V.NETWORKS Model VN-C10 INSTRUCTIONS For Customer Use: Enter below the Serial No. which is located on the body. Retain this information for future reference. Model No. VN-C10 Serial No. LWT0095-001C VN-C10_E_01-43.
IMPORTANT SAFEGUARDS 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. 17. 18. 19. Read all of these instructions. Save these instructions for later use. All warnings on the product and in the operating instructions should be adhered to. Unplug this appliance system from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. Do not use attachments not recommended by the appliance manufacturer as they may cause hazards.
Safety Precautions FOR USA AND CANADA Due to design modifications, data given in this instruction book are subject to possible change without prior notice. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Thank you for purchasing this product. (These instructions are for VN-C10U.) Before beginning to operate this unit, please read the instruction manual carefully in order to make sure that the best possible performance is obtained. Contents Introduction Contents ................................................................................................. 4 Features ................................................................................................. 6 Items Included ........................
Operations (V.Networks Controller) Step 4 Setting with V.Networks Controller 4-1 Starting Up V.Networks Controller ............................................. 44 4-2 Function Settings with V.Networks Controller ............................ 45 4-3 Motion Detection Standby ......................................................... 46 4-4 Image Size and Inversion .......................................................... 47 4-5 Setting the Image Quality .......................................................
Introduction Features • VN-C10 uses a 1/3-inch CCD with 380,000 pixels, enabling monitoring of high quality images. • For the compression method, in addition to the standard JPEG, VN-C10 supports MPEG4 for a wide range of bit rates. (With MPEG4, up to 4 clients can be connected at one time.) • Equipped with an image recording function by motion detection and alarm input. • VN-C10 has a design similar to other CCTV monitoring cameras, allowing peripheral equipment for such cameras to be also used for VN-C10.
Required Operating Environment PC Specifications OS CPU Memory Capacity Hard Disk Space Display/Video Card : Windows 2000 (Service Pack 1 or higher) Windows XP Home Edition Windows XP Professional : Pentium III 500 MHz or higher (1 GHz or higher recommended) : 128 MB or more : 20 MB or more : 1024 X 768 pixels or more, True Color (24 bits or 32 bits) LAN Specifications • 10 BASE-T/100 BASE-TX network connected with IEEE802.3 hubs. Note The PC specifications above are only for a reference purpose.
Introduction Operating Precautions ● VN-C10 is designed for indoor use. For outdoor use, prepare a proper housing to cover and protect the camera. ● The product should not be installed or used in the following locations. • Locations subject to rain or water. • Locations with hot air or oil vapors such as in kitchens, etc. • Locations where the allowed ambient temperature (0 °C to 40 °C) is exceeded. • Locations exposed to X-ray radiation or where strong electrical or magnetic waves are generated.
Controls, Connectors and Indicators (Front, top and side views) 2 1 3 4 5 7 1 Lens mount 8 6 5 Screw hole (1/4-20UNC) The mount for attaching a lens. Either a Cmount or a CS-mount lens can be used. 2 Back-focus adjustment ring The ring for adjusting back-focus and changing the mount method. For adjusting back-focus or changing the mount method, loosen the back-focus locking screw (3) by turning it counterclockwise and, after the operation, fix it by turning it clockwise.
Introduction Controls, Connectors and Indicators (continued) (Side and rear views) # 2 G 2 1 OUT COM OUTPUT DC12V AC24V 1 $ % INPUT 0 ! CLASS 2 ONLY For USA ISOLATED POWER ONLY For EUROPE 9 ALARM RESET @ IRIS PUSH POWER 10BASE-T/100BASE-TX DO NOT CONNECT TO THE TELEPHONE NETWORK For USA ^ 9 Ventilation opening For the internal cooling fan. Install the camera in a way that does not cover the opening.
Preparations Connection Examples LAN Connection MAC address ALC LEVEL Av Pk L H VN-C10 BF LOCK LAN PC MAC address ALC LEVEL Av Pk L H VN-C10 BF LOCK Network Connection MAC address ALC LEVEL Av Pk L H VN-C10 BF LOCK MAC address ALC LEVEL Av Pk L H VN-C10 LAN BF LOCK INTERNET FTP Server PC Images are automatically updated at a regular interval. PC Peer-to-Peer Connection H Av Pk L ALC LEVEL VN-C10 MAC address BF LOCK PC 11 VN-C10_E_01-43.
