1© KEMET Electronics Corporation • KEMET Tower • One East Broward Boulevard FS8005_MSR • 9/9/2020

Fort Lauderdale, FL 33301 USA • 954-766-2800 • www.kemet.com

Built Into Tomorrow

Benets

• Magneticuxconvergenceimprovement–increasesthe

relativepermeability(u’)whilekeepingthemagneticloss

(u”) low.

• Effective carrier frequency 13.56 MHz and below

• Resistanttoshock,notbrittle

• Thin,exiblematerialusedinportableequipment

• Virtuallynolimitationinwhereitcanbeused

• Less time required for installation

• Easilycutintoanyshape

• EasilylaminatestheFLEXSUPPRESSORrolltothetagroll

• RoHScompliantandhalogen-free

Overview

TheKEMETMagneticSheetforradiofrequency

identication(RFID)FLEXSUPPRESSORprevents

interference between a loop antenna and metallic objects

andeffectivelyimprovesthecommunicationrangeofRFID.

Theexiblesheetisapolymerbase,blendedwithmicron-

sizedmagneticpowdersdispersedthroughoutthematerial.

Thesesheetsimprovethemagneticuxconvergenceand

canbecutintoavarietyofshapesandsizes.

Applications

•Cellphonewithradiofrequencyidentication(RFID)

function

• ContactlessICcard

• RFIDreader/writer

• RFIDtag

FLEXSUPPRESSOR

Magnetic Sheet for RFID

SheetType Roll Type

Summary of content (10 pages)

PAGE 1
FLEX SUPPRESSOR® Magnetic Sheet for RFID Overview Applications The KEMET Magnetic Sheet for radio frequency identification (RFID) FLEX SUPPRESSOR prevents interference between a loop antenna and metallic objects and effectively improves the communication range of RFID. • Cell phone with radio frequency identification (RFID) function • Contactless IC card • RFID reader/writer • RFID tag The flexible sheet is a polymer base, blended with micronsized magnetic powders dispersed throughout the material.
PAGE 2
FLEX SUPPRESSOR® Magnetic Sheet for RFID Part Number System M4 (100)- 240X240 T0800 Series Thickness Standard Dimensions Adhesive Tape Thickness (100) = 0.1 mm (200) = 0.2 mm (300) = 0.3 mm (01) = 0.1 mm (02) = 0.2 mm (025) = 0.25 mm (03) = 0.
PAGE 3
FLEX SUPPRESSOR® Magnetic Sheet for RFID Table 1 – Ratings & Part Number Reference Part Number Series Thickness Tape Thickness Permeability at 13.56 MHz Specific Gravity Surface Resistivity Weight mm mm µ Typical Ω/sq. typical g 7 M4(100)-185X70T0800 M4(100)-240X10M M4(100)-240X10MT0800 M4(100)-240X240T0800 M4(100)-240X50M M4(100)-240X50MT0800 M4(100)-90X70T0800 M4(200)-185X70T0800 M4 M4 M4 M4 M4 M4 M4 M4 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.2 0.03 -0.03 0.03 -0.03 0.03 0.
PAGE 4
FLEX SUPPRESSOR® Magnetic Sheet for RFID Applications Communication disturbance by metal (degraded communication range) Transmission distance decreases IC Card Magnetic energy is consumed as electric current inside the metal Effect of magnetic sheet (improved communication range) Transmission distance increases Functions as magnetism deflection yoke FLEX SUPPRESSOR® Metal part (e.g.
PAGE 5
FLEX SUPPRESSOR® Magnetic Sheet for RFID Applications cont. Communication distance evaluation of a cell phone RFID antenna.
PAGE 6
FLEX SUPPRESSOR® Magnetic Sheet for RFID Examples of Shapes KEMET FLEX SUPPRESSOR sheets can be cut into a variety of shapes and sizes: With holes, cut-out shapes, and circular shapes Reel Precut Roll With Aluminum or PET sheet Some examples of customization, available upon request: • The use of PET film in the front, for insulation or mechanical support • The use of aluminum sheet in the front, for shielding effect • The use of different adhesive tapes on the back - stronger, thinner, thicker, etc.
PAGE 7
FLEX SUPPRESSOR® Magnetic Sheet for RFID Permeability Characteristics M4 50 13.56 MHz Permeability µ 40 30 20 10 0 1 10 100 1,000 100 1,000 Frequency [MHz] RM4A 60 13.56 MHz Permeability µ 50 40 30 20 10 0 1 10 Frequency [MHz] © KEMET Electronics Corporation • KEMET Tower • One East Broward Boulevard Fort Lauderdale, FL 33301 USA • 954-766-2800 • www.kemet.
PAGE 8
FLEX SUPPRESSOR® Magnetic Sheet for RFID Handling Precautions Avoid high temperature, humidity and direct sunlight. Storage environment should be below 40°C and below 70% relative humidity. The surface resistance value listed in this catalog is a reference value of the circuit parameter to indicate noise suppression. The value does not represent the product’s insulation characteristics. The value may become lower if an excess pressure is applied to the product.
PAGE 9
FLEX SUPPRESSOR® Magnetic Sheet for RFID Information on environmentally influential substances The FLEX SUPPRESSOR does not contain any of the substances listed below: (1) Ozone depleting substance • CFC (chlorofluorocarbon) • Halon • Carbon tetrachloride • 1,1,1-Trichloroethane • HCFC (hydrochlorofluorocarbon) • HBFC (hydrobromfluorcarbon) • Methyl bromide (2) Substances regulated by EU RoHS Directive 2011/65/EU and EU Directive 2015/863 • Lead and lead compound • Mercury and mercury compound • Cadmium an
PAGE 10
FLEX SUPPRESSOR® Magnetic Sheet for RFID KEMET Electronics Corporation Sales Oﬃces For a complete list of our global sales offices, please visit www.kemet.com/sales. Disclaimer All product specifications, statements, information and data (collectively, the “Information”) in this datasheet are subject to change. The customer is responsible for checking and verifying the extent to which the Information contained in this publication is applicable to an order at the time the order is placed.
