MX-KB4(C).book Page 1 Thursday, March 11, 2004 1:10 PM COMPACT COMPONENT SYSTEM SYSTEME DE COMPOSANTS COMPACT MX-KB4 Consists of CA-MXKB4 and SP-MXKB4 Se compose de CA-MXKB4 et de SP-MXKB4 STANDBY/ON SLEEP AUX FM MODE CD1 CD2 CD3 FM /AM CD REPEAT PROGRAM /RANDOM TAPE A SOUND MODE TAPE B VOLUME FADE RHYTHM AX MUTING REMOTE CONTROL SP-MXKB4 CA-MXKB4 SP-MXKB4 INSTRUCTIONS MANUEL D’INSTRUCTIONS For Customer Use: Enter below the Model No. and Serial No.
MX-KB4(C).book Page 1 Thursday, March 11, 2004 1:10 PM Warnings, Cautions and Others / Mises en garde, précautions et indications diverses (For U.S.A) INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
MX-KB4(C).book Page 2 Thursday, March 11, 2004 1:10 PM IMPORTANT FOR LASER PRODUCTS IMPORTANT POUR LES PRODUITS LASER 1. CLASS 1 LASER PRODUCT 2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the Unit; leave all servicing to qualified service personnel. 3. CAUTION: Visible and invisible laser radiation when open and interlock failed or defeated. Avoid direct exposure to beam. 4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED INSIDE THE UNIT. 1. PRODUIT LASER CLASSE 1 2.
MX-KB4(C).book Page 1 Thursday, March 11, 2004 1:10 PM English Introduction Thank you for purchasing the JVC Compact Component System. We hope it will be a valued addition to your home, giving you years of enjoyment. Be sure to read this instruction manual carefully before operating your new stereo system. In it you will find all the information you need to set up and use the system. If you have a query that is not answered by the manual, please contact your dealer.
MX-KB4(C).book Page 2 Thursday, March 11, 2004 1:10 PM English Table of Contents Introduction ...................................................................................................................1 Features.................................................................................................................................................... 1 How This Manual Is Organized...............................................................................................................
MX-KB4(C).book Page 3 Thursday, March 11, 2004 1:10 PM English Getting Started Accessories Make sure that you have all of the following items, which are supplied with the System. AM Loop Antenna (1) FM Wire Antenna (1) Remote Control (1) Batteries (2) If any of these items are missing, contact your dealer immediately. How To Put Batteries In the Remote Control Match the polarity (+ and –) on the batteries with the + and – markings in the battery compartment.
MX-KB4(C).book Page 4 Thursday, March 11, 2004 1:10 PM English Getting Started CAUTION: • Make all connections before plugging the System into an AC power outlet. Connecting the FM Antenna Using the Supplied Wire Antenna FM wire antenna (supplied) Extend the supplied FM Wire Antenna horizontally. Strip vinyl shield from cut line, twist wire core. Using an FM 75-Ohm Antenna Cable (not Supplied) If reception is poor, connect the outside antenna.
MX-KB4(C).book Page 5 Thursday, March 11, 2004 1:10 PM English Getting Started Connecting the AM Antenna Rear Panel of the Unit AM antenna wire (not supplied) If reception is poor, connect the outside antenna. Turn the loop until you have the best reception. AM loop antenna (Supplied) Attach the AM loop to its base by snapping the tabs on the loop into the slot in the base. • Even when connecting an outside AM antenna, keep the indoor AM loop connected.
MX-KB4(C).book Page 6 Thursday, March 11, 2004 1:10 PM Connecting External Equipment Connect a signal cord with stereo mini plugs (not supplied) between the System’s AUX jack on the front panel and the audio output jack or output terminals of the external portable CD, MD player, STB, etc. You can then listen to the external source through the System. Signal cord (not supplied) White Lch Rch Red To audio output of external equipment.
MX-KB4(C).book Page 7 Thursday, March 11, 2004 1:10 PM English Basic Operations ) STANDBY/ON STANDBY/ON Display SLEEP Numeric keys RHYTHM AX indicator RHYTHM AX AUX FM MODE FM /AM SOUND MODE VOLUME STANDBY/ON PHONES STANDBY indicator CD1 CD2 CD3 CD REPEAT PROGRAM /RANDOM TAPE A SOUND MODE SOUND MODE TAPE B VOLUME VOLUME +,– FADE RHYTHM AX MUTING FADE MUTING RHYTHM AX Various information REMOTE CONTROL Sound Mode indicator Level bar Status bar (Indicates various statuses.
