Chapter 4: Using the DVR
DVR User’s Manual
51
4.5.3 Video and Audio Sengs
The VIDEO menu allows you to congure the video and audio output sengs, including the seng of Privacy Zone
which is used to hide an area on the screen from being viewed.
Seng the Video Output
1 In preview mode, right-click on the mouse to display the Pop-up menu.
2 Select Main Menu > SYSTEM > VIDEO.
3 Modify the necessary sengs.
Menu Item
Descripon
Video System Select the video system used in your locaon (NTSC/PAL).
VGA
Resoluon
Select the output resoluon.
OSD Output Select where you want to display the OSD menu when mulple monitors are connected
to the DVR (BNC Out, VGA, or Auto).
Rotate Time Set the interval me in seconds when changing screen display in Auto Switch mode. See
“3.4.5 Auto Switch View” on page 26
4 Click Edit.
Seng the Volume
1 In preview mode, right-click on the mouse to display the Pop-up menu.
2 Select Main Menu > SYSTEM > VIDEO.
3 Click Volume.
4 Drag the slider bar to adjust the output volume.
5 Click X to close the volume bar.
6 Click Apply to save volume sengs.
7 When data saving is complete, click OK.