Preparations Preparation Procedure Set the camera in the following procedure. Step 1 Connection and Installation Attach a lens and connect the power cable, a LAN cable and an alarm etc. Then, install the camera to a fixer, etc. Fix a wire securely for preventing the ☞ Page 13 camera from falling off. Step 2 Setting the Network Install the software [V.Networks Controller], and set the network for the PC and VN-C10. Also perform the setting with [V.
Preparations (Step 1 Connection and Installation) 1-1 Attaching a Lens Attach a lens in the following procedure. 1. Before (a) attaching a lens, check the mount method of the lens. VN-C10 is set for CS-mount at the factory. For attaching a C-mount lens, loosen the backfocus locking screw using a screwdriver and turn the back-focus adjustment ring to change the mount method accordingly with a finger or a pointed tool like a screwdriver. To attach a lens, observe the length shown as (a).
Preparations (Step 1 Connection and Installation) 1-2 Connecting the Power Cord Connect the camera to DC 12 V or AC 24 V. The power indicator is lit when the power is turned on. G 2 1 OUT COM OUTPUT 2 INPUT DC12V AC24V 1 CLASS 2 ONLY For USA ISOLATED POWER ONLY For EUROPE To Power ALARM PUSH Power indicator lamp POWER 10BASE-T/100BASE-TX For USA DO NOT CONNECT TO THE TELEPHONE NETWORK Power Cord • Do not connect the power cord to DC 12 V and AC 24 V at the same time.
1-3 Connecting a LAN Cable G 2 • For hub connection Use a straight cable. 1 OUT COM OUTPUT 2 INPUT DC12V AC24V 1 CLASS 2 ONLY For USA ISOLATED POWER ONLY For EUROPE Connect the camera to a hub or a PC by using a LAN cable. ALARM • For PC connection Use a cross-over cable. PUSH Caution POWER 10BASE-T/100BASE-TX For USA DO NOT CONNECT TO THE TELEPHONE NETWORK There are a few types of LAN board for which a cross-over cable cannot be used.
Preparations (Step 1 Connection and Installation) 1-4 Connecting the Alarm I/O Terminals G 1 OUT COM OUTPUT 2 INPUT 2 AC24V DC12V 1 CLASS 2 ONLY For USA ISOLATED POWER ONLY For EUROPE Connect the alarm I/O terminals with external equipment such as a sensor, buzzer, etc. ALARM PUSH POWER 10BASE-T/100BASE-TX Press the buttons for connecting or disconnecting cables as shown on the left. Cable Specifications 50 m max.
1-4 Connecting the Alarm I/O Terminals (continued) Alarm Output Terminal This terminal is for connecting with an alarm annunciator such as an indicator, a lamp or a buzzer. Annunciator Output Requirements Connection Example 1 VN-C10 Output terminal MAX 300 mA COM terminal Grounding terminal (Alarm output equivalent circuit) DC 12 V R IN MAX 12 V COM GND Annunciator Connection Example 2 R DC 12 V IN Buzzer, lamp, LED etc. • Equivalent to NPN open collector output (The output logic is set with [V.
Preparations (Step 1 Connection and Installation) 1-5 Installing the Camera Fall-Preventive wire For attaching the camera to a fixer or a rotating platform, use the screw hole of the mounting bracket. Camera mounting screw hole Camera-mounting bracket Fall-preventive holes Screws for the bracket [x 2: M2.6 x 6 mm] Caution ● The length of the screw for mounting the camera must not exceed 7 mm. Do not use a longer screw as it MAX. may damage the internal 7 mm parts of the camera.
Preparations (Step 2 Setting the Network) 2-1 Installing the Software For operating VN-C10, install the software from the CD-ROM, which is supplied with ~~~~~~~~~~~~~~~ the camera in the following procedure. Installing V.Networks Controller 1. Select [Setup.exe] found in the [JVC] folder. 2. Proceed by following the instructions shown on the screen. 3. If the installation is successfully executed, the [V.Networks] icon is created in [Programs] of the Windows [Start] menu. [V.
