ITEM #0498363 1/4 IN. RATCHET WRENCH MODEL #SGY-AIR214 Français p. 16 Español p. 31 KOBALT ®and the K Design® are registered trademarks of LF, LLC. All Rights Reserved. ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT, 8:00 a.m.-8:00 p.m., EST, Monday-Friday.
TABLE OF CONTENTS Product Specifications ...................................................................................... 3 Safety Information ............................................................................................ 3 Package Contents ........................................................................................... 9 Preparation ....................................................................................................... 9 Assembly Instructions .................
PRODUCT SPECIFICATIONS COMPONENT SPECIFICATIONS FREE SPEED SQUARE DRIVE MAXIMUM TORQUE WORKING PRESSURE AVERAGE AIR CONSUMPTION AIR INLET RECOMMENDED AIR HOSE 250 RPM 1/4 in 30 ft-lbs 90 PSI 5.1 CFM 1/4 in. NPT 3/8 in. (inside diameter) SAFETY INFORMATION Please read and understand this entire manual before attemptingto assemble, operate or install the product. If you have any questions regarding the product, please call customer service at 1-888-3KOBALT, 8:00 a.m.-8:00 p.m., EST, Monday-Friday.
SAFETY INFORMATION WA R N I N G RISK OF EYE OR HEAD INJURY WHAT COULD HAPPEN HOW TO PREVENT IT This particular air powered tool can be capable of propelling materials such as fasteners, metal chips, sawdust, and other debris at high speed which could result in serious injury. Always wear ANSI approved Z87.1 safety glasses with side shields. Never leave operating tool unattended. Disconnect air hose when tool is not in use, and place in a safe area.
SAFETY INFORMATION WA R N I N G RISK OF ENTANGLEMENT WHAT COULD HAPPEN HOW TO PREVENT IT Tools which contain moving elements or drive other moving parts, such as impact sockets, can become entangled in hair, clothing, jewelry and other loose objects, resulting in severe injury. Do not wear loose clothing, jewelry, or anything that may get caught or tangled when using tool. Remove any jewelry which may be caught by the tool. Always keep hands and body parts away from moving parts.
SAFETY INFORMATION WA R N I N G RISK OF PERSONAL INJURY WHAT COULD HAPPEN HOW TO PREVENT IT A tool left unattended or with the air hose attached can be activated by unauthorized persons leading to their injury or injury to others. Remove air hose when tool is not in use and store tool in secure location away from reach of children and untrained users. Air tools can propel fasteners or other materials throughout the work area. Use only parts, fasteners and accessories recommended by the manufacturer.
SAFETY INFORMATION WA R N I N G RISK OF PERSONAL INJURY WHAT COULD HAPPEN HOW TO PREVENT IT Keep proper footing at all times. Do not overreach, as slipping, tripping, and or falling can be a major cause of serious injury and or death. Be aware of excess air hose and power plugs in the working area or work surface. Loss of control of the tool can lead to injury to self of others in the work area. Keep handles dry, clean and free from oil/grease. Stay alert. Watch what you are doing. Use common sense.
SAFETY INFORMATION WA R N I N G RISK OF PERSONAL INJURY WHAT COULD HAPPEN HOW TO PREVENT IT There is a risk of bursting if the tool is damaged. Follow lubrication instructions for best and safest operation. Follow assembly and repair instructions on how to properly change accessories. Use of an accessory not intended for use with a specific tool increases the risk of injury to operator and anyone in the work area.
PACKAGE CONTENTS C A E B D PART A B C D E DESCRIPTION Ratchet Wrench Anvil Forward/Reverse Knob Trigger Air Inlet QUANTITY 1 1 1 1 1 PREPARATION Before beginning the assembly of the product, make sure all parts are present. Compare parts with package contents list. If any part is missing or damaged, do not attempt to assemble the product.
ASSEMBLY INSTRUCTIONS 1. Remove the air inlet protective cap from the air inlet (E) (See Figure 1). 1 2. Mount a male plug (not included) by hand into the air inlet (E) (See Figure 2). 2 NOTE Use threaded sealant tape (not included) on the threading of the male plug. Once sealant tape is properly in place, tighten male plug turning clockwise with a wrench (not included) for air tight connection. DO NOT OVERTIGHTEN. 3.
ASSEMBLY INSTRUCTIONS 4. Mount a 1/4 in. to 3/8 in. adapter (not provided) onto the anvil (B) if necessary, and then choose the correct impact socket (not provided) as needed and mount it onto the adapter (See Figure 4). 4 WARNING Only use adapter and sockets that have a torque rating equal to or greater than the tool itself. Before using tool, always make sure attachments are properly mounted/secured.
OPERATING INSTRUCTIONS Clockwise 2. To remove or loosen the threaded fasteners/workpiece, turn the forward/reverse knob (C) clockwise to the reverse position. Press the trigger (D). The tool anvil (B) runs counterclockwise removing/loosening the threaded fasteners/workpiece.
CARE AND MAINTENANCE Always remove tool from air supply before performing any maintenance on tool. An in-line oiler (not included) is recommended to be installed to air supply. It will help increase tool life and keep the tool properly lubricated. The in-line oiler should be regularly checked and filled with air tool oil as needed. To check if the in-line oiler is properly lubricating the tool, place a sheet of paper next to the tool’s exhaust ports while holding the throttle completely open for 30 seconds.
WARRANTY This tool is warranted by the manufacturer to the original purchaser from the original purchase date for three (3) years subject to the warranty coverage described herein. This tool is warranted to the original user to be free from defect in material and workmanship. If you believe that a tool is defective, return the tool, with proper proof of purchase to the point of purchase.
EXPLODED VIEW 29 30 23 24 25 26 27 28 21 22 1 20 2 3 4 5 31 32 9 12 C 34 35 37 36 B 39 41 40 19 18 17 16 15 14 13 11 10 E 42 45 43 44 Part No.
