DV300H-JN.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. WARNING: Do not install this equipment in a confined space such as a bookcase or similar unit. CAUTION: Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
CAUTION: • • • The STANDBY/ON button does not completely shut off mains power from the unit, but switches operating current on and off. When moving the product, press STANDBY/ON to turn off the power, and wait at least 30 seconds before unplugging the power cord. Then, wait at least 2 minutes before moving the product. When discarding batteries, environmental problems must be considered and the local rules or laws governing the disposal of these batteries must be followed strictly.
Contents Introduction . . . . . . . . . . . . . . . . . .5-8 About the Symbol Display . . . . . . . . . . . . .5 Symbol Used in this Manual . . . . . . . . . . . . . .5 Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . .5 Handling Discs . . . . . . . . . . . . . . . . . . . . . . .5 Storing Discs . . . . . . . . . . . . . . . . . . . . . . . .5 Cleaning Discs . . . . . . . . . . . . . . . . . . . . . . .5 Types of Playable Discs . . . . . . . . . . . . . . . . .6 Regional Code . . . . . . . . .
Introduction Notes on Discs Introduction To ensure proper use of this product, please read this owner’s manual carefully and retain it for future reference. Handling Discs This manual provides information on the operation and maintenance of your DVD player. Should the unit require service, contact an authorized service location. Symbol Display Symbol Used in this Manual After playing, store the disc in its case.
Types of Playable Discs DVD (8 cm / 12 cm disc) Video CD (VCD/SVCD) (8 cm / 12 cm disc) Audio CD (8 cm / 12 cm disc) In addition, this unit plays DVD±R/RW and CD-R/RW, Dual disc that contains audio titles, MPEG4, MP3, WMA, and/or JPEG files. This indicates a product feature that is capable of playing DVD-RW discs recorded with Video Recording format.
a b c d e f g h i a 1/' STANDBY/ON Switches the unit ON and OFF. f N (PLAY) Starts playback. b Disc Tray Insert a disc here. g x (STOP) Stops playback. c Z (OPEN/CLOSE) Opens or closes the disc tray. h . (SKIP) Returns to the beginning of current chapter or track or go to the previous chapter or track. Press and hold the button for search backward. d Display window Shows the current status of the unit. e Remote Sensor Point the remote control here.
Remote Control 1/') STANDBY/ON (1 Switches DVD Player ON and OFF. OPEN/CLOSE (Z) Opens and closes the disc tray. DISPLAY Accesses On-Screen Display. DVD MENU Accesses menu on a DVD disc. b / B / v / V (left/right/up/down) Selects an item in the menu. PAUSE/STEP ( X ) Pauses playback temporarily/ press repeatedly for frame-by-frame playback. SKIP (. / >) Go to next chapter or track. Returns to the beginning of current chapter or track or go to the previous chapter or track.
Installation and Setup DVD Player Connections Depending on your TV and other equipment there are various ways you can connect the player. Please refer to the manuals of your TV, stereo system or other devices as necessary for additional connection information. Rear of TV Introduction The picture and sound of a nearby TV, VCR, or radio may be distorted during playback. If this occurs, position the player away from the TV, VCR, or radio, or turn off the unit after removing the disc.
HDMI connection If you have an HDMI TV or a monitor, you can connect it to this player using an HDMI cable. HDMI compatible TV 1. Set the TV’s source to HDMI (refer to TV Owner’s manual). 2. Connect the HDMI OUTPUT jack on the unit to the HDMI jack on a HDMI compatible TV or monitor (H). 3. Press RESOLUTION repeatedly to select the desired resolution. Notes: • Both PCM and Bitstream Audio out is available when the sample frequency is set to 48kHz in HDMI connection.
Rear of DVD Player Introduction Connect the DVD player to your optional equipment for audio output. Amplifier equipped with 2-channel analog stereo or Dolby Pro Logic ll / Pro Logic: Connect the left and right AUDIO OUTPUT jacks on the DVD player to the audio left and right IN jacks on your amplifier, receiver, or stereo system, using the audio cables (A).
When you turn on for the first time The menu for a language selection will appear when you turn on the unit for the first time. You must select a language to use the unit. Use b / B / v / V to select a language then press ENTER and the confirm menu will appear. Use b / B to select [Enter] then press ENTER. Displaying Disc Information on-screen You can display various information about the disc loaded on-screen.
DISPLAY Menu Language TV Aspect 4:3 – Select when a standard 4:3 TV is connected. 16:9 – Select when a 16:9 wide TV is connected. Disc Audio / Subtitle / Menu Display Mode Select the language you prefer for the audio track (disc audio), subtitles, and the disc menu. The Display Mode setting works only when the TV Aspect mode is set to 4:3. Original – Refers to the original language in which the disc was recorded.
AUDIO Sample Freq. (Frequency) Each DVD disc has a variety of audio output options. Set the player’s AUDIO options according to the type of audio system you use. If your receiver or amplifier is NOT capable of handling 96 kHz signals, select 48 kHz. When this choice is made, this unit automatically converts any 96 kHz signals to 48 kHz so your system can decode them. If your receiver or amplifier is capable of handling 96 kHz signals, select 96 kHz.
