XL-MC334BK LVT0022-001B [J] COMPACT COMPONENT SYSTEM COMPACT DISC AUTOMATIC CHANGER XL-MC334BK XL-MC334 COMPACT DISC AUTOMATIC CHANGER CONTINUE ONE DISC PROGRAM POWER CLEAR DISC CALL OPEN/CLOSE STOP/CLEAR PLAY/PAUSE OPEN/ CLOSE TRACK EXCHANGE RANDOM INTRO PLAY MODE CALL < REPEAT CURSOR ENTER > CANCEL 11 DISPLAY RANDOM INTRO REPEAT CHARACTER TITLE INPUT DISC SEARCH USER FILE DISC/TRACK / DOWN UP STANDBY 200 POWER +10DISC ENTER CANCEL –1DISC –10DISC +1DISC DISPLAY 2
XL-MC334BK LVT0022-001B [J] WARNING AND CAUTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK) . NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
XL-MC334BK LVT0022-001B [J] INTRODUCTION Thank you very much for purchasing this JVC product. We sincerely hope it proves its quality and performance to your full satisfaction. Please read the instructions contained in this manual in order to get the most out of the product’s capability and performance. If there are any questions concerning the product, please consult your JVC dealer. XL-MC334BK main features The XL-MC334BK Compact disc automatic changer provides many sophisticated features.
XL-MC334BK LVT0022-001B [J] PRECAUTIONS SETTING UP Installation Connecting the unit • Select the best location Select a level location to install this unit, where it is free from extremes of temperature (5 to 35°C, or 41 to 95°F) and humidity, dust, or vibration. If noise interference is caused when receiving AM broadcast by a tuner/receiver located nearby, relocate it or this unit, or turn off either one.
XL-MC334BK LVT0022-001B [J] 3. TEXT COMPU LINK connection If you are using a JVC audio amplifier/receiver supporting TEXT COMPU LINK, connect either one of the TEXT COMPU LINK ports on the back of the unit with the amplifier/receiver’s TEXT COMPU LINK port using the supplied TEXT COMPU LINK cord (green).
XL-MC334BK LVT0022-001B [J] FRONT PANEL AND REMOTE CONTROL Front panel Numbers in brackets following button names indicate their counterparts on the remote control.
XL-MC334BK LVT0022-001B [J] 15 4 (track skip/search backward) button [ 19 , 22 ] Skips tracks or searches for a track backward. Holding down this button causes playback to fast backward. Also moves the cursor backward during the character input. 16 ¢ (track skip/search forward) button [ 21 , 24 ] Skips tracks or searches for a track forward. Holding down this button causes playback to fast forward. Also moves the cursor forward during character input.
XL-MC334BK LVT0022-001B [J] Remote control Numbers in brackets following button names indicate their counterparts on the front control. 2 4 POWER button [ 5 CLEAR button 3 Clears the contents of the Program and Disc information. CONTINUE ONE DISC PROGRAM POWER 1 CLEAR CALL OPEN/ CLOSE 5 9 DISC ] 1 4 6 6 CALL button [ 12 ] 7 7 OPEN/CLOSE button [ 8 DISC button [ TRACK 8 24 4 ] ] Selects the numeric button function for disc number entry.
XL-MC334BK LVT0022-001B [J] BASIC OPERATION 3. Place the disc in a slot, with its label facing to the left. Turning the power on OPEN/CLOSE Check that the STANDBY indicator on the front panel is lit. Then press the POWER button either on the front panel or remote control.
XL-MC334BK LVT0022-001B [J] 2. To unload or change discs in other slots, turn the DISC/TRACK jog dial or press the / / / buttons to specify the slot number, which is shown as the “DISC” number on the display. Then press the DISC EJECT button to raise the disc up. 2 Selecting a disc • Method 1 Press the DISC button, then use the DISC/TRACK jog dial on the front panel or the numeric buttons to select a disc.
XL-MC334BK LVT0022-001B [J] 3 Selecting a track • Skipping discs/tracks during playback If you want to listen to the selected disc from a desired track instead of the first track, select the track by one of the methods below. To skip discs or tracks during playback, the same basic methods as described in “2 Selecting a disc” on page 8 or “3 Selecting a track” on page 9 can be used.
XL-MC334BK LVT0022-001B [J] CONTINUE MODE PLAYBACK Every loaded disc can be played back entirely in the numerical order in the CONTINUE mode. After the playback of the last disc ends, the playback begins again from the first disc. Discs and tracks can be played back randomly from all the loaded discs (RANDOM function). One track can be played back repeatedly in the basic mode as well as when the RANDOM function is selected (REPEAT-1 function).
XL-MC334BK LVT0022-001B [J] ONE DISC MODE PLAYBACK One disc can be selected and played back entirely in the ONE DISC mode, like a standard CD player. Playing back the disc repeatedly Every track of the disc can be played back once in a random order (RANDOM function). To repeatedly playback the entire disc selected in Step 2 above, press the REPEAT button to show “REPEAT” on the display. Then press the 3/8 button.
XL-MC334BK LVT0022-001B [J] PROGRAM MODE PLAYBACK Discs and tracks can be selectively specified in a program and played back according to the program in the PROGRAM mode. The entire program can be played back repeatedly (REPEAT function) or one program step can be selected and played back repeatedly (REPEAT 1 function). Reviewing the steps: Pressing the CALL button displays the step in the programmed order. Deleting a step: Press the CALL button as many times as required to display a step to be deleted.
