KS KSCOMPONENTSYSTEM KS650.2, KS60.2, KS50.
KSComponentSystem Owner’sManual KS650.2 / KS60.2 / KS50.2 Models: Note: The KS50.2 mounting ring attaches over the front of the woofer. All other KS Component models attach as shown in Figure 2. Figure 2 Door Body Door Panel Authorized Kicker Dealer: Congratulations on your KICKER purchase _________________________ Speaker cut-out Please record your purchase information and keep your sales receipt for validation of warranty.
TweeterMounting Figure 5 The tweeter can be mounted one of four ways: flush, surface, angled, and coaxial mounting. For flush mounting applications, please refer to the illustration in Figure 5. Choose a flat location on the panel with space behind the panel to allow room for the mounting nut and motor structure. After checking the clearances, cut a 1 15/16” (4.9 cm) diameter mounting hole in the panel. Position the shorter mounting nut behind the panel.
WiringMultipleSpeakers AcousticsLimitedWarranty Modern high performance component system speakers have a lower DC Resistance than what used to be available. The Kicker KS-Series component system speakers are rated at four ohms and work with any source unit or amplifier designed to operate at a four ohm load. If you want to use two KS-Series component system speakers (two midrange/woofers and two tweeters) on each channel of your source unit or amplifier wire the crossovers in series, as shown below.
