/EDIT. On the remote control ONLY: • To cancel the setting, press CANCEL, then repeat from step 4. 6 Press ¢ or 4 to select the position where you want to move the track.
English 6 Repeat steps 4 and 5 to select all the tracks you want Erasing Tracks—ERASE This function allows you to erase unwanted tracks. You cannot resume the erased tracks. Once tracks are erased, the other tracks and/or groups are renumbered. You can erase up to 15 tracks at a time. • To stop any time during the editing process before step 8, press TITLE/EDIT. On the remote control ONLY: In the following example, the process is explained from the very first—that is, inserting a disc.
1 Insert an MD you want to edit into the MD loading Assigning Titles to an MD slot. You can assign a name to each MD, to each group and to each track using alphabetic characters (uppercase and lowercase), symbols and numerals. Once a title is assigned, it is displayed for your confirmation. • You cannot edit titles composed of more than 64 characters. About the number of characters entered for an MD The total number of characters that you can enter for an MD is 1792.
English 6 Press ENTER to finish the current title entry. 5 Enter characters. The next title entry screen appears. • For the disc title: The track title entry screen for the track 1 appears. • For the track title: The next track title entry screen appears (or the unit exits from the title entry screen if the current track is the last one on the disc). • For the group title: The next group title entry screen appears (or the same screen still remains if the current group is the last one on the disc).
You can assign titles during play or recording • During play: Entering a track title The MD recorder repeats playback of the current track until you press ENTER in step 6 above. When you press ENTER, the next track will be played. Entering a disc title The MD recorder repeats playback of all tracks of the MD until you press ENTER in step 6 above. When you press ENTER, the MD recorder enters the track title entry mode.
English Using the Timers The buttons emphasized in the illustration below are used and explained in this section (pages 60 to 63). Remote control Main unit – 59 – EN59-63UX-Z7MD[UB]f 59 02.6.
There are three timers available—Recording Timer, Daily Timer and Sleep Timer. 3 Select the source to record. 1) Press ¢ or 4 repeatedly to select the source. • Each time you press the button, the source changes as follows: • Before using these timers, make sure the built-in clock is set correctly (see page 12). • When using the tuner as the source, preset stations in advance (see page 18). AM FM AUX • When you select “FM” or “AM,” press SET, then select a preset number by pressing ¢ or 4.
English 6 Set the timer-off time. Using Daily Timer 1) Press ¢ or 4 repeatedly to adjust the hour. You can adjust the hour using the number buttons. 2) Press SET. The minute digit starts flashing. 3) Press ¢ or 4 repeatedly to adjust the minute. You can adjust the minute using the number buttons. With Daily Timer, you can wake up to your favorite music or radio program. • You can set Daily Timer whether the unit is turned on or in standby mode.
6 Adjust the volume level. 1) Press ¢ or 4 repeatedly to select the source. • Each time you press the button, the source changes as follows: FM AM AUX TAPE English 3 Select the source to play back. 1) Press ¢ or 4 repeatedly to adjust the volume level. • You can adjust the volume level to “– –” or within the range of 0 (silent) to 40 (maximum). • When you select “VOLUME – –,” the volume is set to the current volume level. CD MD • You can also use the source selecting buttons.
English Using Sleep Timer To sleep with the Sleep Timer and wake up with the Daily Timer With Sleep Timer, you can fall asleep to your favorite music. • You can set Sleep Timer when the unit is turned on. The unit turns off when the shut-off time comes (set by the Sleep Timer), and turns on when the timer-on time (set by the Daily Timer) comes. How Sleep Timer actually works 1 2 The unit automatically turns off after the specified time length passes.
English Maintenance To get the best performance of the unit, keep your discs, tapes and mechanism clean. Handling MDs General Notes • Do not open the shutter. - The shutter is locked so that it will not open. Trying to force it open will break the MD. If the shutter opens accidentally, close it again quickly without touching the MD inside. In general, you will have the best performance by keeping your CDs, MDs and the mechanism clean.
English Additional Information MD Disc Types There are two types of MDs: Premastered (prerecorded) and Recordable (blank). Premastered MDs Premastered MDs, which have been recorded at music studio, can be played back like regular CDs. On an MD of this type, data is recorded as the presence or absence of tiny pits. A laser beam focuses on the pits on the surface of the MD and reflects the detection back to the lens in the MD recorder. The MD recorder then decodes the signals and plays them back as music.
English SCMS (Serial Copy Management System) The MD recorder integrated to this unit uses the Serial Copy Management System which allows only first-generation digital copies to be made of premastered software (like CDs or prerecorded MDs). 1st Generation ABCDEFG 2nd Generation ABCDEFG CD-R/RW CD HCMS (High-speed Copy Management System) Now onto recordable MDs (minidiscs), you can record (copy) sound at a recording speed exceeding the normal speed.
English CD/MD Messages For CD: Message Signification CANNOT PLAY CD NO DISC Solution You are trying to play back a CD which Change the CD. cannot be played or there is a problem with the CD. • No disc is on the disc tray. • Place a disc on the disc tray. • You are trying to play back a • This is not a malfunction. You can CD-R/RW which has not been play back “finalized” CD-R/RWs. “finalized.” You are trying to record a CD onto a MD and a tape at the same time using x2 or x4 speed recording.
English Message Signification EMERGENCY STOP Solution A malfunction has occurred during recording. Stop playback, and eject the MD and re-insert it. You are trying to form over 99 groups. This is not a malfunction. There can be up to 99 groups on an MD. You are trying to make a group by including a track which belongs to another group. This is not a malfunction. (See “Forming a Group—FORM GR” on page 44.) An internal timer works to protect copyrights.
English Troubleshooting If you are having a problem with your unit, check this list for a possible solution before calling for service. If you cannot solve the problem from the hints given here, or the unit has been physically damaged, call a qualified person, such as your dealer, for service. Symptom No sound is heard from the speakers. Unable to record on an MD. Poor radio reception. Possible Cause • Connections are incorrect or loose. • • A pair of headphones is connected.
Specifications 46 W (23 W + 23 W) at 4 Ω (MAX.) 40 W (20 W + 20 W) at 4 Ω (10 % THD) Audio input sensitivity/Impedance (at 1 kHz) AUX/DVD: 400 mV/47 kΩ (at “LEVEL 1”) 200 mV/47 kΩ (at “LEVEL 2”) Output Power (IEC 268-3/DIN): Speaker Terminals: 4 Ω – 16 Ω Tuner FM tuning range: AM tuning range: 87.50 MHz—108.
VICTOR COMPANY OF JAPAN, LIMITED V EN, CS UX-Z7MD[UB]Cover_f J 2 02.6.
