Table of contents Congratulations ............................................................................................................2 Selecting music ............................................................................................................8 Box contents.................................................................................................................2 Setting and using stream presets ...............................................................................
Safety precautions (continued) FCC Warning This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in this instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. Note This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Connecting the DT-7000S to your audio system Use the cables supplied with the DT-7000S to make these connections. About the RS-232C connection: The RS-232C connection is provided to allow the DT-7000S to be controlled by compatible 3rd-party control systems. Kenwood recommends that this connection only be used by experienced professional system installers. DO NOT connect the RS-232C connection to a computer—it is NOT COMPATIBLE with personal computers.
Finding a location for the optional Kenwood CX-SRH30 antenna Due to the paths of the SIRIUS satellites over the US, the best location for the antenna will depend on what part of the country you live in, the orientation of your home, and the locations of any obstructions that could prevent the satellite signal from reaching the antenna. A. Use this map as a general placement guideline—some experimentation may be needed to obtain the best reception in your particular situation. See pg.
Controls and Features Note: Buttons on the unit and remote with the same name have the same function. POWER Button (unit only): STANDBY Indicator (unit only): Power Off/On Buttons (remote only): Remote Control Receiver: Category Jog Dial (unit)/CAT Buttons (remote): DIRECT Button: Turns the DT-7000S on and puts it into the Standby mode. Emit discrete codes to turn the DT-7000S off and on.
Installing batteries in the remote 1. Remove the battery cover as shown in diagram #1 (right). 2. Install two AAA batteries as shown in diagram #2 (right). •Observe the polarity markings on the inside of the battery compartment 3. Replace the battery cover. Using the remote Basic operation • The supplied batteries are for operational checks, and may not last as long as alkaline batteries.
Selecting entertainment • After you make your selection, the display will revert to the Normal Operation screen In addition to the Normal Operation and Category Select screens, the DT-7000S has three ways to search for and select entertainment: by stream, by artist, and by song.
the presets. Each time you change a preset its number will appear on the display and the stream will play. Option 2: Press the ENTER button. The Preset List Screen will appear on the display, listing all of the stream presets that have been programmed in all 4 banks (right) 1. Press the SETUP button to enter the Setup Mode. 7. Press the ENTER button to save your choice (second, right). Press the SETUP button twice to exit the Setup Mode.
4. When one (or more) of the selected songs is playing on any stream, an alert screen will be superimposed over the data on the original screen (below). • The number on the screen will count down from ‘10’ to ‘0’. To hear the song, press the ENTER button before the counter reaches zero; to make the alert screen disappear, press the SETUP button on the front panel. The DT-7000S will switch to the stream that is playing the song.
5. When the display shows the correct hour and minute, press the ENTER button to turn the alarm on. Sleep Timer 6. Press the MEMO button to save your settings. The Step 2—Set Stream screen will appear (right). 1. While listening to SIRIUS, press the ENTER button to enter the Stream List mode. You can program the DT-7000S to play for 30 or 60 minutes and then automatically turn itself off. Step 2—Set Stream Screen 7.
Lock Code Setup If you have locked any streams in the Channel Lock mode, you will need to enter a 4digit lock code to unlock them. The factory default lock code is “1 1 1 1”. You can change the Lock Code to your own preference: 1. While in the Setup Mode, turn the CATEGORY jog dial (unit) or press the CAT buttons (remote) until the Lock Code Setup screen appears (top, right): 2. Turn the CH/PRESET jog dial (unit) or press the CH buttons (remote). The Lock Code screen appears (second, right): 3.
Troubleshooting guide Problem No power on DT-7000S (display not illuminated) Possible Cause Solution Power cord is not properly connected Make sure the power cord is properly connected Audio and/or digital cable is not properly connected Make sure cable is properly connected Incorrect input selected on receiver/controller Select the receiver/controller input that the DT-7000S is connected to Signal is weak or can’t be found Check the Antenna Signal screen (see page 12); Change the antenna location
DT-7000S Instruction Manual
DT-7000S Instruction Manual 15