Preparations (Step 2 Setting the Network) 2-2 Setting the PC’s IP Address for Windows XP After attaching the camera, proceed to set the IP address of the PC by which the camera is operated. With Windows XP, follow the procedure below to set the IP address. (For Windows 2000, ☞ Page 22) Note Under a DHCP environment and also if the IP address to be allotted to [V.Networks] is already known, skip 2-2 [Setting the PC’s IP Address]. 1. Click . • Right-click [My Network] and select [Properties]. 2.
2-2 Setting the PC’s IP Address for Windows XP (continued) 3. Select [Internet Protocol (TCP/IP)] and click [Properties]. Select [Internet Protocol (TCP/IP)]. Click [Properties]. 4. Select [Use the following IP address] to set [IP Address] and [Subnet Mask] and then click . Select [Use the following IP address]. Set [IP Address] to “192.168.0.3.” Note ● Before changing the IP address, note down the original address. ● Do not use the same IP address elsewhere in this network environment.
Preparations (Step 2 Setting the Network) 2-2 Setting the PC’s IP Address for Windows 2000 After attaching the camera, proceed to set the IP address of the PC by which the camera is operated. With Windows 2000, follow the procedure below to set the IP address. 1. Click . Select [Settings] and click [Control Panel]. 2. Double-click [Network and Dial-up Co...]. 3. Double-click [Local Area Connection]. Select [Internet Protocol (TCP/IP)]. Click [Properties]. 22 VN-C10_E_01-43.
2-2 Setting the PC’s IP Address for Windows 2000 (continued) 4. Click [IP Address] in [TCP/IP properties]. Select [Use the following IP Address]. Set the IP address to “192.168.0.3.” Set [Subnet mask] to an appropriate value according to the operating environment. Ask the network administrator if necessary. 5. Click . 23 VN-C10_E_01-43.
Preparations (Step 2 Setting the Network) 2-3 Setting the IP Address for VN-C10 with V.Networks Setup Tool Set the IP address for VN-C10 by using the installed [V.Networks Setup Tool]. (With this [V.Networks Setup tool] only VN-C10, not other models, can be connected.) Caution ● After the power for VN-C10 is turned on, there will be about 20 seconds until VN-C10 becomes ready to be connected with the PC. This is not a defect. ● At the factory, DHCP is set enabled for VN-C10.
2-3 Setting the IP Address for VN-C10 with V.Networks Setup Tool (continued) 2. Confirm the settings. Select whether to use DHCP. Note ● With DHCP selected, the IP address of the DHCP server etc. can be checked. Change the IP address to the one alloted, or approved, by the network administrator. Set the subnet mask to an appropriate value according to the operating environment. Ask the network administrator if necessary. Click For other settings, ☞ next page 3. Click . . [V.
Preparations (Step 2 Setting the Network) 2-4 Other Settings with V.Networks Setup Tool Set passwords, alarm, motion detection etc. by using the installed [V.Networks Setup Tool]. 1. Select [Start], [Programs], [V.NETWORKS] and then [vn-c10u Setup Tool] to start up [V.Networks Setup Tool]. ☞Page 27 ☞Page 38 ☞Page 39 ☞Page 40 ☞Page 34 ☞Page 41 ☞Page 38 ☞Page 28 ☞Page 32 ☞Page 30 ☞Page 36 2. Refer to the relevant pages (☞) for these settings shown above. 26 VN-C10_E_01-43.
2-4 Other Settings with V.Networks Setup Tool [1. Password Setting] VN-C10 is equipped with an access protection (security) function that, by setting passwords, regulates users of the connected PC. Setting and cancellation of passwords can be performed with [V.Networks Setup Tool]. According to access right (authorization) levels, up to 3 passwords (user, operator and administrator) can be set. Access Right Level User Operator Administrator Allowed Actions Only viewing moving images All operations with [V.
Preparations (Step 2 Setting the Network) 2-4 Other Settings with V.Networks Setup Tool [2. Alarm Setting] This section describes alarm setting. Alarm input is activated in the following cases. • Input signals are received from an input terminal located on the rear panel of the camera, [ALARM INPUT 1] or [ALARM INPUT 2]. (☞ Page 16) • Motion has been detected. (☞ Page 30) Operation when alarm input is activated.
