26
General
Power requirements: AC 110-240 V ~ 50/60 Hz
Power consumption: 9 W
Dimensions (Approx.): 430 x 39 x 192 mm (17 x 1.5 x 7.6 inches) (W x H x D) without foot
Net weight (Approx.): 1.5 kg (3.3 lbs)
Operating temperature: 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity: 5 % to 90 %
Outputs
VIDEO OUTPUT: 1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1
S-VIDEO OUTPUT: (Y) 1.0 V (p-p), 75 Ω, negative sync, Mini DIN 4-pin x 1
(C) 0.3 V (p-p) 75 Ω
COMPONENT VIDEO OUTPUT: (Y) 1.0 V (p-p), 75 Ω,negative sync, RCA jack x 1
(Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack x 2
HDMI OUTPUT (Video/Audio): 19 pin (HDMI standard, Type A)
AUDIO OUTPUT: 2.0 Vrms (1 KHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
DIGITAL AUDIO OUTPUT: COAXIAL: 0.5 V (p-p), 75 Ω, RCA jack x 1
OPTICAL: 3 V (p-p), Optical jack x 1
System
Laser: Semiconductor laser, wavelength 650 nm
Signal system: NTSC
Frequency response: DVD (PCM 96 kHz): 8 Hz to 44 kHz
DVD (PCM 48 kHz): 8 Hz to 22 kHz
CD: 8 Hz to 20 kHz
Signal-to-noise ratio: More than 90 dB (ANALOG OUT connectors only)
Harmonic distortion: Less than 0.02%
Dynamic range: More than 95 dB (DVD/CD)
Accessories
Video cable (1), Audio cable (1), Remote control (1), Batteries (2)
Note: Design and specifications are subject to change without prior notice.
Specifications
