Datasheet

KEMET Part Number: T598D337M006ATE080
T598, Tantalum, Polymer Tantalum, 330 uF, 20%, 6.3 VDC, SMD, Polymer, Molded, Low ESR, AEC-Q200, 80 mOhms, 7343,
Height Max = 3.1mm
Dimensions
Footprint 7343
L 7.3mm +/-0.3mm
W 4.3mm +/-0.3mm
H 2.8mm +/-0.3mm
T 0.13mm REF
S 1.3mm +/-0.3mm
F 2.4mm +/-0.1mm
A 3.8mm MIN
B 0.5mm +/-0.15mm
P 0.9mm REF
R 1mm REF
X 0.1mm +/-0.1mm
Packaging Specifications
Weight: 434.83 mg
Packaging: T&R, 178mm
Packaging Quantity: 500
General Information
Supplier: KEMET
Series: T598
Dielectric: Polymer Tantalum
Style: SMD Chip
Description:
SMD, Polymer, Molded, Low
ESR, AEC-Q200
Features: Automotive
RoHS: Yes
Termination: Tin
Qualifications: AEC-Q200
AEC-Q200: Yes
Shelf Life: 52 Weeks
MSL: 3
Specifications
Capacitance: 330 uF
Capacitance Tolerance: 20%
Voltage DC:
6.3 VDC (105C), 4.22 VDC
(125C)
Temperature Range: -55/+125C
Rated Temperature: 105°C
Humidity: 85C, 85% RH, load, 1000 Hours
Dissipation Factor: 10.00% 120Hz 25C
Failure Rate: N/A
Resistance: 80 mOhms (100kHz 25C)
Ripple Current:
1677 mAmps (100kHz 45C),
1509.3 mAmps (85C), 419.3
mAmps (125C)
Leakage Current: 207.9 uA (5min 25C)
