2519-7201-03(820-1281 Rev B)_da.qxd:_ 2011.1.25 Carbon Monoxide Alarm User’s Guide Models: KN-COB-LCB-A KN-COB-LCB-A • 120V AC Plug-In • 9V Battery Backup • Tamper Resist Feature ATTENTION: Please take a few minutes to thoroughly read this user’s guide which should be saved for future reference and passed on to any subsequent owner. Manual P/N 820-1281 Rev.
519-7201-03(820-1281 Rev B)_da.qxd:_ 2011.1.25 What to do When the Alarm Sounds! Carbon Monoxide Alarm Procedure WARNING: Activation of the CO Alarm indicates the presence of Carbon Monoxide (CO) which can kill you. 1) Operate the Test/Reset button; 2) Call your emergency services (Fire Department or 911); PHONE NUMBER: 3) Immediately move to fresh air - outdoors or by an open door/window. Do a head count to check that all persons are accounted for.
2519-7201-03(820-1281 Rev B)_da.qxd:_ 2011.1.25 Welcome Note: Many times throughout this User’s Guide, we will refer to Carbon Monoxide as “CO”. This Kidde carbon monoxide (CO) alarm is an important part of your family’s home safety plan. This alarm has been designed and tested to detect CO buildup in a residential environment. Your alarm is for use specifically in the home. As an owner of a CO alarm, there are some basic facts you should know about for your protection.
2519-7201-03(820-1281 Rev B)_da.qxd:_ 2011.1.25 Important Warning Statements WARNING: This product is intended for use in ordinary indoor locations of family living units. It is not designed to measure compliance with Occupational Safety and Health Administration (OSHA), commercial or industrial standards. It is not suitable for installation in hazardous locations as defined in the National Electric Code.
2519-7201-03(820-1281 Rev B)_da.qxd:_ 2011.1.25 1. Information About Carbon Monoxide General Carbon Monoxide Information Carbon monoxide is a colorless, odorless and tasteless poison gas that can be fatal when inhaled. CO inhibits the blood’s capacity to carry oxygen. Periodically review this alarm manual and discuss your CO alarm emergency procedure with all the members of your family. Never ignore a CO alarm. A true alarm is an indication of potentially dangerous levels of CO.
2519-7201-03(820-1281 Rev B)_da.qxd:_ 2011.1.25 1. Information About Carbon Monoxide Possible Sources of Carbon Monoxide Inside your home, appliances used for heating and cooking are the most likely sources of CO. Vehicles running in attached garages can also produce dangerous levels of CO. CO can be produced when burning any fossil fuel, such as gasoline, propane, natural gas, oil and wood.
2519-7201-03(820-1281 Rev B)_da.qxd:_ 2011.1.25 1. Information About Carbon Monoxide To be safe, know the possible sources of CO in your home. Keep fuelburning appliances and their chimneys and vents in good working condition. Learn the early symptoms of exposure, and if you suspect CO poisoning, move outside to fresh air and get emergency help. Your first line of defense is an annual inspection and regular maintenance of your appliances.
2519-7201-03(820-1281 Rev B)_da.qxd:_ 2011.1.25 1. Information About Carbon Monoxide • CO being present on one level of the home and not reach a CO alarm installed on a different level. (For example, CO in the basement may not reach an alarm on the second level, near the bedrooms). For these reasons, we recommend you provide complete coverage by placing a CO alarm on every level of the home. Please carefully read all information on properly installing this CO alarm.
2519-7201-03(820-1281 Rev B)_da.qxd:_ 2011.1.25 2. Product Features and Specifications Tamper-Resist Feature This is an alert to notify consumers the unit has been unplugged or has come loose from the outlet. This feature is not activated for two minutes after power is first supplied to give you time to plug the unit in after activating the battery. This feature is also disabled once the battery voltage has reached a level to cause a low battery warning chirp.
2519-7201-03(820-1281 Rev B)_da.qxd:_ 2011.1.25 2. Product Features and Specifications Low Battery HUSH® CONTROL When the battery needs to be replaced, the unit will produce a low battery warning. The Low Battery HUSH® feature allows you to press the button on the alarm and disable the “chirp” for a random period of up to 12 hours. This gives you a chance to replace the battery at a more convenient time without sacrificing your safety by disconnecting the alarm from power.
2519-7201-03(820-1281 Rev B)_da.qxd:_ 2011.1.25 3. Installation Locations Recommended Installation Locations CO alarms should be mounted in or near bedrooms and living areas. It is recommended that you install a Kidde CO alarm on each level of your home. When choosing your installation locations, make sure you can hear the Recommended Locations alarm from all sleeping areas. If you install only one CO alarm in your home, install it near bedrooms, not in the basement or furnace room.
2519-7201-03(820-1281 Rev B)_da.qxd:_ 2011.1.25 4. Installation Instructions How to Install Your Alarm Direct Plug Alarm To install: 1. Choose a standard 120V unswitched outlet to plug the alarm into. 2. Pull the yellow tab to activate the battery backup. 3. Plug the alarm into the outlet. CAUTION: Do not rotate the alarm while it is plugged into an outlet, as damage to plug may result.
2519-7201-03(820-1281 Rev B)_da.qxd:_ 2011.1.25 6.Operating Characteristics When you first power up the alarm: The alarm will sound briefly, then the green Operate LED will light. This indicates that the CO alarm is receiving power and that the alarm circuit is functioning. Within a few minutes, your carbon monoxide alarm will start monitoring for CO and will continue to do so as long as it receives power.
2519-7201-03(820-1281 Rev B)_da.qxd:_ 2011.1.25 7. Maintenance NOTE: This unit is sealed. The cover is not removable. Due to the loudness of the alarm, we suggest that you place your fingers over the sounder opening while testing your alarm. CAUTION: Continuous exposure to the high sound level of this alarm over an extended period of time may cause hearing loss.
2519-7201-03(820-1281 Rev B)_da.qxd:_ 2011.1.25 7. Maintenance Maintenance Tips To keep your alarm in good working order, you must follow these steps: • Test the alarm once a week by pressing the Test/Reset button. • Vacuum the alarm cover once a month to remove accumulated dust. • Instruct children never to touch, unplug or otherwise interfere with the unit. Warn children of the dangers of CO poisoning. • Never use detergents or solvents to clean the alarm.
2519-7201-03(820-1281 Rev B)_da.qxd:_ 2011.1.25 FIVE YEAR LIMITED WARRANTY Warranty Coverage: The manufacturer warrants to the original consumer purchaser, that this product (except battery) will be free of defects in material and workmanship for a period of five (5) years from date of purchase. The manufacturer’s liability hereunder is limited to replacement of the product, repair of the product or replacement of the product with repaired product at the discretion of the manufacturer.
