Specification Sheet

42
MEGA DUO OVAL
MEGA DUO OVAL
WITH MOULDED PANEL
inch mm inch mm
Model No. 184 184 184-7 184-7
External length a 70.87 1800 70.87 1800
External width b 35.43 900 35.43 900
Depth c 17.72 450 17.72 450
External length (bottom) a
1
– – 54.33 1380
External width (bottom) b
1
– – 21.26 540
Overall height with panel c
1
– – 22.83 580
Internal length (top) d 66.14 1680 66.14 1680
Internal length (bottom) e 50.79 1290 50.79 1290
Internal width (top) f
1
; f
2
30.71; 25.20 780; 640 30.71; 25.20 780; 640
Internal width (bottom) g 14.17 360 14.17 360
Height with feet h 22.24-23.62 565-600 22.24-23.62 565-600
Height of rim i 1.97 50 1.97 50
Distance top edge to centre of overfl ow hole j 2.76 70 2.76 70
Distance tub edge to centre of drain hole k 35.43 900 35.43 900
Diameter of overfl ow hole l 2.05 52 2.05 52
Diameter of drain hole m 2.05 52 2.05 52
Distance foot end of tub edge to centre of foot n 19.29 490 19.29 490
Distance between the feet o 32.28 820 32.28 820
Max. width of feet p 18.90 480 18.90 480
Width of rim (foot end; lengthwise) s
1
; s
2;
s
3
2.36; 2.36; 5.12 60; 60; 130 2.36; 2.36; 5.12 60; 60; 130
Distance between centre holes u 12.20 310 12.20 310
Armrest depth v 5.51 140 5.51 140
Water volume** in gallons 49.14 49.14
Weight of the enamelled bath tub in lbs 121.25 –

bathing with a friend: two identical back rests and centrally
positioned outlet

wide arm rests on both sides provide optimum bathing comfort

made of Kaldewei steel enamel 3.5 mm

the moulded panel emphasises the high design standard and
enables the bath to be free-standing
Subject to technical alterations and tolerances.
** 18.49 gallons displacement on average.
