TM PVS10921 Q Portable DVD Player with LCD Display R D I G I TAL PHOTO OWNER'S MANUAL Model: PVS10921 English 811-109291-020 Printed in China 1
SAFETY PRECAUTIONS The lightning flash with an arrowhead symbol, within the equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to cause an electric shock. CAUTION WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
IMPORTANT SAFETY INSTRUCTIONS 1. 2. 3. 4. 5. Read Instructions - All the safety and operating instructions should be read before you use the unit Keep the Instructions - The safety and operating instructions should be kept for future reference. Pay Attention to Warnings - All warnings on the unit and in this user's manual should be followed. Follow Instructions - All operating and use instructions should be followed.
TABLE OF CONTENTS Repeat Playback ................................... 18 Safety Precautions ..................................1 Important Safety Instruction ................. 2 Table Of Contents .................................... 3 Disc Formats ............................................ 4 Accessories ............................................... 5 Remote Control ........................................ 5 Control Reference Guide .................... 6-7 Power Supply ...................................
DISC FORMATS The unit can playback. DVDs [8cm/12cm disc] Compatible Audio CDs [8cm/12cm disc] Region Management Information Region Management Information: This unit is designed and manufactured to respond to the Region Management Information that is encoded on DVDs. If the Region number printed on the DVD does not correspond to the Region number of this unit, it cannot play that disc. The region number of this unit is 1.
ACCESSORIES Please locate the included accessories: Remote control (with battery) ........................................................................................... x 1 AC adaptor .......................................................................................................................... x 1 AC power cord ................................................................................................................... x 1 Audio/V ideo cable ...........................................
CONTROL REFERENCE GUIDE Remote Control 1 2 3 4 5 6 TV MODE STOP PLAY PREV PAUSE SEARCH MEM ANGLE M 8 15 GOTO 14 NEXT 13 12 11 10 DISPLAY AUDIO ENTER 2 7 MENU 3 SUBTITLE/RETURN 4 5 6 7 8 9 9 0 SETUP A-B DISC REPEAT REPEAT A-B / DISC buttons Perform point-to-point repeat playback on a DVD or CD. Repeat a DVD chapter or title. Repeat a CD track or the entire disc. 9) SUBTITLE / RETURN button Select one of the subtitle languages programmed on a DVD (if available).
CONTROL REFERENCE GUIDE Unit 14 12 11 13 DC IN 9V CAR PLUG 12V 10 1 9 1) 8 7 6) - VOLUME + button Adjusts the volume up (+) and down (-). MENU button Open and close DVD's menu. 2) 3) 4) 5) 7) 8) PAUSE button Press to pause playback of disc. Each time you subsequently press the PAUSE button the picture advances one frame at a time. Press the PLAY button to resume playback at normal speed.
E - 8
POWER SUPPLY C. Using the rechargeable battery pack • Charge the battery for at least 4-5 hours before using it for the first time. The charging light will go out when the battery is fully charged. When recharging the battery, disconnect it from the unit. RECHARGEABLE BATTERY PACK PO WER POWER indicator FOR BATTERY CHARGE Use the supplied AC adaptor. Never dispose of in fire or heat up. Do not use in high temperature or near heat sources. Never connect the positive and negative poles with metal.
POWER SUPPLY Disconnecting rechargeable Battery Pack from the unit. Push the button to disconnect the RECHARGEABLE BATTERY PACK FOR BATTERY CHARGE Use the suppli ed AC adaptor. Never dispose of in fire or heat up. Do not use in hi gh temperature or near heat sources. Never c onnect t he pos iti ve and negativ e poles with metal. Do not open the cover, ref er servicing only to qual ifi ed servi ce personnel. BAT T.
CONNECTING OTHER EQUIPMENT A. Connecting the unit to a TV • If your TV has Audio/Video inputs, you can connect the unit to your TV using the included Audio/Video cable. Right side of unit AUDIO VIDEO OUT OUT TV To AV OUT Jacks (Yellow) VIDEO IN (Red) AUDIO/VIDEO CABLE (included) AUDIO/VIDEO CABLE AUDIO IN (White) Watching a DVD on your TV 1. Turn on the unit, slide the AV IN / DVD switch to select "DVD". 2. Turn on the TV and follow the instructions provided with it to play the DVD.
CONNECTING OTHER EQUIPMENT Using Headphones/Earphones • Turn down the volume before connecting, and then adjust the volume level. • When headphones/earphones are connected, no sound will be output from the unit's speakers. Right side of unit AUDIO VIDEO OUT OUT Caution: • Avoid listening to sound at levels which may be harmful to your ears. Note: • When headphones are connected to the unit, the speakers are automatically disabled. HEADPHONES / EARPHONES (3.
DVD CD PLAYING A DISC Basic playback This owner’s manual explains the basic instructions for operating this unit. Some DVDs are produced in a manner that allows specific or limited operation during playback. Therefore, this unit may not respond to all operating commands. THIS IS NOT A DEFECT. Please refer to the instructions accompanying the specific DVD in question for more information about the options available on that DVD. “ ” may appear on the screen during operation.
