Chapter 1: Product Overview
DVR User’s Manual
13
1.5 Remote Control
4-Channel / 8-Channel DVR
1 2 3
4 5 6
7 8 9
ALL
0
MENU
AUDIO/
SEARCH
MUTE
SEL
1
3
5
8
9
11
14
15
7
2
4
7
10
12
16
13
6
No. Icon Descripon
1 1 ~ 8
Numeric keys
Press to display channel 1 ~ 8.
2 9, 0
Numeric keys
Press “0” key to switch between video output monitor (HDMI/VGA or
BNC).
3
ALL Press to display all channels.
4 MENU Press to enter or exit the Main Menu.
5 SEL Press to enter the selected menu item and edit the seng.
6
Press to move up in the OSD menu.
7 Press to move le or right in the OSD menu.
8 Press to move down in the OSD menu.
9
Audio/
Search
In Playback mode, press to turn the audio on or o.
Press to search for recorded video.
10 Mute Press to turn mute on or o.
11 Press to rewind during video playback.
12 Press to play recorded video or enter the recording search menu.
13 Press to fast forward during video playback.
14 Press to start manual recording.
15
Press to pause the video playback or enter frame-playback mode.
16 Press to stop manual recording or stop the video playback.