MX-KB4(C).book Page 8 Thursday, March 11, 2004 1:10 PM Fade-out Muting (FADE MUTING) You can mute the output with one touch operation. To muting the output, press the FADE MUTING button on the Remote Control. The output is faded out. To release muting, press the FADE MUTING button once again. The output is faded in to the previous level. • After Fade-out Muting, turning the VOLUME control on the unit or pressing the VOLUME button on the Remote Control will increase the volume from the previous level.
MX-KB4(C).book Page 9 Thursday, March 11, 2004 1:10 PM English Using the Tuner STANDBY/ON Numeric keys SLEEP AUX FM MODE SET FM /AM FM/AM FM MODE FM/AM ¡ 1 CD1 CD2 CD3 CD REPEAT PROGRAM /RANDOM TAPE A SOUND MODE 1 ¢ ¡ 4 TAPE B VOLUME FADE RHYTHM AX MUTING REMOTE CONTROL Band display, Frequency display, Preset channel FM mode indicators * When the System is in use, the display shows other items as well. For simplicity, we show here only the items described in this section.
MX-KB4(C).book Page 10 Thursday, March 11, 2004 1:10 PM CAUTION: • In AM broadcast, reception sensitivity will be changed by turning the AM loop antenna. Turn the AM loop antenna for best reception. • Even if the System is unplugged or if the power failure occurs, the preset stations will be stored for a few days. However, in case the preset stations are erased, you will need to preset the stations again. Presetting Stations You can preset up to 30 FM stations and up to 15 AM stations.
MX-KB4(C).book Page 11 Thursday, March 11, 2004 1:10 PM English Using the CD Player REPEAT PROGRAM RANDOM CD Open/ Close 0 DISC SKIP STANDBY/ON CD 6 Numeric keys SLEEP SET AUX CANCEL FM MODE ¢ 4 1 ¢ ¡ 4 7 CD1-CD3 CD1 CD2 CD3 7 CD CD 6 REPEAT PROGRAM /RANDOM TAPE A CD1-CD3 FM /AM TAPE B REPEAT PROGRAM /RANDOM SOUND MODE Track number, Playing time, Program number, etc.
MX-KB4(C).book Page 12 Thursday, March 11, 2004 1:10 PM About Disc Indicator: Disc Rotation indicator Disc Number indicator Selected Disc indicator The Disc indicator consists of the following three kinds of indicators: Disc Number indicator: Lights all the time. Selected Disc indicator:Lights for the currently selected disc number. Disc Rotation indicator:Runs when the selected CD is playing or paused. This indicator goes out if a CD is not loaded for the selected disc number.
MX-KB4(C).book Page 13 Thursday, March 11, 2004 1:10 PM English Using the CD Player Basics of Using the CD PlayerNormal Play To Play CDs 1 2 GROUP mode Total group number Load CDs. Press one of the Disc button (CD1-CD3) you want to play. The selected disc number (e.g. “CD DISC 1” ) appears on the display. The first track of the selected CD begins playing. When the first CD finishes playing, the next and the third CDs are continuously played back.
MX-KB4(C).book Page 14 Thursday, March 11, 2004 1:10 PM Programming the Playing Order of the Tracks You can program the playing order of the tracks on all the CDs. Note that you can only make a program when the CD Player is stopped. ❏ You can program up to 32 tracks in any desired order including the same tracks. For MP3 discs • If you try to select a MP3 disc that has once been read or played, "MP3 DISC" appears on the display and it can not be programmed.
MX-KB4(C).book Page 15 Thursday, March 11, 2004 1:10 PM English Using the CD Player Random Play Tray Lock Function The tracks of the selected CD will play in no special order when you use this mode. In order to safely keep the CD in the CD Player, the tray can be electronically locked. When the electronic lock is on, the tray cannot be opened even if the CD Open/Close 0 button on the Unit is pressed. 1 In Stop mode, set the CD Player in Random Play mode.
