User's Manual

Solar Shield
CPRI-1
(primary)
CPRI-2
(secondary)
Status LED
2. Product overview – physical interfaces
Bottom view
GND GND
-48V
DC IN
alarms ports
AISG
(output)
Rx3
TxRx2
Rx4
TxRx1
Notes:
Solar shield now shown in these views
GND = Protective Earth (PE) ground located on
GND = Protective Earth (PE) ground
,
located on
lower right side and lower right side of RRH (when
facing front of RRH)
Alcatel-Lucent RRH 2x60-B4
Alcatel-Lucent – Internal
Proprietary – Use pursuant to Company instruction
3MN-01520-0002-RJZZA Issue 0.02 March 2014
Sheet 7 of 24
Rear view