2-4 Other Settings with V.Networks Setup Tool [2. Alarm Setting] (continued) 1 2 3 4 Alarm 1 Select [ON] to convert signals input to the [ALARM INPUT 1] terminal to [Alarm 1] signals. If [Alarm Output] is selected, alarm signals are sent to the [ALARM OUTPUT] terminal according to the output port setting. Alarm 2 Select [ON] to convert signals input to the [ALARM INPUT 2] terminal to [Alarm 2] signals.
Preparations (Step 2 Setting the Network) 2-4 Other Settings with V.Networks Setup Tool [3. Motion Detection Setting] This section describes the setting of the motion detection function which enables VN-C10 to trigger an alarm when motion is detected in a specified area. Motion is monitored while being compared to the reference image. The area within which the function is effective can be set in the following procedure. (This function cannot be set for MPEG4.) 1. Start up [V.Networks Setup Tool].
2-4 Other Settings with V.Networks Setup Tool [3. Motion Detection Setting] (continued) 3. Press [Detail] to display [Motion Detection Setting]. V.Networks General Setting Refresh Interval The reference image on which motion detection is based is refreshed at a regular interval. In a condition where the reference image changes, like outdoors, set a low value. Note With the interval set to “0 second,” the reference image is automatically refreshed if a motion is not detected for 10 seconds.
Preparations (Step 2 Setting the Network) 2-4 Other Settings with V.Networks Setup Tool [4. Recording Setting] This function records the image to the memory of VN-C10 when an alarm is activated. (This cannot be set for MPEG4.) • When an alarm is activated, image recording can be carried out in one of the following two ways. One way, local recording, saves images to the VN-C10 memory, and the other records images with [V.Networks Controller] and saves them to the PC hard disc drive, etc. (☞ Page 51) 1.
2-4 Other Settings with V.Networks Setup Tool [4. Recording Setting] (continued) 3. Others Set the recording action when the memory capacity for recording has become full. One of the following two can be selected. (The internal memory capacity is 8 MB.) • Stop recording until a free memory space for recording is created. • Delete files older than the designated number of days. (If the number of days is set to “0,” the files are deleted, starting with the oldest one.
Preparations (Step 2 Setting the Network) 2-4 Other Settings with V.Networks Setup Tool [5. FTP Client Setting] VN-C10 is equipped with an FTP client function which regularly uploads still images to an existing FTP server, thus enabling simultaneous image monitoring at many places and by many people. (This function cannot be set for MPEG4.) 1. Start up [V.Networks Setup Tool] and select [FTP Setting]. The [FTP Setting] screen is displayed. 1 2 3 4 5 6 7 8 9 0 34 VN-C10_E_01-43.
2-4 Other Settings with V.Networks Setup Tool [5. FTP Client Setting] (continued) 1 FTP To use the FTP function, select [Available]. 2 Rec File FTP Select [Available] if locally recorded *.rec files are to be uploaded to an FTP server automatically. 9 Note ● Uploading automatically starts when a rec file was created. ● Delete Rec file according to the [Lower memory size] setting of the Record setting screen.
Preparations (Step 2 Setting the Network) 2-4 Other Settings with V.Networks Setup Tool [6. Multicast] Selecting [Multicast Mode] allows VN-C10 to send the same image data to multiple recipients on the network at one time without lowering the frame rate. • In a narrowband environment, for example, of dial-up connection, select [Unicast Mode]. • Multicast cannot be set for MPEG4. 1. Start up [V.Networks Setup Tool] and select [Multicast]. The [Multicast Setting] screen is displayed.
2-4 Other Settings with V.Networks Setup Tool [6. Multicast] (continued) VN-C10 multicast addresses on the network can be searched. 1. Start up [V.Networks Setup Tool]. Select [Search]. Click [Search...]. 2. The [V.Networks Search] screen is displayed. Click [Multicast search]. 3. The [Multi Address Search] screen is displayed. To start search, click [Search]. 4. The search result is displayed. 37 VN-C10_E_01-43.
Preparations (Step 2 Setting the Network) 2-4 Other Settings with V.Networks Setup Tool [7. Compression Format] Either JPEG or MPEG4 can be selected as the image compression format. 1. Start up [V.Networks Setup Tool] and for the compression format, select JPEG or MPEG4. For MPEG4, select [MPEG-4]. Set the frame rate for MPEG4 (30, 15 or 7.5). For smoother display of images, set a larger value. Set the bit rate for MPEG4 (64 to 2048). For a better image quality, set a larger value.