MX-KB4(C).book Page 16 Thursday, March 11, 2004 1:10 PM English Using the Cassette Deck (Listening to a Tape) STANDBY/ON TAPE A 3 TAPE B 3 SLEEP AUX 7 FM MODE FM /AM 4 ¢ CD1 CD2 CD3 22 0 PUSH OPEN (Deck A) CD REPEAT PROGRAM /RANDOM TAPE A TAPE B TAPE B 3 TAPE A 3 SOUND MODE 0 PUSH OPEN (Deck B) ¡ 7 VOLUME FADE RHYTHM AX MUTING REMOTE CONTROL Deck indicators 3: Tape indicator * When the System is in use, the display shows other items as well.
MX-KB4(C).book Page 17 Thursday, March 11, 2004 1:10 PM English Using the Cassette Deck (Recording) STANDBY/ON SLEEP AUX FM MODE REC START/STOP CD REC START PROGRAM DUBBING FM /AM TAPE B 3 7 TAPE A 3 CD1 CD2 CD3 CD REPEAT PROGRAM /RANDOM TAPE A TAPE A 3 TAPE B 3 SOUND MODE 0 PUSH OPEN (Deck B) 0 PUSH OPEN (Deck A) 7 TAPE B VOLUME FADE RHYTHM AX MUTING REMOTE CONTROL 3: Tape indicator Deck indicators REC indicator * When the System is in use, the display shows other items as well.
MX-KB4(C).book Page 18 Thursday, March 11, 2004 1:10 PM Standard Recording 2 Insert a blank or erasable tape into the Deck B and wind past the tape leader. Press the CD REC START button on the Unit. This is the basic method for recording any source. The System also has special ways for recording CD to tape, and tape to tape, which save you time and effort, as well as give you some special effects.
MX-KB4(C).book Page 19 Thursday, March 11, 2004 1:10 PM English Using an External Equipment STANDBY/ON SLEEP AUX AUX FM MODE FM /AM AUX CD1 CD2 CD3 CD AUX jack REPEAT PROGRAM /RANDOM TAPE A SOUND MODE TAPE B VOLUME FADE RHYTHM AX MUTING REMOTE CONTROL Listening to the External Equipment You can listen to the external equipment such as portable CD, MD player, STB, or other auxiliary. ❏ First, make sure that the external equipment is properly connected to the System. (See page 6.
MX-KB4(C).book Page 20 Thursday, March 11, 2004 1:10 PM English Using the Timers STANDBY/ON SLEEP SLEEP AUX FM MODE FM /AM CLOCK/TIMER SET ¢ CD1 CD2 CD3 CD 4 REPEAT PROGRAM /RANDOM TAPE A SOUND MODE TAPE B VOLUME FADE RHYTHM AX MUTING DAILY Timer indicator REMOTE CONTROL SLEEP indicator Timer indicator REC (Recording) Timer indicator * When the System is in use, the display shows other items as well. For simplicity, we show here only the items described in this section.
MX-KB4(C).book Page 21 Thursday, March 11, 2004 1:10 PM English Using the Timers 2. Press the ¢ or 4 button to set the minute, then press the SET button. Setting the Daily Timer Once you have set the Daily Timer, the timer will be activated at the same time every day. The Timer indicator ( ) and “DAILY” indicator on the display shows that the Daily Timer you have set is in effect. You can set the Daily Timer whether the System is turned on or off.
MX-KB4(C).book Page 22 Thursday, March 11, 2004 1:10 PM Preparation for each music source: Perform the following operation according to the music source you have selected. Then, the System enters Volume Setting mode. When selecting TUNER FM or TUNER AM: Press the ¢ or 4 button to select the preset station number, then press the SET button. When selecting CD : Press the ¢ or 4 button to select the disc number, then press the SET button.
MX-KB4(C).book Page 23 Thursday, March 11, 2004 1:10 PM English Using the Timers Using the Unit You can set the time in the same way as for setting the Daily Timer. 1 2 Insert a blank or erasable tape into the Deck B and wind past the tape leader. Press the CLOCK/TIMER button until “ON TIME” immediately after “REC” appears on the display. The Timer indicator ( ) lights and the “REC” indicator blinks.