XL-MC334BK LVT0022-001B [J] Playing back a program step repeatedly You can listen to a selected step of the program repeatedly. 1. Press the 3/8 button to start playback. STOP/CLEAR PLAY/PAUSE / or (Remote control) 2. Select the step you want to listen to repeatedly using the 4 and ¢ buttons. / < CURSOR > or (Remote control) 3. Press the REPEAT button twice to show “REPEAT 1” on the display.
XL-MC334BK LVT0022-001B [J] SHOWING DISC INFORMATION You can see the disc information in a CD text disc on the display, as well as the information of a normal CD stored manually. With CD Text discs The disc information in a CD Text disc consists of Disc title, Track title, Performer, Genre, Song writer, Composer, Arranger and Message. However, it depends on which information are recorded on discs.
XL-MC334BK LVT0022-001B [J] ENTERING DISC INFORMATION You can manually store the Title information of each normal audio CD. Each Title information includes Disc title, Performer and Genre, and is displayed when the disc is selected. (See “SHOWING DISC INFORMATION” on page 14.) Title information stored may also be used for the search operation. (See “SEARCHING FOR A DISC” on page 17.) NOTE: You can store a Title not only while playback is stopped but also during playback.
XL-MC334BK LVT0022-001B [J] 4. Press the TITLE INPUT button. [Preset genres] TITLE INPUT TITLE INPUT or (Remote control) The disc title is stored and “PERFORMER” lights instead of “DISC TITLE” on the display, The leftmost disc information area blinks, prompting for character entry of the performer name. 5. Enter the performer name by following the “How to enter characters” on the previous page. 6. Press the TITLE INPUT button.
XL-MC334BK LVT0022-001B [J] SEARCHING FOR A DISC You can search for a disc you want to listen to using the Title information: Disc title, Performer or Genre. For a normal CD, Title information can be stored manually by following the procedures in “Storing Title information” on page 15. For a CD Text disc, by reading its pre-recorded disc information, the unit memorizes Disc title, Performer and Genre information.
XL-MC334BK LVT0022-001B [J] USER FILE You can enroll discs in the unit to 8 user files. While a user file is recalled, pressing the 3/8 button starts playback of the discs in the file in the enrolled order. You can enroll up to 32 discs to each user file and assign a name to it. Assigning a user file name 1. Press the USER FILE button as many times as required until the user file to which you want to assign a name is shown.
XL-MC334BK LVT0022-001B [J] Deleting a disc from the user file 1. Call the disc to be deleted by following the procedures described in “Checking user file contents”. 2. Press the CANCEL button. CANCEL CANCEL or (Remote control) NOTE: • If you want to delete the disc just enrolled, you do not need to press the CALL button because the disc title is shown on the display. • To clear all the user file contents, delete discs enrolled in the user file one by one.
XL-MC334BK LVT0022-001B [J] RESERVE FUNCTION You can reserve the following tunes to be played back while listening to music, without interrupting your enjoyment. The reserve function is available only in the CONTINUE mode. Reserving the following tunes to be played back 1. Select the disc during playback in the CONTINUE mode, by pressing the DISC button then using the DISC/TRACK jog dial on the front panel or the numeric buttons on the remote control.
XL-MC334BK LVT0022-001B [J] TEXT COMPU LINK SYSTEM COMPU LINK-3 REMOTE CONTROL SYSTEM Using the XL-MC334BK with JVC’s amplifier/receiver and/or MD recorder equipped with the TEXT COMPU LINK remote control system offers the following advantages. The COMPU LINK system, which is a remote control system developed by JVC, links JVC audio components to establish systematized operation control of the linked components.
XL-MC334BK LVT0022-001B [J] HANDLING AND TAKING CARE OF DISCS Handling compact discs Protect the disc from being scratched, warped, or damaged in any way — the plastic disc can easily be damaged and the damaged disc disrupts sound reproduction and operation of the player. SPECIFICATIONS & PACKING LIST General Readable discs: Power requirements: Power consumption: Audio compact discs AC 120V Ó , 60Hz 12 W (POWER ON), 6.0 W (STANDBY mode) 7.8 kg (17.2 lbs) 435 x 199.5 x 482.
XL-MC334BK LVT0022-001B [J] TROUBLESHOOTING What appears to be a malfunction may not always be serious and can easily be corrected. The table below describes some typical problems and their remedies. Check them before calling your JVC dealer. Symptom The CD can not be played back. The sound is intermittent or harsh. The remote control does not work properly. The component does not operate. Possible Cause Remedy The CD is not loaded. Load the disc.
QUALITY SERVICE HOW TO LOCATE YOUR JVC SERVICE CENTER TOLL FREE : 1-800-537-5722 Dear customer: In order to receive the most satisfaction from your purchase, read the instruction booklet before operating the unit. In the event that repair is necessary, or for the address nearest your location, please refer to the factory service center list below or within the Continental United States, Call 1-800-537—5722 for your authorized servicer. Remember to retain you Bill of Sale for Warranty Service.
LIMITED WARRANTY AUDIO-1 JVC COMPANY OF AMERICA warrants this product and all parts thereof, except as set forth below ONLY TO THE ORIGINAL PURCHASER AT RETAIL to be FREE FROM DEFECTIVE MATERIAL AND WORKMANSHIP from the date of original retail purchase for the period as shown below. (“The Warranty Period.”) PARTS LABOR 1YR 1YR THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY(50) UNITED STATES, THE DISTRICT OF COLUMBIA AND IN COMMONWEALTH OF PUERTO RICO.
XL-MC334BK LVT0022-001B [J] VICTOR COMPANY OF JAPAN, LIMITED EN.
