Chapter 1: Product Overview
8
DVR User’s Manual
Chapter 1: Product Overview
1.1 Features
This device supports the following features:
• Real-me high compression (H.264) and supports dual stream network transmission
• Remote view with Symbian, Windows Mobile, iPhone, Blackberry, and Android phones
• Mul monitor:
- VGA output with the maximum resoluon of 1440 x 900
- 1 built-in BNC video output
- 1 HDMI output with 1920 x 1080 resoluon ( oponal)
• Real-me remote view with IE browser
• PTZ control via built-in RS-485 port
• USB mouse or remote control on the OSD interface operaon
• Live view, record, playback, back up, and network transmission
• Alarm modes: Moon Detecon, Video Loss, HDD Full, and HDD Loss
• Supports simultaneous playback of up to 16 channels
• ADPCM audio compression and audio transmission via network
• Four privacy masks for private area protecon on each channel
• Automac maintenance funcon
• Up to two 2TB SATA HDD
• Email Alert funcon
• KGUARD DDNS Service (kguard.org) included
1.2 Package Contents
The following items come with your package. If any of them is missing or damaged, please contact your retailer.
1 2 3
4 5 6
7 8 9
DISPLAY
MODE
0
REC SEARCH
2X2
3X3
4X4
AUTO
ENTER
PIP
STOP
PLAY
FWD
REW
PAUSE
/FRAME
SLOW
MENU/ESC MUTE
ZOOM FOCUS IRIS
Z
_
F
_
I
_
LOCK
Z+ F+ I+ PTZ
Remote Control Mouse Baeries* CD-ROM
Power Cord Power Adapter BNC to RCA Cable Audio Cable
-
* Not available in all countries.
