ENGLISH
Chapter 3: Geng Started
DVR User’s Manual
25
3.4.2 Split Mode
You can customize the 16 channels to be displayed separately on a 4-window or 9-window display or show all 16
channels on the screen.
There are 7 split mode opons:
1 In the preview mode, right-click on the mouse to display the
Pop-up menu.
2 Select Split Windows, then select an opon:
• CH 01-04
• CH 05-08
• CH 09-12
• CH 13-16
• CH 01-09
• CH 08-16
• CH 01-16
The selected channels will be displayed on the screen.
3.4.3 Picture-in-Picture (PIP) Mode
With Picture-in-Picture (PIP) mode, you can watch two more channels to be simultaneously displayed on the rst
channel live preview.
1 In the preview mode, right-click on the mouse
to display the Pop-up menu.
2 Select PIP > 1 X1 or 1 X2.
An addional mini-window appears on the main screen display.
3 To move the mini-windows around your main screen,
click and drag it to a new posion.
Second channel
For example: PIP 1 X1 mode
First channel
Note:
If you select 1 X2, two mini-window frame appear on the main screen display. This funcon only works if there are
more than two cameras connected to the DVR.