Body.fm Page 24 Tuesday, March 16, 2004 10:48 AM Setting the SLEEP Timer Timer Priority Use the Sleep Timer to turn the System off after a certain number of minutes when it is playing. By setting the Sleep Timer, you can fall asleep to music and know that your System will turn off by itself rather than play all night. • You can only set the Sleep Timer when the System is on. Since REC Timer and DAILY Timer can be set independently, you may wonder what happens if the settings overlap.
MX-KB4(C).book Page 25 Thursday, March 11, 2004 1:10 PM English Care And Maintenance Handle your CDs and tapes carefully, and they will last a long time. Cassette Tapes • If the tape is loose in its cassette, take up the slack by inserting a pencil in one of the reels and rotating. • If the tape is loose, it may get stretched, cut, or caught in the cassette. Compact Discs Recordable • Only CDs bearing these marks can be used with this System.
MX-KB4(C).book Page 26 Thursday, March 11, 2004 1:10 PM • If you are having a problem with your System, check this list for a possible solution before calling for service. • If you cannot solve the problem from the hints given here, or the System has been physically damaged, call a qualified person, such as your dealer, for service. Symptom No sound is heard. Possible Cause • Headphones are connected. • Check all connections and make corrections. (See pages 4 to 6.) • Disconnect the headphones.
MX-KB4(C).book Page 1 Thursday, March 11, 2004 1:10 PM Introduction Français Merci d'avoir fait l'acquisition de le système compacte par éléments de JVC. Nous espérons qu'elle apportera un plus considérable à votre foyer et que vous pourrez en profiter pendant de nombreuses années. Veuillez lire attentivement le présent manuel d'utilisation avant de faire fonctionner votre nouvelle système stéréo. Vous y trouverez toutes les informations nécessaires pour l'installation et l'utilisation de le système.
MX-KB4(C).book Page 2 Thursday, March 11, 2004 1:10 PM Table des matières Introduction ...................................................................................................................1 Fonctions ................................................................................................................................................. 1 Structure du manuel.................................................................................................................................
MX-KB4(C).book Page 3 Thursday, March 11, 2004 1:10 PM Introduction Accessoires Français Vérifier si vous avez bien reçu tous les éléments suivants, livrés avec le système. Antenne cadre AM (1) Fil d'antenne FM (1) Télécommande (1) Piles (2) Si un de ces éléments devait manquer, contacter immédiatement le revendeur. Comment insérer les piles dans la télécommande Faire correspondre la polarité (+ et –) des piles avec les repères + et – du logement des piles.
MX-KB4(C).book Page 4 Thursday, March 11, 2004 1:10 PM Introduction ATTENTION: • Effectuer tous les branchements avant de raccorder le système à une prise secteur. Français Raccordement de l'antenne FM Utilisation du fil d'antenne livré Fil d'antenne FM (livré) Déployer l'antenne à fil FM fournie à l'horizontale. Dénuder la gaine en vinyle à la ligne de découpe et torsader l'âme du fil. Utilisation d'un fil d'antenne FM 75 ohms (non fourni) Si la réception est mauvaise, raccorder l'antenne externe.
Body_Fra.fm Page 5 Thursday, March 11, 2004 7:10 PM Introduction Branchement de l'antenne AM Français Dos de l'appareil Fil d'antenne AM (non fourni) Si la réception est mauvaise, raccorder une antenne externe. Tourner le cadre pour avoir la meilleure réception possible. Antenne cadre AM (fournie) Fixer le cadre AM à son socle en insérant à fond les languettes du cadre dans la fente du socle. • En cas de raccordement d'une antenne AM extérieure, laisser l'antenne cadre AM branchée.
MX-KB4(C).book Page 6 Thursday, March 11, 2004 1:10 PM Introduction Branchement d'équipements externes Cordon de signaux (non fourni) Blanc Canal de gauche Canal de droite Rouge A la sortie audio d'un équipement extérieur. Raccordement à une prise secteur Brancher le cordon d'alimentation secteur dans la prise. Le système est à présent à vos ordres! Mode DEMO Lors du branchement de le système à une prise secteur, le mode DEMO affiche automatiquement certaines des fonctions de le système.
