Chapter 1: Product Overview
DVR User’s Manual
9
1.3 Parts and Funcons
1.3.1 Front Panel
1 8 9 10 11 12 13 142 3 4 5 6 7
16 15
No. Item Icon Descripon
1 Channel Buons
1 - 0
Press the buons to view the channel in full screen.
In menu opons, press to enter numbers.
2 Preview Press to display channels in mul-window.
3 Mute Press to acvate the mute funcon.
4 Play Press to enter Playback mode or play recorded videos.
5 Pause Press to pause the video playback or enter the frame-playback mode.
6 Stop Press to stop the video playback or stop manual recording.
7 Record Press to start manual recording.
8 Arrow Up Press to move up in OSD menu.
9 Arrow Down Press to move down in OSD menu.
10 PTZ / Enter
Press to enter PTZ mode.
In menu opons, press to enter the selected menu item and edit the seng.
11
Arrow Le /
Rewind
Press to move le in the OSD menu.
During video playback, press to rewind the video.
Also used for switching OSD control panel.
12
Arrow Right /
Fast Forward
Press to move right in OSD menu.
During video playback, press to fast forward the video.
13 Power Indicator Lights green to indicate the power is turned on.
14 HDD Indicator Blinks connuously to indicate the HDD is being accessed.
15 Menu / Escape Press to enter or exit the OSD menu.
16 USB port Connects to a USB device (ash drive, hard drive, recorder, etc).
