User manual

Important information
22/200
CAUTION!
Risk of damage!
● Never clean the charging station using spray water (from a hose, high-pressure cleaner
etc.) to clean the charging station!
● Pull the charging cable out of the plug connection by the plug only and not by the cable.
● Make sure that the charging cable is not damaged mechanically (kinked, pinched or
driven over) and do not allow the contact area to come into contact with sources of
heat, dirt or water.
1.4 Intended use
The device is a "charging station" for the indoor and outdoor area which can be used to charge electrically
operated vehicles (e.g. electric automobiles).
The charging station is designed for installation on a wall or in a floor-mounted column. The respective na-
tional regulations must be observed with regard to the installation and connection of the charging station.
The intended use of the device always includes the compliance with the environmental conditions for which
this device was developed.
The device was developed, manufactured, inspected and documented in compliance with the relevant safety
standards. Therefore, the products do not pose any danger to the health of persons or a risk of damage to
other property or equipment under normal circumstances, provided that the instructions and safety precau-
tions relating to the intended use are properly observed.
The instructions contained in this manual must be precisely followed in all circumstances. Failure to do so
could result in the creation of potential sources of danger or the disabling of safety devices. Apart from the
safety instructions given in this manual, the safety precautions and accident prevention measures appropri-
ate to the situation in question must also be observed.
Only electrical vehicles or their chargers may be connected. The connection of other devices (e.g. electric
tools) is not allowed!
Due to technical or legal restrictions, not all versions/options are available in all countries.
1.5 About this manual
This manual and the functions described apply to devices of the type:
● KeContact P20 / firmware version: v2.x (and above)
● KeContact P30 / firmware version: v3.x (and above)
Use of this manual
This manual is intended for the following groups of people:
● End-users (users of the charging station)
● Commissioning technicians, service technicians