2-4 Other Settings with V.Networks Setup Tool [9. Web] An HTML file can be set as the default page of the web browser. 1. Start up [V.Networks Setup Tool] and select [Web]. Select whether to enable the setting of the HTTP default page. If [Available] is selected, specify an html file for the default page. Set the port number. There are a few types of proxy server that caches CGI and the above setting cannot be properly done. In such a case, select [No Cache].
Preparations (Step 2 Setting the Network) 2-4 Other Settings with V.Networks Setup Tool [10. FTP Server] Using FTP client software, HTML pages, GIF and JPEG images can be uploaded. 1. Start up [V.Networks Setup Tool] and select [FTP Server]. Select whether to enable or disable the FTP server function. Note ● The FTP server name is fixed to [Administrator] and also use the password for the administrator. ● For the FTP user area, approximately 300 kB are allotted.
2-4 Other Settings with V.Networks Setup Tool [11. Time Setting] This section describes how to set the standard time for VN-C10. NTP can be used for this function. 1. Start up [V.Networks Setup Tool] and select [Time]. There are two ways to set the time, with or without NTP. NTP is not used. Set the date and time. The time by the PC clock can be checked. NTP is used. Enter the IP address of the NTP server. Set the time zone. Set the interval at which the current time is obtained from the NTP server.
Preparations (Step 2 Setting the Network) 2-5 Registering the Connected Camera with V.Networks Controller The connected camera can be registered with the installed [V.Networks Controller]. 1. Select [Start], [Programs], [V.NETWORKS] and then [V.Networks Controller] to start up [V.Networks Controller]. Select [File] and [New]. 2. [New] is displayed. Enter 198.168.0.2 in [IP Address]. Note In a DHCP environment, enter the IP address allotted by the DHCP server. Enter [V.
Preparations (Step 3 Adjusting the Camera) 3-1 Back-focus Adjustment At the factory, back-focus is set at the point for the widest range of use for CS-mount. However, it is necessary to readjust back focus if a zoom or C-mount lens is used or if focus cannot be attained using the focus ring of the lens. To adjust, follow the procedures described below.
Operations (Step 4 Setting with V.Networks Controller) 4-1 Starting Up V.Networks Controller With the installed Controller, camera images can be monitored. The settings for recording, replay and frame rate etc. can also be performed. 1. Select [Start], [Programs], [V.NETWORKS] and then [V.Networks Controller] to start up [V.Networks Controller]. In the pull down menu, select the camera to connect.
4-2 Function Settings with V.Networks Controller With [V.Networks Controller], settings for image size, alarm etc. can be performed. 12 3 4 1 File 3 Setting New : Creates a new file if the camera is connected for the first time. Delete : Deletes a file. Motion Detect Standby : For selecting the camera for which motion detection is enabled. : Exits “Controller.” Exit Quality : Sets the compression rate and image quality. Framerate : Sets the number of frames transmitted per second.
Operations (Step 4 Setting with V.Networks Controller) 4-3 Motion Detection Standby With [V.Networks Controller] running, automatic connection will be activated upon reception of motion detection alert from VN-C10. 1. Select [File] and then [Motion Detect Standby]. 2. Select the camera. Select the camera for which you wish to enable the motion detection function. Click 3. Click . . 46 VN-C10_E_44-61.
4-4 Image Size and Inversion With [V.Networks Controller], it is possible to set the size of the moving image window and invert the image. 1. Select [View]. 2. Select an image size and whether or not to invert the image. Note ● With MPEG4, the following settings are not available. • 640x480 • Upside Down ● In the Fine mode, image details can be checked. Not suitable when a moving object is to be recorded. (only for VN-C10 firmware version 1.4 and subsequently) ● 640 x 480 size is only use in fine mode.
Operations (Step 4 Setting with V.Networks Controller) 4-5 Setting the Image Quality With [V.Networks Controller], settings for image quality such as the image compression rate, white balance, etc., can be done. 1. Select [Setting] and [Quality]. 2. Change the set values. (For functional description, ☞ next page) 1 4 2 5 3 6 7 3. Click . 48 VN-C10_E_44-61.
