® DELUXE STROLLER PUSHBAR™ Assembly Instructions Model # 8135-199 Printed on 100% recycled paper! picture similar USA Tools Required: (adj. wrench) (phillips head screwdriver) (flat head screwdriver) KETTLER® International, Inc. 1355 London Bridge Road Virginia Beach, Virginia 23453 USA Email: parts@kettlerusa.com Web Address: www.kettlerusa.
USA Assembly Instructions n important information for your safety and for the correct use and maintenance of this KETTLER® product. Keep the instructions in a safe place for information or for ordering spare parts. This KETTLER® product has been designed in accordance with the latest standards of safety and subjected to constant quality monitoring. The data gained from this quality process is then incorporated in the development of our products.
USA KETTLER® Limited Warranty THERE ARE NO WARRANTIES, EXPRESSED OR IMPLIED, MADE BY EITHER THE DISTRIBUTOR OR THE MANUFACTURER ON KETTLER® PRODUCTS, EXCEPT THE MANUFACTURER’S LIMITED WARRANTY AGAINST DEFECTS IN MATERIAL SET OUT BELOW: This KETTLER® Limited Warranty applies to products sold through the KETTLER® Authorized Dealer Network to the original retail purchaser and authenticated by proof of purchase from a retailer located in the United States.
USA Checklist 1 1 1 1 1 1 1 (soft canopy) 1 (large metal tubing pieces) 1 USA Hardware NOTE: ALL HARDWARE IS PREASSEMBLED TO THE CORRESPONDING PARTS USED IN EACH STEP.
1 x1 A UAL ACT x2 ACT UAL SIZE SIZE x1 NOTE: IF ATTACHING PUSHBAR TO ASSEMBLED TRIKE, SEAT MUST FIRST BE REMOVED THEN REATTACHED AFTER COMPLETING STEP 1. 2 A NOTE: Make sure the spring clip clicks into place when inserting the push bar shell tube.
3 NOTE: Loosen slide adjusters before attempting to slide onto push bar arms by untwisting large knobs slightly.
4 ACT UAL A x2 SIZE x2 x2 A B ACT UAL SIZE x2 7
5 A ACT UAL SIZE x2 B NOTE: Secure canopy bar to arms (making sure that spring clip ‘clicks’ into place). Once secure, slide front of canopy over bar and attach back with hook and loop fastener.
6 NOTE: Snap the drink/snack tray into place. No hardware required.
USA Spare parts drawing DELUXE STROLLER PUSHBAR Model # 8135-199 12 11 17 15 14 6 4 5 7 AD JU A BL ST E 13 16 8 9 10 A D JU A BL ST E 3 2 1 When ordering spare parts, always state the full model number, spare part number, the quantity required, and the serial number of the product. Example Order: model# 8135-199/spare part# 8135-199#07/1 piece/ sn... IMPORTANT: spare part pieces do not include fastening material; if fastening material (bolts, nuts, washers, etc.
USA Spare parts list DELUXE STROLLER PUSHBAR Model # 8135-199 pos. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 description push bar adapter stroller pushbar shell tube spring clip head rest stroller pushbar connecting tube, right stroller pushbar connecting tube, left adjustment knob slide adjuster endcap slide adjuster, front slide adjuster, rear stroller pushbar grip tube drink/snack tray canopy arm, right canopy arm, left canopy spring clip canopy bar canopy qty. part no.
