REPLACEMENT PARTS LIST

INdooR AIR HANdLER

B6BMM0, B6BMMX, B6BM-X, B6EMMX, B6EMMN, B6VMAX, & B6VMMX

SERIES

NoTE: SOME MODELS USE A COPPER TUBE ALUMINUM FIN COIL. MICROCHANNEL COIL SHOWN IN PICTURE.

Summary of content (8 pages)

PAGE 1
REPLACEMENT PARTS LIST Indoor Air Handler B6BMM0, B6BmmX, B6BM-X, B6EMMX, B6EMMN, B6VMAX, & B6VMMX Series 3 9 12 24 11 10 23 2 26 21 17 8 4 29 26 20 NOTE: Some models use a copper tube aluminum fin coil. Microchannel coil shown in picture.
PAGE 2
B6BMM030K-A B6BMM030K-B B6BMM036K-B B6BMM042K-B B6BMM048K-B B6BMM048K-C B6BMM060K-C DESCRIPTION B6BMM024K-B ITEM B6BMM024K-A B6BMM0 Air Handler 921145 921146 921147 921148 921150 921151 921152 921153 921154 1 PLATE, CLOSE-OFF (Not Shown) 226420R 226420R 226420R 226420R 226420R 226420R 226420R 226420R 226420R 2 BLOWER HOUSING 297210R 297212R 297210R 297212R 297212R 297212R 297212R 297214R 297219R 3 PANEL, TOP 921877 921878 921877 921878 921878 921878 921878
PAGE 3
B6BM-X30K-A B6BM-X30K-B B6BM-X36K-B B6BM-X42K-B B6BM-X48K-C B6BM-X60K-C DESCRIPTION B6BM-X24K-B ITEM B6BM-X24K-A B6BM-X Series Air Handler 921312 921313 921314 921315 921316 921317 921318 921319 1 PLATE, CLOSE-OFF (Not Shown) 226420R 226420R 226420R 226420R 226420R 226420R 226420R 226420R 2 BLOWER HOUSING 297210R 297212R 297210R 297212R 297212R 297212R 297214R 297219R 3 PANEL, TOP 921877 921878 921877 921878 921878 921878 921879 921879 4 DOOR, FILTER 921874
PAGE 4
B6BMMX30K-A B6BMMX30K-B B6BMMX36K-B B6BMMX42K-B B6BMMX48K-C B6BMMX60K-C DESCRIPTION B6BMMX24K-B ITEM B6BMMX24K-A B6BMMX Series Air Handler 922082 922083 922084 922085 922086 922087 922088 922089 1 Plate, Close Off (Not Shown) 226420R 226420R 226420R 226420R 226420R 226420R 226420R 226420R 2 Blower Housing 297210R 297212R 297210R 297212R 297212R 297212R 297214R 297214R 3 Panel, Top 921877 921878 921877 921878 921878 921878 921879 921879 4 Door, Filter 921874
PAGE 5
DESCRIPTION B6EMMNX60K-C ITEM B6EMMNX36K-B B6EMMN Series Air Handler 922467 922470 1 PLATE, CLOSE-OFF (Not Shown) 226420R 226420R 2 BLOWER HOUSING 297217R 297219R 3 PANEL, TOP 921878 921879 4 DOOR, FILTER 921875 921876 5 PLATE, TUBE CLOSE-OFF (Not Shown) 921880 921880 6 HARNESS, FSHE / VSHE, UPPER (Not Shown) 2C0251R 2C0251R 7 HARNESS, FSHE, LOWER, (Not Shown) 2C0252R 2C0252R 8 MOTOR, BLOWER 622500R 622501R 9 TRANSFORMER 622036R 622036R 10 CAPACITOR 11 — — BOA
PAGE 6
B6EMMX30K-A B6EMMX30K-B B6EMMX36K-B B6EMMX42K-B B6EMMX48K-C B6EMMX60K-C DESCRIPTION B6EMMX24K-B ITEM B6EMMX24K-A B6EMMX Series Air Handler 921155 921156 921157 921158 921159 921160 921162 921163 1 PLATE, CLOSE-OFF (Not Shown) 226420R 226420R 226420R 226420R 226420R 226420R 226420R 226420R 2 BLOWER HOUSING 297210R 297217R 297210R 297217R 297217R 297217R 297219R 297219R 3 PANEL, TOP 921877 921878 921877 921878 921878 921878 921879 921879 4 DOOR, FILTER 921874
PAGE 7
B6VMAXX30K-A B6VMAXX30K-B B6VMAXX36K-B B6VMAXX42K-B B6VMAXX48K-C B6VMAXX60K-C DESCRIPTION B6VMAXX24K-B ITEM B6VMAX24K-A B6VMAX Series Air Handler 921164 921165 921166 921167 921168 921169 921171 921172 1 PLATE, CLOSE-OFF (Not Shown) 226420R 226420R 226420R 226420R 226420R 226420R 226420R 226420R 2 BLOWER HOUSING 297210R 297217R 297210R 297217R 297217R 297217R 297219R 297219R 3 PANEL, TOP 921877 921878 921877 921878 921878 921878 921879 921879 4 DOOR, FILTER
PAGE 8
B6VMMXX30K-A B6VMMMXX30K-B B6VMMXX36K-B B6VMMXX42K-B B6VMMXX48K-C B6VMMXX60K-C DESCRIPTION B6VMMXX24K-B ITEM B6VMMX24K-A B6VMMX Series Air Handler 922289 922290 922291 922292 922293 922294 922295 922296 1 PLATE, CLOSE-OFF (Not Shown) 226420R 226420R 226420R 226420R 226420R 226420R 226420R 226420R 2 3 4 BLOWER HOUSING 297210R 921877 921874 297217R 921878 921875 297210R 921877 921874 297217R 921878 921875 297217R 921878 921875 297217R 921878 921875 297219R 921879 921876 2