Installation and Setup Introduction OTHERS PBC Set Playback Control (PBC) to On or Off. On: Video CDs with PBC are played according to the PBC. Off: Video CDs with PBC are played in the same way as Audio CDs. B.L.E. (Black Level Expansion) To select the black level of playback pictures. Set your preference and monitor’s ability. On: Expanded grey scale. (0 IRE cut off) Off: Standard grey scale. (7.5 IRE cut off) Note: Reference Operation The B.L.E. function works NTSC system only.
Operation General Features Discs Buttons Operations OPEN/CLOSE (Z) Opens or closes the disc tray. ALL PAUSE/STEP (X) During playback, press PAUSE/STEP (X) to pause playback. ALL Press PAUSE/STEP (X) repeatedly to play Frame-byFrame. DVD VCD MPEG4 During playback, press SKIP (. or >) to go to the next chapter/track or to return to the beginning of the current chapter/track.
Notes on general features: Last Scene Memory • On a Video CD with PBC, you must set PBC to Off on the setup menu to use the repeat function (See “PBC” on page 15). This player memorizes last scene from the last disc that is viewed. The last scene remains in memory even if you remove the disc from the player or switch off the player. If you load a disc that has the scene memorized, the scene is automatically recalled.
Playing an Audio CD or MP3/WMA file This unit can play Audio CDs or MP3/WMA files. MP3/ WMA/ Audio CD Once you insert an MP3/WMA files recorded media or Audio CD, a menu appears on the TV screen. Use v / V to select a track/file and then press PLAY (N) or ENTER and playback starts. You can use variable playback functions. Refer to page 16-17. ID3 TAG When playing a file containing information such as track titles, you can see the information by pressing DISPLAY.
Programmed Playback The program function enables you to store your favorite tracks from any disc in the player memory. A program can contain 30 tracks. 1. Insert an Audio CD or MP3/WMA files recorded media. AUDIO CD or MUSIC menu appears. 2. Press PROGRAM and the E mark will appear. Repeat Programmed Tracks Press REPEAT to select a desired repeat mode. • TRACK: Repeats the current track. • ALL: Repeats all the tracks on programmed list. • Off (No display): Does not play repeatedly.
Viewing a JPEG file This unit can play JPEG files. 1. Insert a JPEG files recording media. The PHOTO menu appears on the TV screen. Zoom During watching pictures, press ZOOM to enlarge the video image (3 steps). You can move through the zoomed picture using b / B / v / V buttons. Rotating the picture Press v / V during showing a picture to rotate the picture clockwise or counter clockwise. Listening to MP3/WMA music while watching picture 1. Insert the disc containing the two types of file in the player.
Playing a MPEG4 Movie file MPEG4 disc compatibility with this player is limited as follows: • Available resolution size of the MPEG4 file is under 720x576 (W x H) pixel. • The file name of the MPEG4 subtitle is available by 56 characters. • The total number of files in a folder should be less than 650 files. • CD-R/RW, DVD±R/RW Format: ISO 9660 • If there is impossible code to express in the MPEG4 file, it may be displayed as “ _ ” mark on the display.
Playing a DVD VR format Disc This unit will play DVD-RW disc that is recorded using the Video Recording (VR) format. 1. Insert a disc and close the tray. The DVD-VR menu appears on the TV screen. 2. Press v / V to select a title then press PLAY (N) or ENTER and playback starts. 3. Press DVD MENU to move to the list menu. Notes: • This unit will play DVD-R/RW disc that is recorded using the DVD-Video format that have been finalized using a DVD-recorder.
Reference Remote Control Function Maintenance and Service Remote Control C1/C2/C3 Code Switching This unit is initially set to C3 code (JVC DVD PLAYER code). You can easily change the Remote Control code to C1 (JVC VCR code), C2 (JVC DVD RECORDER code) or C3 as shown below. Refer to the information in this chapter before contacting a service technician. STANDBY/ON x Handling the Unit When shipping the unit Please save the original shipping carton and packing materials.
Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu.
Troubleshooting Possible Cause Correction No power. • The power cord is disconnected. • Plug the power cord into the wall outlet securely. The power is on, but the DVD player does not work. • No disc is inserted. • Insert a disc. (Check the disc indicator in the display window is lit.) No picture. • Your TV does not accept the resolution that you set on the unit. • Please read TV’s owner’s manual then use RESOLUTION button to set the resolution that your TV can accept.
Specifications General Power requirements: AC 110-240 V ~ 50/60 Hz Power consumption: 9W Dimensions (Approx.): 430 x 39 x 192 mm (17 x 1.5 x 7.6 inches) (W x H x D) without foot Net weight (Approx.): 1.5 kg (3.3 lbs) Operating temperature: 5 °C to 35 °C (41 °F to 95 °F) Operating humidity: 5 % to 90 % Outputs VIDEO OUTPUT: 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1 S-VIDEO OUTPUT: (Y) 1.0 V (p-p), 75 Ω, negative sync, Mini DIN 4-pin x 1 (C) 0.
Reference MEMO 27