MX-KB4(C).
MX-KB4(C).book Page 8 Thursday, March 11, 2004 1:10 PM Opérations de base Vous pouvez assourdir la diffusion sonore par le biais d'une opération à une touche. Pour couper la diffusion du son, appuyer sur la touche FADE MUTING de la télécommande. Le son est alors fondu. Pour supprimer l'assourdissement, réappuyer sur la touche FADE MUTING. La diffusion sonore revient progressivement à son niveau préalable.
MX-KB4(C).book Page 9 Thursday, March 11, 2004 1:10 PM Utilisation du tuner STANDBY/ON Touches numériques SLEEP Français AUX FM MODE SET FM /AM FM/AM FM MODE ¡ 22 CD1 CD2 CD3 CD FM/AM 22 ¢ ¡ 4 REPEAT PROGRAM /RANDOM TAPE A SOUND MODE TAPE B VOLUME FADE RHYTHM AX MUTING REMOTE CONTROL Affichage de bande, affichage de fréquence, station présélectionnée Indicateurs du mode FM * Lors de l'utilisation de le système, l'affichage indique également d'autres informations.
MX-KB4(C).book Page 10 Thursday, March 11, 2004 1:10 PM Utilisation du tuner • Au point 4, vous pouvez sélectionner le numéro de présélection à l'aide des touches numériques de la télécommande. Voir “Entrer le numéro à l'aide de la télécommande ” à la page 8. ATTENTION: Présélection des stations Vous pouvez présélectionner jusqu'à 30 stations FM et 15 stations AM. • Des numéros de présélections peuvent avoir été réglés sur des fréquences de test à l'usine avant le transport.
MX-KB4(C).book Page 11 Thursday, March 11, 2004 1:10 PM Utilisation du lecteur CD ) REPEAT PROGRAM RANDOM Ouvrir/fermer tiroir CD 0 DISK SKIP STANDBY/ON Touches numériques CD 6 SLEEP Français AUX FM MODE 4 ¢ CD1-CD3 CD1 CD2 CD3 TAPE A TAPE B REPEAT SOUND MODE CANCEL CD1-CD3 7 22 ¢ CD 6 ¡ 4 CD REPEAT PROGRAM /RANDOM PROGRAM /RANDOM SET FM /AM 7 VOLUME FADE RHYTHM AX MUTING REMOTE CONTROL Numéro de plage, temps de lecture, numéro du programme, etc.
MX-KB4(C).book Page 12 Thursday, March 11, 2004 1:10 PM Au sujet de l'indicateur du disque: Indicateur de rotation du disque Indicateur du numéro du disque Indicateur du disque sélectionné L'indicateur de disque comprend les trois sortes d'indicateurs suivants: Indicateur de numéro Reste continuellement allumé. de disque: S'allume pour le numéro du Indicateur du disque disque sélectionné.
MX-KB4(C).book Page 13 Thursday, March 11, 2004 1:10 PM Utilisation du lecteur CD Notions de base pour l'utilisation du lecteur CD - Lecture normale Français Pour écouter les CD 1 2 Total du nombre de groupes Charger les CD. Appuyer sur une des touches de disques (CD1-CD3) correspondant au disque que vous voulez écouter. Le numéro du disque sélectionné (par ex. “CD DISC 1” ) s'affiche. La lecture de la première plage du disque sélectionné démarre.
MX-KB4(C).book Page 14 Thursday, March 11, 2004 1:10 PM Utilisation du lecteur CD Vous pouvez programmer l'ordre de lecture des plages sur tous les CD. Remarquer cependant que vous pouvez uniquement effectuer cette programmation lorsque le lecteur CD est à l'arrêt. ❏ Vous pouvez programmer jusqu'à 32 plages dans n'importe quel ordre, y compris en répétant les mêmes plages.
MX-KB4(C).book Page 15 Thursday, March 11, 2004 1:10 PM Utilisation du lecteur CD Lecture aléatoire Fonction de verrouillage du tiroir Les plages du CD sélectionnées seront jouées dans n'importe quel ordre lorsqu'on utilise ce mode. Afin de pouvoir conserver en toute sécurité les CD dans le lecteur, il est possible de verrouiller le tiroir de manière électronique.
