Data Sheet

KERN PFB600-2M
Schnellanzeigende Präzisionswaage mit komfortabler Bedienphilosophie und Eichzulassung
[M]
Measuring system
Adjustment options: External calibration
Linearity: 20 mg
n/a: 20 g
Readout [d]: 10 mg
Recommended adjusting weight: 600 g (F1)
Reproducibility: 10 mg
Resolution: 60000
Stabilisation time: 3 s
Tare range: 599,990 g
Warm up time: 2 h
Weighing range [Max]: 600 g
Weighing system: Strain gauge
Weighing units: g
Display
Display digit height: 1,500 cm
Display digit height: 5 mm
Technical data about verification
Minimum load [Min]: 500 mg
Verification approval conforming
to 2014/31/EU:
yes
Verification by KERN possible: yes
Verification class: II
Verification value [e]: 100 mg
Counting
Counting resolution: 30000
Mininum piece weight at piece
counting (Laboratory:
20 mg
Mininum piece weight at piece
counting (Normal):
200 mg
Functions
Capacity display: yes
Counting function: yes
Function to save totals: yes
Percentage determination: yes
Environmental conditions
Maximum humidity: 80 %
Maximum operating temperature: 40
O
C
Minimum ambient temperature: 5
O
C
Minimum humidity: 0 %
Power supply
Input voltage: 220 V - 240 V AC 50 Hz
n/a: CH EURO UK US
Service
Adjustment at the location of installation:961-247
DAkkS Certificate: 963-127
Verification: 965-216
Category
Brand: KERN
Category: Balances
Product Group: Precision balance
Packaging & shipping
Delivery: 24 h
Dimensions packaging (WxDxH): 260 x 335 x 255 mm
Gross weight: 2,400 kg
Net weight: 1,700 kg
Shipping method: Parcel service
Construction
Casing material: Plastic
Dimensions housing (WxDxH): 200 x 240 x 75 mm
Level indicator: yes
Material weighing plate: stainless steel
Overall dimensions mounted
(WxDxH):
200 x 240 x 155 mm
Revolving screw feet: yes
Weighing surface (d): 120
KERN & SOHN GmbH
.
Ziegelei 1
.
72336 Balingen
.
Germany
.
Tel. [phone] - 99 33-0
.
www.kern-sohn.com 1
