Electronic Thermostat ES120/ES230/ESP230

ES saves up to 15% on your heating costs Electronic temperature sensing is the most accurate technology

ESP saves up to 28% on your heating costs 3 minute cycle rate reduces temperature swings and increases

Even temperature control comfort at all control settings

3-wire installation Complies with all codes requiring anticipated or electronic thermostats

LCD display of room temperature Single pole design with third wire to power display

Red LED Heater ON Indicator Shallow design allows more wiring room inside full electrical boxes

Comfort Color Back light Display Available in 120V or 208/240V

(Red at 75ºF / Blue at 65ºF) System On/Off switch 1 year warranty

VOLTSUPCMODEL AMPS

Ordering Information

TYPE WIRE LEADS TEMP. RANGE

ES120-R 10372 Electronic Line Voltage 3 Wire 120 22 40ºF-95ºF

ES230-R 10374 Electronic Line Voltage 3 Wire 208/240 22 40ºF-95ºF

ESP230 10374 7-Day Programmable 3 Wire 208/240 22 44ºF-95ºF

ESP230-R 10372 7-Day Programmable 3 Wire 208/240 22 44ºF-95ºF

3-1/8”

4-7/8”

1-1/4”

2”

Dimensional Data

ES120

ES230

Non Programmable

ESP230

Programmable

The ES Electronic Thermostat

This line voltage thermostat is one of-a-kind in features then

improved with memory backup for power outages. All the

features you want with only two buttons. Simple has always

been better. Two keys on the front control the temperature up

and down. With comfort color back lighting and an on/off switch

to control the illumination and system. Comfort color back light

display is blue at 65ºF and red at 75ºF and varies in color

between making it quick and easy to know your temperature.

The illuminated LCD display can be read across the room making

it easy to see at night. Simple, accurate control is the goal of the

ES model. No fancy programming, just dependable temperature

control for your home, saving money on your heating bills.

The ESP Electronic Programmable

This thermostat took years to develop and has become a popular

model. All the features you want without too many buttons. Simple

is always better. We have added backlighting to the full-size display

and an on/off switch to control the illumination. On the front two

simple buttons control the temperature up and down, while all the

programming keys are hidden under the front cover, protected

from wandering, unauthorized ﬁngers. Comfort and convenience is

always our primary goal at King.

Temperature Range: 40°F - 95°F (4°-35°C)

Temperature Default: Your saved setting

Display Format: LCD

Illumination: Blue/Red LED

Sample Rate: Every 60 seconds

Room Temp. Display: Large LCD

Delay: 3 minutes on or off

Accuracy: NEMA TEST 1.5°F @ 22 Amps,

1.4°F @ 16 Amps, 1.2°F @ 10 Amps,

0.9°F @ 4.2 Amps

Power Source: 120 VAC (ES120),

208/240 VAC (ES230), 50 - 60Hz

Battery Backup

• 22 Amps at 240V, 5280 Watts

• 22 Amps at 208V, 4576 Watts

• 22 Amps at 120V, 2640 Watts

• Wire leads #12 AWG

• 40°F to 95°F set point range

• Electronically anticipated

ESP Technical SpeciﬁcationsES Technical Speciﬁcations

• 120V or 208/240V models only

• Digital thermometer/set point

• Meets energy requirements

• Three wire installation

• Snap action relay built-in

• 30 Amp relay

• 3 min. delay between cycles

• For use on all types of electric

heaters, fan-forced, baseboard,

radiant, etc.

• Single button operation

• Thermistor sensor

• Contemporary styling

• LCD display

• 1.5 degrees maximum

• 3/4" depth into wire box

• On/Off switch for back light

• On/Off switch for system

Temperature Range: 44°F - 95°F (7°-35°C)