DVD CD PLAYING A DISC Basic playback Fast Forward/Fast Reverse 1. Press the SEARCH or SEARCH button of the remote unit when a disc is playing. • The disc begins a fast scan at two times normal (x2) speed. or SEARCH button is pressed, the speed of the fast • Four speeds are available. Each time the SEARCH scan changes. Note : You also can press and hold 2. Press the / (PREV/NEXT) buttons on unit repeatedly to select different fast scan speeds.
PLAYING A DISC Subtitle selection 1. While a DVD is playing, press the SUBTITLE / RETURN button to display the current language setting, as shown in the diagram. 2. Press the SUBTITLE / RETURN button repeatedly to select the desired subtitle language. 1/3 Eng Notes : • If only one language is recorded, the language does not change. • About two seconds after selecting the subtitle language, playback continues with the new subtitle you selected.
DVD CD SPECIAL FUNCTIONS Basic playback DISPLAY function DVD Using DISPLAY, you can check and change the current settings of the following items: ANGLE, AUDIO and SUBTITLE. • While the disc is playing, press the DISPLAY button of the remote unit to display the screen as shown in diagram. Elapsed time: Elapsed time from the beginning of the chapter which is currently playing. Remaining time: Remaining time of the title which is currently playing.
CD / DVD PROGRAMMABLE MEMORY Programmable memory The two types of programmed playback provided by this unit are title programmed playback and chapter programmed playback. Title / Chapter programmed playback 1. Press the MEMORY button while the disc is stopped. 2. Enter the title numbers in in - - . -- . Use or button to highlight your desired chapter and enter the chapter numbers 3. Use , , or button to move to another field. 4. Repeat steps 2 to 3. 5.
DVD REPEAT PLAYBACK You can play a specific title or chapter repeatedly. (Title repeat, chapter repeat, A-B repeat) REPEATING A DVD TITLE While the disc is playing, press the REPEAT DISC button until the “ Repeat Title ” indicator displays on the screen. The current title is played repeatedly. Repeating a specific section You can play a specific section repeatedly. 1.
PLAYING MP3 AND PICTURE FILES This unit can play MP3 and Picture files recorded on CD-R and CD-RW discs. Playing a MP3 /Picture file disc 1. Insert the MP3/Picture file disc. 2. Close the disc door. 3. The unit will load the disc and automatically display the contents of the disc on the screen, while also beginning to play the first MP3 file or Picture files. Each file will be played one after another. 4.
CUSTOMIZING THE FUNCTION SETTINGS LANGUAGE setting 1. Press the SETUP button in stop mode. 2. Use or button to select a language, then press the ENTER button. The screen will change to your selected language immediately. 3. To exit the SETUP MENU and return to the normal screen, press the RETURN or SETUP button. VIDEO setting 1. Press the SETUP button in stop mode. 2. Use or button to select Video, then press the ENTER button. or button to select the options (TV Shape, Brightness or 3.
CUSTOMIZING THE FUNCTION SETTINGS RATING Some DVDs are equipped with a password function and are rated according to their content. The contents allowed by parental lock levels and the way a DVD is controlled may vary from disc to disc. For example, if the disc allows, you could lock-out violent scenes unsuitable for children or you could lock out playback of the disc altogether. 1. Press the SETUP button in stop mode. 2. Use or button to select the Rating, press the ENTER button. 3.
LANGUAGE CODE LIST FOR DISC LANGUAGE Code Language Name Code Language Name Code Language Name Code Language Name AA AB AF AM AR AS AY AZ BA BE BG BH BI BN BO BR CA CO CS CY DA DE DZ EL EN EO ES ET EU FA FI FJ FO FR Afar Abkhazian Afrikaans Ameharic Arabic Assamese Aymara Azerbaijani Bashkir Byerlorussian Bulgarian Bihari Bislama Bengali Bangla Tibetan Breton Catalan Corsican Czech Welsh Danish German Bhutani Greek English Esperanto Spanish Estonian Basque Persian Finnish Fiji Faroese French Frisian Irish
MAINTENANCE Cleaning Disc A defective or dirty disc inserted into the unit can cause sound to drop out during playback. Handle the disc by holding its inner and outer edges. • Do NOT touch the surface of the unlabeled side of the disc. • Do NOT stick paper or tape on the surface of the disc. • Do NOT expose the disc to direct sunlight or excessive heat. • Clean the disc before playback. Wipe the disc from the center outward with a cleaning cloth.
TROUBLE SHOOTING GUIDE SYMPTOM CAUSE (AND REMEDY) No power. • Make sure that the AC adapter is connected. • Make sure that the unit is turned on. The remote control does not function. • Make sure the infrared remote sensor is not blocked. • Make sure the plastic sheet has been removed from the remote. • Point the remote directly at the infrared remote sensor on the unit. • Replace the battery in the remote with a new one.