MX-KB4(C).
MX-KB4(C).
MX-KB4(C).book Page 18 Thursday, March 11, 2004 1:10 PM Utilisation de la platine à cassette (enregistrement) • Si vous ne voulez enregistrer qu'un seul CD, vous n'avez besoin de charger qu'un seul CD. Il s'agit de la méthode de base pour enregistrer n'importe quelle source. Le système possède également des fonctions spéciales pour enregistrer un CD sur une cassette, une cassette sur une autre, afin de vous épargner du temps et des efforts et de vous permettre d'ajouter certains effets spéciaux.
MX-KB4(C).book Page 19 Thursday, March 11, 2004 1:10 PM Branchement d'équipements externes STANDBY/ON SLEEP AUX Français AUX FM MODE FM /AM AUX CD1 CD2 CD3 CD Jack AUX REPEAT PROGRAM /RANDOM TAPE A SOUND MODE TAPE B VOLUME FADE RHYTHM AX MUTING REMOTE CONTROL Ecoute d'équipements externes Vous pouvez écouter des équipements externes tels qu'un CD portatif, une platine MD, un STB ou d'autres équipements annexes.
MX-KB4(C).
MX-KB4(C).book Page 21 Thursday, March 11, 2004 1:10 PM Utilisation des minuteries 2. Appuyer sur les touches ¢ ou 4 pour régler les minutes puis appuyer sur SET. Français Réglage de la minuterie quotidienne Une fois que vous avez programmé la minuterie quotidienne, celle-ci se met en marche tous les jours à la même heure. L'indicateur de la minuterie ( ) et l'indicateur “DAILY” montrent que la minuterie quotidienne programmée est activée.
MX-KB4(C).book Page 22 Thursday, March 11, 2004 1:10 PM Utilisation des minuteries 5 6 Préparation pour chaque source de musique: Effectuer l'opération suivante en fonction de la source de musique sélectionnée. Le système se met ensuite en mode de réglage du volume. Lors de la sélection de TUNER FM ou TUNER AM: Appuyer sur les touches ¢ ou 4 pour sélectionner le numéro de la station présélectionnée puis appuyer sur SET.
MX-KB4(C).book Page 23 Thursday, March 11, 2004 1:10 PM Utilisation des minuteries Sur l'appareil Vous pouvez programmer l'heure comme pour la minuterie quotidienne. Insérer une cassette vierge ou effaçable dans la platine B et bobiner l'amorce. 2 Appuyer sur la touche CLOCK/TIMER jusqu'à ce que l'indication “ON TIME” apparaisse immédiatement après “REC” sur l'affichage. Français 1 L'indicateur de la minuterie ( ) s'allume et l'indicateur “REC” clignote.
Body_Fra.fm Page 24 Tuesday, March 16, 2004 10:48 AM Utilisation des minuteries Utiliser la minuterie Bonsoir pour éteindre le système après un certain nombre de minutes d'écoute. La programmation de la minuterie Bonsoir vous permet de vous endormir en musique sans vous soucier de le système, qui s'éteint automatiquement. • Vous pouvez uniquement programmer la minuterie Bonsoir lorsque le système est sous tension.
MX-KB4(C).book Page 25 Thursday, March 11, 2004 1:10 PM Nettoyage et entretien Manipuler vos CD et vos cassettes avec grand soin, pour qu'ils durent plus longtemps. Français Disques compacts Recordable • Seuls les CD portant ces marques peuvent être utilisés dans ce lecteur. Cependant, l'utilisation continue de CD de formes irrégulières (en forme de coeur, octogonaux, etc.) risque d'endommager le système.
MX-KB4(C).book Page 26 Thursday, March 11, 2004 1:10 PM Guide de dépannage Symptôme Pas de son. Cause possible Remède • Les branchements ne sont pas corrects ou sont trop lâches. • Vérifier toutes les connexions et effectuer les corrections nécessaires. (Voir pages 4 à 6.) • Débrancher le casque d'écoute. • Un casque d'écoute est branché. Mauvaise réception radio. • L'antenne est débranchée. • L'antenne cadre AM est trop près de le système.
MX-KB4(C).