4-5 Setting the Image Quality (continued) 1 Compression Rate Sets the image compression rate. A lower compression rate means a higher image quality. However, with a reduced compression rate, data volume also increases. This setting is not available for MPEG4. Value range: 1 to 7 (Set to “2” at the factory) 2 White Balance Auto : Automatically adjusts the white balance, the standard for color saturation. Factory set. R gain : To manually adjust the white balance toward more red intensity.
Operations (Step 4 Setting with V.Networks Controller) 4-6 Frame Rate With [V.Networks Controller], it is possible to set the frame rate, the number of image updates per second, for JPEG. Frame rate setting with [V.Networks Controller] is possible only for JPEG. Frame rate for MPEG4 can be set with [V.Networks Setup Tool]. (☞ Page 38) 1. Select [Setting] and [Framerate]. 2. Set the frame rate in the [Frame Rate] screen. Sets the maximum number of images per minute that are sent from VN-C10.
4-7 Alarm Setting With [V.Networks Controller], it is possible to set the action to be taken upon reception of an alarm signal. 1. Select [Setting] and [Alarm Setting]. 2. Change the set values. (For functional description, ☞ next page) Settings are performed for [Motion Detection Alarm], [Alarm 1], [Alarm 2] and [Relay Alarm]. 1 Text box 2 3 4 (With [Relay Alarm] selected, 1 and 2 cannot be set.) 3. When the settings are complete, click . 51 VN-C10_E_44-61.
Operations (Step 4 Setting with V.Networks Controller) 4-7 Alarm Setting (continued) 1 Message When an alarm is received, the message entered into the text box is displayed. The maximum number of characters that can be entered is 100. 2 Recording When an alarm is received, recording starts. Non-Stop : Recording continues until the Stop button is pressed. Stop 1min : Recording stops after 1 minute. 3 Note If a large Wave file (.
4-8 Time Stamp With [V.Networks Controller], the [Time Stamp] function can be set. This function displays the date and time on the camera images, and the date and time are recorded. 1. Select [Setting] and [Time Stamp]. 2. Proceed with the setting. Select [Visible]. Select the display style in [Style]. “YYYY,” “MM,” and “DD” represent “year,” “month” and “day” respectively. “HH” represents “hour” while “MM,” “minute,” “SS,” “second” and “mm,” “millisecond.” Click [Font...] to select the font.
Operations (Step 4 Setting with V.Networks Controller) 4-9 Changing the Registered Information With [V.Networks Controller], registered information on camera connection etc. can be changed. 1. Select [Setting] and [Property]. 2. Proceed with the setting. Change the camera. Cannot be changed. Set whether to start recording on connection. 3. When complete, click . Caution Information cannot be changed for a connected camera. 54 VN-C10_E_44-61.
Operations (Step 5 Operations with V.Networks Controller) 5-1 Operations with V.Networks Controller [V.Networks Controller] can be used to select the camera, record and playback the camera images etc. (The Controller screens are identical with those for other V.Networks models. Certain functions are not available for VN-C10.) 1 6 Not available for VN-C10. 2 3 4 5 1 Camera 4 REC Displays the name of the connected camera. It is also possible to select the camera using the pull down menu.
Operations (Step 5 Operations with V.Networks Controller) 5-2 Record/Stop [V.Networks Controller] can be used to save camera images to a file. 1. Click the [REC] button. Connected camera (Files are saved under this name) Recording format [Record] display 2. 1. (Moving image window) [REC] display 2. Click the [STOP] button. Recording stops. The [Recording] and [REC] displays disappear. When the [Snapshot] button is clicked, one single frame of the image being displayed is recorded.
5-3 Playback For playback, select the file saved with the record function of [V.Network Controller]. The playback function cannot be effective while moving images are displayed. 1. Click the [PLAY] button. [PLAY] button 2. Select the file you wish to replay from [Playback File] and click . To replay a local recording file, click [Refer to Local Rec.]. And select the file. Press [Refer to Local Rec.] to select the file.
Operations (Step 5 Operations with V.Networks Controller) 5-3 Playback (continued) 3. Click . 4. [Playback] is displayed. Slidebar • Moves toward the right as the playback time progresses. • Can be dragged with the mouse. [Stop] button [Pause] button [Play] button 58 VN-C10_E_44-61.
