ITEM #0864447 FLOODLIGHT MODEL #KFL 124B-03 Español p. 11 ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST, Monday - Friday.
TABLE OF CONTENTS Product Specifications....................................................................................... 2 Package Contents............................................................................................. 3 Safety Information............................................................................................. 4 Preparation........................................................................................................ 5 Operating Instructions................
PACKAGE CONTENTS C E A B D G F PART DESCRIPTION A Light head PART DESCRIPTION E ON/OFF switch B Transparent cover F Tripod mount 5/8 in. - 11UNC C Carry handle G Tripod mount 1/4 in. D Pedestal WARNING • Remove the tool from the package and examine it carefully. Do not discard the carton or any packaging material until all parts have been examined.
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble or operate this product. If you have any questions regarding the product, please call customer service at 1-888-3KOBALT, 8 a.m. - 8 p.m., EST, Monday - Friday. Know the Tool To operate this tool, carefully read this manual and all labels affixed to the tool before using it. Keep this manual available for future reference. Important This tool should be serviced only by a qualified service technician.
SAFETY INFORMATION Save all warnings and instructions for future reference • Know your floodlight. Read the operator’s manual carefully. Learn the applications and limitations, as well as the specific potential hazards related to this tool. Following this rule will reduce the risk of electric shock, fire or serious injury. • Do not use outdoors. This floodlight is intended for household use only. Using it outdoors may increase the risk of electric shock or fire.
PREPARATION Know Your Floodlight Before attempting to use the floodlight, familiarize yourself with all of its operating features and safety requirements. WARNING • Do not allow familiarity with the tool to cause carelessness. Remember that one careless moment is enough to cause severe injury. Before attempting to use any tool, be sure to become familiar with all of the operating features and safety instructions.
OPERATING INSTRUCTIONS 1. To Attach Battery Pack a. b. Align the raised portion on the battery pack with the grooves on the bottom of the tool, then slide the battery pack onto the tool as shown. Make sure that the battery-release buttons on the battery pack snap into place and the battery pack is secured to the tool before beginning operation.
OPERATING INSTRUCTIONS 3. Upright Position Carefully swivel the pedestal away from the body and place the floodlight on the floor or other stable surface. Ensure that it has a firm footing. 4. Swiveling the Light Head The light head can be swiveled a maximum 180°, in 30-degree increments, to suit the application. 4 30° 180° 0° 5. Fastening to an Optional Tripod You may use the tripod mount (F, G) to screw the floodlight onto an optional tripod that has 5/8 in. - 11UNC threading or 1/4 in.
TROUBLESHOOTING WARNING • Press the ON/OFF button to switch off the floodlight, and remove battery from the tool before performing troubleshooting procedures. PROBLEM The floodlight does not work. POSSIBLE CAUSE CORRECTIVE ACTION 1. Low battery capacity. 1. Recharge the battery. 2. The floodlight has stopped working to protect internal circuits. 2. Turn off the floodlight, wait for the tool and battery to cool down, then start the tool again.
ARTÍCULO #0864447 REFLECTOR MODELO #KFL 124B-03 ADJUNTE SU RECIBO AQUÍ Número de serie Fecha de compra ¿Preguntas, problemas, piezas faltantes? Antes de volver a la tienda, llame a nuestro Departamento de Servicio al Cliente al 1-888-3KOBALT (1-888-356-2258), de lunes a viernes de 8 a.m. a 8 p.m., hora estándar del Este.
ÍNDICE Especificaciones del producto......................................................................... 12 Contenido del paquete.................................................................................... 13 Información de seguridad................................................................................ 14 Preparación..................................................................................................... 16 Instrucciones de funcionamiento...................................
CONTENIDO DEL PAQUETE C E A B D G F PIEZA DESCRIPCIÓN PIEZA DESCRIPCIÓN A Cabezal de la lámpara E Interruptor de ENCENDIDO/ APAGADO B Cubierta transparente F Montaje de trípode de 5/8 pulg - 11UNC C Mango para transportar G Montaje de trípode de 1/4 pulg D Pedestal ADVERTENCIA • Retire la herramienta del paquete y examínela con cuidado. No deseche la caja ni ningún material de embalaje hasta después de examinar todas las piezas.
INFORMACIÓN DE SEGURIDAD Lea y comprenda completamente este manual antes de intentar ensamblar u operar este producto. Si tiene preguntas relacionadas con el producto, llame al Departamento de Servicio al Cliente al 1-888-3KOBALT, de lunes a viernes de 8 a.m. a 8 p.m., hora estándar del Este. Conozca la herramienta Para operar esta herramienta, lea cuidadosamente este manual y las etiquetas fijadas a la herramienta antes de usarla. Guarde este manual para referencia futura.
INFORMACIÓN DE SEGURIDAD • Lea todas las advertencias de seguridad, las instrucciones, las ilustraciones y las especificaciones que incluyen esta herramienta eléctrica. No seguir todas las instrucciones que se detallan a continuación puede provocar descargas eléctricas, incendios o lesiones graves. Guarde todas las advertencias e instrucciones para referencia futura • Conozca su reflector. Lea el manual del operador con atención.
PREPARACIÓN Conozca su reflector. Antes de intentar usar el reflector, familiarícese con todas sus características de funcionamiento y con los requisitos de seguridad. ADVERTENCIA • Sea cuidadoso, incluso si está familiarizado con la herramienta. Recuerde que un momento de descuido es suficiente para causar lesiones graves. Antes de intentar utilizar cualquier herramienta, asegúrese de familiarizarse con todas las funciones de operación e instrucciones de seguridad.
INSTRUCCIONES DE FUNCIONAMIENTO 1. Para fijar el paquete de baterías a. b. Alinee la parte elevada del paquete de baterías con las ranuras de la parte inferior de la herramienta y luego deslice el paquete de baterías en la herramienta, como se muestra. Asegúrese de que los botones de liberación de la batería del paquete de baterías encajen en su lugar y que el paquete de baterías quede fijo a la herramienta antes de comenzar la operación.
INSTRUCCIONES DE FUNCIONAMIENTO 3. Posición vertical Gire con cuidado el pedestal lejos del cuerpo y coloque el reflector en el suelo o sobre otra superficie estable. Asegúrese de tener un apoyo de pies firme. 4. Para girar el cabezal El cabezal puede girar a un máximo de 180°, en incrementos de 30 grados para adaptarse a la aplicación. 4 30° 180° 0° 5.
SOLUCIÓN DE PROBLEMAS ADVERTENCIA • Presione el botón de ENCENDIDO/APAGADO para apagar el reflector y retire el paquete de baterías de la herramienta antes de realizar cualquier procedimiento de solución de problemas. PROBLEMA El reflector no funciona. CAUSA POSIBLE ACCIÓN CORRECTIVA 1. La capacidad de la batería es baja. 1. Recargue la batería. 2. El reflector ha dejado de trabajar para proteger los circuitos internos 2.
