Chapter 1: Product Overview
10
DVR User’s Manual
1.3.2 Rear Panel
VGA
AUDIO IN (CH5-CH16)
HDMI
DC 12V
LAN
MAIN
SPOT
AUDIO OUTVIDEO OUT AUDIO IN
2
4
1
3
MAIN
SPOT
CH8
CH16
CH7
CH15
CH6
CH14
CH5
CH13
CH4
CH12
CH3
CH11
CH2
CH10
CH1
CH9
G 12345678910 11
+
- NO COM G1615141312
RS-485 OUT IN
ALARM
1 2 43 65 7 8 11 12109
No. Connector Descripon
1 Video input Connects to a maximum of 16 video input devices via BNC.
2 Video output Connects to a maximum of 2 monitors for video output via BNC.
3 Audio input Connects to a maximum of 4 audio input via BNC.
4 Audio output Connects to a maximum of 2 audio output via BNC.
5 HDMI output Connects to a monitor output via HDMI.
6 Parallel input Connects to a maximum of 12 audio input using a Parallel-to-BNC adapter.
7 VGA output Connects to a VGA monitor.
8 LAN Connects to LAN via RJ-45.
9 USB mouse Connects to a USB mouse.
10 RS-485 Connects to a Speed dome camera, sensor or alarm device via RS-485.
11 Power switch Press to turn the DVR on or o.
12 Power Connects to the power adapter.
1.4 Mouse
The DVR is supplied with a USB mouse that you can use to operate the DVR. Simply plug in the supplied mouse into
the USB mouse connector at the rear panel of the device.
Mouse Operaon Descripon
Le-click In OSD menu, click the le buon to select and edit the seng.
Right-click In preview mode, click the right buon to display the pop-up menu.
In main menu or sub menu mode, click the right buon to exit the current menu.
Double-click the Le buon Double-click the live image of any channel for full screen display. Double-click the le
buon again to return to the window-display of all cameras.
Drag an area/line In moon mode, use this funcon to select moon area.
In [Color Setup] menu mode, it will adjust color control bar.