5-4 Other Instructions on Record and Playback Record/Playback time • Do not record or play a file that exceeds 2 GB with [V.Networks Controller]. With Windows applications, data in excess of 2 GB cannot be randomly accessed. Approximate recording time for 2 GB JPEG data (at 5 frames per second) Image size Data size per image 160 x 120 320 x 240 Approx. 5 kB Approx. 15 kB Approximate recording time 20 hours 6 hours 640 x 480 Approx.
Operations (Step 5 Operations with V.Networks Controller) 5-5 Snapshot With [V.Networks Controller], images being displayed or replayed can be saved as still image files. 1. Click the [SnapShot] button. Note Snapshots are saved as JPEG files in the JPEG mode and as BMP files in the MPEG mode. [SnapShot] button 2. The [Snap] screen appears. Select [File] and [Save]. 3. The [Save As] screen appears. Specify the folder into which the file is saved. Enter the file name. Press [Save] to save a snapshot.
Operations (Step 6 Operations with a Web Browser) It is possible to view still/moving images and perform various settings via not only the provided [Controller] software but via a Web browser as well. However, note that MPEG4 files cannot be viewed with a browser. Also, the browser does not support the image inversion function. 6-1 Required Operating Environment The following environment is required for viewing and operating VN-C10 with a Web browser.
Operations (Step 6 Operations with a Web Browser) 6-2 Access Authorization The structure of URLs within the VN-C10 is as shown below. Security level Top page (index-e.html) Still image page (still-e.html) Moving image page (java-e.html) Still image URL (still.jpg) Serverpush moving image URL (push.jpg) Configuration page (javaconfig-e.html) Configuration menus Image Quality Configuration (configimage-e.html) Java moving image URL (mjpeg.
6-3 Starting Up the Web Browser Start up the web browser. Specify the factory-set web page address of VN-C10. (With the factory-set IP address entered, the web browser displays the VN-C10 top page.) Note If a proxy server is set for accessing the Internet, there are cases in which the IP address cannot be directly specified. In this case, change the proxy setting so that the address can be entered. 1. Start up the Web browser. http://192.168.0.2/index-e.
Operations (Step 6 Operations with a Web Browser) 6-4 Settings with a Web Browser IP address, image quality, alarm, FTP, etc. can be set with a Web browser. Top page Click [Settings]. The setting page is displayed. Hyperlink to the Home page. 64 VN-C10_E_62-78.
6-4 Settings with a Web Browser (1. Other Settings) Other Settings: http://******/config-e.html (****** represents the URL of VN-C10.) The settings can be changed in the [Other] screen. (They can also be changed with [V.Networks Setup Tool] .) Click [Apply] to update the settings. 65 VN-C10_E_62-78.
Operations (Step 6 Operations with a Web Browser) 6-4 Settings with a Web Browser (1. Other Settings) (continued) Items in the [Other] screen Item DHCP IP Address Effect Sets whether to use DHCP. Changes to the address allotted or approved by the network administrator. (This can be changed only when DHCP is not used.) Sets the value provided or approved by the network administrator as in the case of IP address. (This can be changed only when DHCP is not used.
6-4 Settings with a Web Browser (1. Other Settings) (continued) Item Effect Default Page (continued) Available/ Not available File Name HTTP Port NTP Settings Available/ Not available Server IP Address Timezone Adjust Interval Select [Available] to enable the Default Page function or [Not Available] to disable it. Enter the file name to be used as the default page. It is possible to enhance the security level by setting the HTTP server port number to other than the default value “80.
Operations (Step 6 Operations with a Web Browser) 6-4 Settings with a Web Browser (2. Image Settings) Image Quality Setting Window: http://******/configimage-e.html (****** represents the URL of VN-C10.) Click [Apply] to update the settings. The values set in this screen return to the ones set at the factory. Item Compression Rate Effect Sets the compression rate for images. A smaller rate means better image quality, but with more amount of data.
6-4 Settings with a Web Browser (3. View Settings) View Setting Window: http://******/viewconfig-e.html (****** represents the URL of VN-C10.) Click [Apply] to update the settings. Item Image size Effect Select one from the 3 image sizes, “640x480,” “320x240” or “160x120.” ❈ In the Fine mode, image details can be checked. Do not use the Fine mode when a moving object is to be recorded. JPEG frame rate Select the maximum number of frames to be transmitted from VN-C10 per second.
Operations (Step 6 Operations with a Web Browser) 6-4 Settings with a Web Browser (4. Alarm Settings) Alarm Setting Window: http://******/alarm-e.html (****** represents the URL of VN-C10.) This section describes the setting of actions of VN-C10 when an alarm signal has been received. Click [Apply] to update the settings. Item Alarm In Alarm 1 and 2 On/Off Alarm Out Relay Alarm On/Off Relay Alarm Setting Alarm Out Alarm Out On/Off Effect Specifies the action when an alarm signal has been received.
6-4 Settings with a Web Browser (5. FTP Settings) FTP Client Setting Window: http://******/ftp-e.html (****** represents the URL of VN-C10.) (This function cannot be set for MPEG4.) Note • FTP Client Function This is a function that regularly uploads VN-C10 still images to the existing FTP server. With this function, it is possible to distribute images from the server, thus greatly increasing the number of clients, which receive them. Click [Apply] to update the settings. 71 VN-C10_E_62-78.
Operations (Step 6 Operations with a Web Browser) 6-4 Settings with a Web Browser (5. FTP Settings) (Continued) Item Effect FTP Function Snap Shot FTP For enabling/disabling the FTP functions. Select here if JPEG images are to be uploaded to an FTP ser ver regularly. Upload Interval File name *.jpg Time Stamp Username Password Host IP Address FTP Port FTP Folder Connection Disconnect every time Specify the interval with which images are uploaded to an FTP server.
6-5 Viewing Still Images Still Image Page: http://******/still-e.html (*******represents the URL of VN-C10.) This page displays only still images. The initial image is the one taken in by the camera at the moment browsing starts. To update the image, press [Refresh] or [Reload] depending on the Web browser and to save the displayed image, select [Save As]. Hyperlink to the Home page 73 VN-C10_E_62-78.
Operations (Step 6 Operations with a Web Browser) 6-6 Viewing Moving Images Moving Image Page: http://******/java-e.html (****** represents the URL of VN-C10.) This page displays only moving images. The images taken in by the camera are updated automatically and displayed as moving images. Note • Moving image pages cannot be saved using the [Save Image As] function of the Web browser. • Web pages cannot be saved using the [Save As] function. Hyperlink to the top page 74 VN-C10_E_62-78.
6-7 VN-C10 Image Link VN-C10 output images can be pasted onto separately created web pages – Images (still and moving) captured with VN-C10 can be incorporated and displayed on a usercreated web page. Note Images cannot be displayed when VN-C10 is in the MPEG4 mode. Displaying a Still Image: By creating a web page with the following description, you can display a still image. ( ****** represents the URL of VN-C10.
Others Troubleshooting Symptoms Remedial Actions Forgotten the VN-C10 IP address that was changed with [V.Networks Setup Tool]. • Press the [Search] button of [V.Networks Setup Tool] to see the IP addresses of all the cameras connected to the network. Unable to record. • Has the folder for saving images been deleted? Check to see if it exists. • Is the disk full? Check the available memory capacity. While “Now Connecting…” is being displayed, it takes time to cancel an action.
Others Specifications LAN standard Communication protocol Image pickup device Available pixels Video S/N ratio Minimum required illumination Image compression Output image format Lens mount Alarm input Alarm output Network interfaces Internal memory Power supply voltage Power consumption Operating temperature Mass IEEE802.3, IEEE802.3u TCP/IP, UDP, HTTP, FTP, ICMP, ARP, RTP, RTSP, DHCP, NTP 1/3 type IT CCD Approx. 380,000 pixels (768 (H) x 494 (V)) 50 dB (50 %, AGC OFF, Compression rate: 1) 2.
VN-C10 V.NETWORKS VICTOR COMPANY OF JAPAN, LIMITED R R is a registered trademark owned by VICTOR COMPANY OF JAPAN, LTD. is a registered trademark in Japan, the U.S.A., the U.K. and many other countries. © 2003 VICTOR COMPANY OF JAPAN, LIMITED 78 VN-C10_E_62-78.
